2. Introduction

To install the Enphase IQ Battery 10C, read and follow all warnings and instructions in this quick installation guide (QIG). Safety
warnings are listed at the start of this guide. These instructions are not meant to be a complete explanation of how to design and
install an energy storage system. All installations must comply with national and local codes and standards. Only Enphase-certified
installers shall install, troubleshoot, or replace the IQ Battery 10C.
The IQ Battery 10C system includes the battery cell pack with integrated IQ Microinverters (SKU: IQ8BL, IQ8BN) and the battery
management system (BMS). The system requires IQ Combiner 6C and IQ Meter Collar for the backup operation. The IQ Gateway
inside the combiner measures PV production, IQ Battery 10C charge/discharge power, and home energy consumption, and it senses
when it is optimal to charge or discharge the battery so that energy is stored when it is abundant and used when it is scarce.
Key specifications
Rated (continuous) output power
Rated output current (@240 V
Rated neutral current (@120 V
Interconnection
Nominal voltage
Nominal frequency
3
Usable capacity
Ambient operating temperature range (charging)
Ambient operating temperature range (discharging)
Chemistry
Mounting
Dimensions (H × W × D)
Maximum lifting weight
Total installed weight
1
7.08 kVA, 29.5 A for the balanced 240V L-L loads.
2 A maximum of 24 A, 120V L-N unbalanced loads can be supported along with 5.5 A, 240V L-L loads.
3 The battery's usable capacity supports loads, and turns PV on (when off-grid), in normal daily operation. The usable capacity includes a safety
critical limit of 2% that safeguards the customer's asset in case of a long-duration grid outage. An additional 3% capacity is maintained for
powering battery electronics at night. Refer to
4
A reduction in charging power occurs at temperatures below 15°C and above 45°C.
5
A reduction in discharging power occurs at temperatures below 5°C and above 50°C.
AC~)
L-L
AC~)
L-N
4
5
http:/ /link.enphase.com/iqbattery_usable_capacity_en_na
7.08 kVA
1
29.5 A
2
24 A
Single-phase
240/ 120 VAC~
60 Hz
10.0 kWh
–4°F to 122°F (–20°C to 50°C) Non-condensing
–4°F to 131°F (–20°C to 55°C) Non-condensing
Lithium iron phosphate (LFP)
Wall-mount or pedestal-mount (sold separately)
24.5 in × 28 in × 14.4 in (621 mm × 708 mm × 362 mm)
125 lb (57 kg)
317 lb (144 kg)
EN-8
for more information.
