7. Unboxing the IQ Battery 10C
Each IQ Battery 10C comes with two 5 kWh battery unit boxes and one IQ Battery 10C cover kit box.
Before unboxing IQ Battery 10C - 5 kWh battery unit, check the "Energize By" label on the shipping box to verify that the IQ Batteries
will be installed by the date shown. If the date has passed, contact your distributor for next steps.
Follow the steps, as shown in the following image:
1
Cut open the straps
4
Carefully take out the mounting bracket
and keep it aside
NOTE: Follow the steps mentioned in
Ensure to take out the accessories bag included in the IQ Battery packaging and store it securely for use during the installation.
Inspect the packaging and the IQ Battery(ies) for any signs of damage, such as cracks, dents, or electrolyte leakage. Do not install
or use the IQ Battery(ies) if it has been dropped or damaged in any way. If the battery is damaged, contact your distributor for a
replacement.
WARNING: Do not lift the IQ Battery 10C by holding onto the microinverters or the wiring compartment section. This may
damage the unit permanently. Always use handles (SKU: B05C-LH-0180-O) to lift the IQ Battery 10C.
WARNING: Do not lift the packaging with the battery inside after cutting the plastic straps.
2
Remove the top box cover
5
Remove the top paper tray
section 7.4 for handle installation and lifting of the unit.
EN-13
3
Remove the four corner guards
6
Open the polythene bag and take out the
battery unit with the help of handles
