IQ Battery 5P
Quick install guide
Scan for the latest
quick install guide
Suchen Sie nach der neuesten
Schnellinstallationsanleitung
Scansione della
Guida all'installazione rapida più recente
Recherchez le dernier
guide d'installation rapide
Scannen voor de nieuwste
quick install guide
Procurar o Guia de Instalação
Rápida mais recente
Buscar la última
Guía de instalación rápida
Σάρωση για τον πιο πρόσφατο
Οδηγό γρήγορης εγκατάστασης
M ODE L
I QB AT TER Y-5P-1P-INT
I QB AT TER Y-10Z-1P -INT
V E R SI O N 5. 0
AUG US T 2024
To exchange with ROW barcode
IQ Battery 5P quick install guide
ENGLISH
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IQ Battery 5P and is the answer not in the manual?

Questions and answers

Related Manuals for enphase IQ Battery 5P

Summary of Contents for enphase IQ Battery 5P

  • Page 1 Οδηγό γρήγορης εγκατάστασης M ODE L I QB AT TER Y-5P-1P-INT I QB AT TER Y-10Z-1P -INT V E R SI O N 5. 0 AUG US T 2024 To exchange with ROW barcode IQ Battery 5P quick install guide...
  • Page 2 To install the Enphase IQ Battery 5P, the top protective shield and the bottom mounting bracket, read and follow all warnings and instructions in this guide. Safety warnings are listed at the end of this guide. These instructions are not meant to be a complete explanation of how to design and install an energy storage system.

  • Page 3: Table Of Contents

    Cable routing and closing the wiring cover Plan a location for the IQ Batteries Energizing and configuring the system 33 Mounting the product Installing the IQ Battery 5P cover Plan a location for the IQ Batteries Disassembling the IQ Battery 5P cover 37 Minimum clearance...

  • Page 4: What's In The Box

    — Quick install guide (QIG) — Anchor Clip — Wall drill template — Cable ties — Control (CTRL) connector (one spare, one pre-installed) — Control (CTRL) connector with resistor (one spare, one pre-installed) — IQ Battery 5P quick install guide...

  • Page 5: Product Compatibility/Additional Items Required

    Installer standard screws only (head thickness <5 mm) (Min. 6) (Min. 6) Washers As required Installer IQ Battery 5P lifting handles. Includes one left-side and one Enphase distributor/ right-side lifting handle (SKU: IQBATTERY-HNDL-5) Installer IQ Battery 5P quick install guide...
  • Page 6 To increase installed capacity, a 5 kWh IQ Battery 5P expansion unit or another IQ Battery 10Z can be installed after one IQ Battery 10Z installation. NOTE: IQ Battery 5P is an expansion unit over IQ Battery 10Z in South Africa. IQ Battery 5P quick install guide...

  • Page 7: Unboxing Iq Battery 5P

    IQ Battery packaging and store it securely for use during the installation of IQ Battery 5P. WARNING: Do not lift the packaging with the battery inside **NOTE: To install handles on the IQ Battery 5P, follow steps 1 after the plastic straps are cut. to 3 in Installing IQ Battery...

  • Page 8: Mounting The Product

    0ºC to 30ºC. -20°C • Installing in direct sunlight or a location where the IQ Battery 5P is subject to higher or lower temperatures will result in reduced battery performance: • Charging at rated power happens between 15°C and 45°C. Reduction in charging power will occur at temperatures below 15°C and above 45°C.

  • Page 9: Mounting The Product

    The maximum conductor size compatible with IQ Battery 5P is 25 mm2, and the maximum circuit breaker rating with this conductor size is 80 A B curve. Use a 20 A B curve circuit breaker for one IQ Battery 5P and Max. 80 A B curve circuit breaker for four Maximum 4 batteries batteries on the same circuit.

  • Page 10: Minimum Clearance

    The mounting instructions that follow are for the included wall-mount distance between the covers of two units should be 76 mm. bracket only. If you wish to install IQ Battery 5P in a floor-mount Installation handles cannot be used for clearance less than...

  • Page 11: Mounting Surface

    NOTE: If the variation of the flatness is more than 2 mm, the battery might not properly sit on the bottom mounting bracket through keyholes. Use spacers or unistruts if the variation is more than 2 mm. IQ Battery 5P quick install guide...

  • Page 12: Install The Bottom Mounting Bracket And The Top Protective Shield

    The bottom mounting bracket carries the weight of the IQ Battery 5P, • Use a minimum of six M6 screws for mounting the top protective and the top protective shield covers the back of the IQ Battery 5P. shield to the wall. Use standard screws only (head thickness <5 mm).
  • Page 13 M8 screws or lag bolts (symmetrically distributed) for multiple vertical mounting slots. Tighten all screws to the manufacturer’s specified torque values. A drill template is included in the IQ Battery 5P packaging to simplify marking of all necessary drilling points. Select the Washer appropriate instructions from the template based on the type of the mounting surface of installation.
  • Page 14 NOTE: Use an electric drive; do not use impact drives or impact drills to tighten the grounding screws. Two M4 grounding screws Fix the top protective shield to the bottom mounting bracket 9(a)(b). at the earth bonding flange. IQ Battery 5P quick install guide...
  • Page 15 Use standard screws only (head thickness <5 mm). Finally, fully tighten the M4 grounding screws between the two shields (torque to 1.5 N m). IQ Battery 5P quick install guide...
  • Page 16 Use standard screws only (head thickness <5 mm). Finally, fully tighten the M4 grounding screws (torque to 1.5 N m). IQ Battery 5P quick install guide...

  • Page 17: Installing Iq Battery 5P

    Otherwise, use mechanical lifting. backplate or wiring cover. WARNING: Do not lift the IQ Battery 5P using microinverters or the plastic behind the microinverters. This may damage the unit permanently.
  • Page 18 Install cable glands on the sides where cable entry is planned before mounting the units on the wall. WARNING: Risk of equipment damage. For rear cable entry, wall drilling should be done before mounting the IQ Battery 5P on the wall. IQ Battery 5P quick install guide...
  • Page 19 Opening on one side can either be used for only entry or exit of the cables. For example, if the cable is entering on the left side, then the cable outlet for the next IQ Battery 5P in the circuit should always be on the right side and vice-versa.
  • Page 20 NOTE: Use lift assist to avoid any mishap during lifting. 9 & 10. To remove the installation handles, pull the plunger outward to unlock them. Then, slide the handle down and pull it away from the unit to remove it. IQ Battery 5P quick install guide...
  • Page 21 Vents or drain holes WARNING: The vent or drain holes provided at the back of the unit serve the dual purpose of natural ventilation and condensation drainage. Blocking these holes can affect the functionality of the product. IQ Battery 5P quick install guide...

  • Page 22: Installation Of Anchor Clip

    13 & 14. Install two Anchor Clips to secure the top section of the IQ Battery 5P to the wall. Slide the Anchor Clip downwards until the top surface of the clip coincides with the top surface of the IQ Battery 5P backplate. IQ Battery 5P quick install guide...

  • Page 23: Wiring

    NOTE: When adding additional IQ Battery 5P units to an existing IQ Battery 5P site, disconnect B1 and B2 (DC connectors)* on the adjacent existing IQ Battery 5P units. *Refer to section C -...
  • Page 24 NOTE: Both L terminal blocks are shorted. Any free L terminal can be used for external connections. The N terminals are also wired similarly. NOTE: The terminal blocks provide multiple free terminals for interconnecting IQ Battery 5P units. The figure shows an example. IQ Battery 5P quick install guide...
  • Page 25 Section C - Wiring The control communication board for the IQ Battery 5P is located above the terminal block for the power. Two CTRL connectors and one drain connector are provided for the control commuication cable connection. CTRL connector (C1)
  • Page 26 C T R L S I G N A L S Screw terminal 1 CTRL L- LOW Screw terminal 2 CTRL H- HIGH Screw terminal 3 CTRL G- GROUND Screw terminal 4 Not used IQ Battery 5P quick install guide...
  • Page 27 NOTE: To ensure optimal system performance, the total length of control communication wiring across the system must not exceed 100 m. NOTE: As long as local regulations allow, the same conduits can be used for power and control communication wire routing with Enphase-recommended control communication cables (order code: CTRL-BL-EU-01). IQ Battery 5P quick install guide...

  • Page 28: Control Communication Wiring Between System Components In Grid-Tied Configuration

    Sequence 2 Sequence 2 IQ Battery 5P → Communications Kit 2 INT → IQ Battery 5P IQ Battery 5P → Communications Kit 2 INT → IQ Battery 5P *Earth connection is needed only if the control cable drain wire is being connected to the terminal. The terminal can accept *Earth connection is needed only if the control cable drain wire is being connected to the terminal.

  • Page 29: Control Communication Wiring Between System Components In Backup Configuration

    Sequence 2: Sequence 2: IQ Battery 5P → IQ System Controller 3 INT → IQ Battery 5P IQ Battery 5P → IQ System Controller 3 INT → IQ Battery 5P IQ Battery 5P IQ System Controller 3 INT...

  • Page 30: Cable Routing And Closing The Wiring Cover

    Communications Kit 2 has a cutout only on one side, and all If the voltage is within the range as required by local codes, other sides are covered. turn off the AC power supply. IQ Battery 5P quick install guide...
  • Page 31 NOTE: Connect CS1 at last to avoid damage to the wiring cover. WARNING: Ensure that all the connectors are latched properly and a clicking sound is heard. Cut two cable ties and insert the connector on CS1 in the BMS board IQ Battery 5P quick install guide...
  • Page 32 HS DIRECTIVE 2015/863/EU). MANUFACTURER WILL BE REQUIRED TO COLOR PANTONE COLOR CODE CT BETWEEN THE SPECIFICATIONS AND RoHS COMPLIANCE, THE PANTONE BLACK 6 C TION. THIRD ANGLE PR PANTONE 109 C PANTONE 2347 C IQ Battery 5P quick install guide...

  • Page 33: Energizing And Configuring The System

    ON and commissioned. Apply AC power to the IQ Battery 5P circuits. The LED flashes green once and switches off. After 15-20 seconds, it starts flashing in a red triple-flash pattern.

  • Page 34: Installing The Iq Battery 5P Cover

    Section E Installing the IQ Battery 5P cover Ensure the wiring cover(s) for all IQ Batteries in the system are closed and secured. WARNING: Risk of equipment damage. Make sure no wires are pinched before placing the cover. WARNING: Do not leave the Control...
  • Page 35 Section E - Installing the IQ Battery 5P cover 5 & 6. Push in the top portion of the cover as shown and make sure 3 & 4. Before releasing the IQ Battery 5P cover, pull out the lower that the cover is locked in place.
  • Page 36 Section E - Installing the IQ Battery 5P cover Peel off the sticker after the installation is complete. After installing the cover, the conduit cover should be installed to cover the opening in the IQ Battery 5P cover on the side. If a conduit or cable gland is installed, the conduit cover is not necessary on that side.

  • Page 37: Disassembling The Iq Battery 5P Cover

    2a & 2b. Remove the two M5 ID cover grounding screws, IQ Battery 5P cover. which are used to fix the cover to the backplate. NOTE: Use a screwdriver or electric drive; do not use impact drives or impact drills. IQ Battery 5P quick install guide...
  • Page 38 Unlock the top plastic cover from the ribs. Make sure the cover is slightly inclined after this step. Pull the cover off in the indicated direction. IQ Battery 5P quick install guide...

  • Page 39: Disengaging The Anchor Clip

    WARNING: Ensure not to touch or damage the EMI metal gaskets while removing the clips. EMI metal gaskets are delicate and need to be handled carefully. IQ Battery 5P quick install guide...

  • Page 40: Operation

    Red single flash Upgrade fail Red double flash IQ Battery 5P is in an error state. Contact Enphase Support to troubleshoot the issue. Red triple flashes DC control switch is OFF, and AC from external source is present. Soft pulse red DC control switch is ON, and AC from external source is NOT present.

  • Page 41: Operating Mode

    Ensure the DC switch is in the OFF position using the following steps: • If the IQ Battery 5P LED is OFF, the DC switch is OFF, and the IQ Battery 5P is in shutdown mode. • If the IQ Battery 5P LED (any colour) is ON, press the DC switch once to turn it OFF and place IQ Battery 5P in shutdown mode.

  • Page 42: Safety

    DANGER: Risk of fire. If the IQ Battery(ies) generate smoke, remove AC following steps: power from the Enphase system and turn the DC control switch to the off position so that charging/discharging stops. DANGER: DO NOT TOUCH OR INGEST ANY LIQUID SUSPECTED TO BE BATTERY ELECTROLYTE.
  • Page 43 United States of America NOTE: Use a G99 type tested third-party network protection relay for PH: +1 (707) 763-4784 IQ Battery 5P units with a system size above 17 kW per phase. Note for third-party products: Environmental Protection ELECTRONIC DEVICE: DO NOT THROW AWAY. Waste electrical products Any third-party manufacturer or importer product(s) used to install or should not be disposed of with household waste.

  • Page 44: Revision History

    140-00333-03 November 2023 • Editorial updates. Updated the “LED status”, “Control communication wiring”, and “What’s in the 140-00333-02 October 2023 box” sections and made editorial updates throughout the document. 140-00333-01 July 2023 Initial release. IQ Battery 5P quick install guide...
