- Page 1 IQ Battery 5P Quick Install Guide M ODE L I QB AT TER Y-5P-1P-R O W V E R SI O N 2. 0 APR I L 2023 To exchange with ROW barcode IQ Battery 5P Quick Install Guide...
- Page 2 To install the Enphase IQ Battery 5P and the wall-mount bracket, read and follow all warnings and instructions in this guide. Safety warnings are listed at the end of this guide. These instructions are not meant to be a complete explanation of how to design and install an energy storage system.
-
Page 3: Table Of Contents
Troubleshooting Step 3: Install the wall-mount bracket Safety Section B Installing IQ Battery 5P Step 1: Prepare to install IQ Battery 5P on mounting bracket Step 2: Prepare for field wiring Section C Wiring Install conduit/raceway adapter and field wiring... -
Page 4: What's In The Box
Q U A N T I T Y IQ Battery 5P B05-T02-ROW00-1-2 ID cover, two conduit covers B05-CX-0550-O Mounting bracket & top shield B05-WB-0543-O M5 Seismic screw M4 Grounding screw M5 ID Cover Grounding screw Quick Install Guide IQ Battery 5P Quick Install Guide... -
Page 5: Tools/Additional Items Required
Provided by Installer (Min. 2) (Min. 5) Washers As required Provided by Installer IQ Battery 5P lifting handles. Includes one left side and one Enphase store/ right side lifting handle (IQBATTERY-HNDL-5) provided by Installer IQ Battery 5P Quick Install Guide... - Page 6 Tools/additional items required NOTE: The Enphase IQ Battery 5P system requires an Internet connection through the IQ Gateway in the IQ System Controller. Failure to maintain an Internet connection may have an impact on the warranty. See enphase.com/warranty for full terms. The IQ Battery 5P and IQ System Controller are all connected to the IQ Gateway and communicate using communication control cables.
-
Page 7: Unboxing Iq Battery 5P
If damaged, contact your distributor for replacement. Risk of injury. Take care when lifting. The IQ Battery 5P unit is heavy (66.25 kg/146.05 lbs) and requires two people to lift it. IQ Battery 5P Quick Install Guide... -
Page 8: Section A
IQ System Controller supports up to a maximum of 80 A breaker for IQ Battery 5P connection circuit. • The maximum conductor size for IQ Battery 5P is 30 mm and the maximum breaker rating with this Max 4 conductor size is 80 A. IQ Battery 5P Quick Install Guide... -
Page 9: Step 1: Minimum Clearance
The mounting instructions that follow are for the included wall-mount If mounted in the path of a motor vehicle, Enphase bracket only. If you wish to install IQ Battery 5P in a floor-mount recommends a minimum mounting height of 91 cm (36 in) configuration, order the pedestal accessory (B05-PM-0550-O) and above the floor. -
Page 10: Step 2: Mounting Surface
NOTE: If the variation of the flatness is more than 2 mm, the battery might not properly sit on the wall-mount bracket through key holes. Use spacers if the variation is more than 2 mm. IQ Battery 5P Quick Install Guide... -
Page 11: Step 3: Install The Wall-Mount Bracket
The key holes are to mount the base unit of IQ Battery 5P to the wall-mount bracket and should not be used to mount the wall-mount bracket to the wall 534 mm (21 in) IQ Battery 5P Quick Install Guide... - Page 12 Ground contact flange Ground contact flange Tightening of wall-mount bracket of top shield direction Mounting on multiple Mounting on single vertical studs vertical stud NOTE: Ensure to always fasten the screw in the encircled hole. IQ Battery 5P Quick Install Guide...
-
Page 13: Section B
Position the Handle Tube bolt concentric to the keyhole slots in the backplate and insert the handle Handle Tube bolt Handle Tube bolt Left handle Right handle Handle Tube bolt IQ Battery 5P Quick Install Guide... - Page 14 1/2 in (13 mm) to 1-1/4 in (32 mm). Follow manufacturer recommended instructions for conduit installation. * One side conduit configuration is supported only if system has one IQ Battery 5P or for the unit last in the daisy chain farthest from the IQ System Controller. IQ Battery 5P Quick Install Guide...
- Page 15 Section B - Installing IQ Battery 5P Open the front wiring cover by unfastening the 11 captive screws (torque to 1.5 N m) from the wiring cover. Use electric drive; do not use impact drives/impact drills. IQ Battery 5P Quick Install Guide...
- Page 16 10 mm2. Drill to appropriate cut-out Ensure that drilling machine do not touch any internal components or wall. Ensure to clean the debris from inside the battery unit after drilling. IQ Battery 5P Quick Install Guide...
- Page 17 Slide the 3. Pull the handle 3. Pull handle Pull the handle Pull the handle away down away from the from the unit to remove it unit to remove it IQ Battery 5P Quick Install Guide...
- Page 18 The vent or drain holes provided at 2x Seismic screws 2x Seismic screws the back of the unit serves the dual purpose of natural ventilation and condensation drainage. Blocking these holes can affect the functionality of the product. IQ Battery 5P Quick Install Guide...
-
Page 19: Step 2: Prepare For Field Wiring
Fasten (torque to 1.5 N m) the 11 captive screws at the wiring cover as shown. Use electric drive; do not use impact drives/ impact drills. IQ Battery 5P Quick Install Guide... -
Page 20: Section C
Use a raceway adapter between units only if the distance between units is ≤ 165 mm (6.5 in) and they are at the same level. Raceway adapters can be provided by Enphase (sold separately) and have the following configuration: S PA C I N G B E T W E E N... - Page 21 NOTE: Power and control communication cables will run in parallel through conduits and raceway adapters. To IQ Battery 5P unit From or IQ System Controller IQ System Controller or IQ Battery 5P unit Ground CTRL (shown in different color for distinction) IQ Battery 5P Quick Install Guide...
- Page 22 55mm for LHS wire DRAIN connector while the other DRAIN connector shall remain unconnected within each IQ Battery 5P. Control connector Terminated with resistor for last unit Termination resistor in a daisy chain on control connector IQ Battery 5P Quick Install Guide...
- Page 23 L and N on the terminal blocks of each IQ Battery 5P unit measures 230 VAC (211-264 V). If the voltage is within the range as required by local codes, turn off the AC power supply. IQ Battery 5P Quick Install Guide...
-
Page 24: Section D
WARNING: Do not leave the Control Switch turned ON for more than 24 hours until system functional testing has been successfully completed. Doing so may void warranty. Peel off this sticker before installing the ID cover Battery serial number IQ Battery 5P Quick Install Guide... - Page 25 IQ Battery 5P chassis. Before releasing, pull out the lower edges while sliding in the cover and make sure the tabs are locked to the back plate as shown in the following figure: IQ Battery 5P Quick Install Guide...
- Page 26 After step 4 Fasten cover to the extension backplate using the two M5 Phillips hex head screws (torque to 3.1 N m) 2x (M5x 10), Phillips hex head 2x (M5x 10), Phillips hex head IQ Battery 5P Quick Install Guide...
- Page 27 Do not leave the DC control Switch in ON position without AC power supply available. This will deplete the battery and may lead to a condition where battery cannot be turned ON and cannot be commissioned. IQ Battery 5P Quick Install Guide...
-
Page 28: Disassembly Of Iq Battery 5P Cover
Remove the two M5 Phillips hex head screws (torque to 3.1 N m) which are used to affix the cover to the extension backplate. 2x (M5x 10), Phillips hex head 2x (M5x 10), Phillips hex head IQ Battery 5P Quick Install Guide... - Page 29 Hand access slot Hand access slot Before step 3 After step 3 Before step 2 After step 2 Isometric view Unlock the top plastic cover from the ribs highlighted in yellow. IQ Battery 5P Quick Install Guide...
- Page 30 Pull out the lower portion of the cover (in order to unlock the highlighted angular tabs) and move it away from the wall slightly as per the directions shown the following figure (back view). IQ Battery 5P Quick Install Guide...
- Page 31 Disassembly of IQ Battery 5P cover Make sure the cover reaches the position shown in the front view. Pull the cover off in the indicated direction. IQ Battery 5P Quick Install Guide...
-
Page 32: Configure And Activate
Configure and activate Use the Enphase Installer App to commission the IQ Battery(ies). Once connected to the IQ Gateway Metered, refer to the Enphase Installer App help topics for more information. Peel off following sticker after functional test is complete. WARNING: Do not leave the Control Switch... -
Page 33: Operation
Solid yellow Not operating due to high temperature. See “Troubleshooting” Solid blue or green Idle. Color transitions from blue to green as state of charge increases. Check Enphase Installer Platform for charge status Soft pulse blue Discharging Soft pulse green... - Page 34 Operation Operating mode and set points IQ Battery 5P supports multiple storage interactive system modes based on usage. Using Enphase App, select “Menu” > “Settings” > “Battery Storage”. Select one of three battery modes: • Self-consumption mode (default, no setting change required) •...
-
Page 35: Troubleshooting
Ensure the DC switch is in the OFF position using the following steps: • If the IQ Battery 5P LED is OFF, the DC switch is in OFF position and the IQ Battery 5P is in shutdown mode. • If the IQ Battery 5P LED (any color) is ON, press the DC switch once to turn it OFF and place IQ Battery 5P in shutdown mode. -
Page 36: Safety
Safety IMPORTANT SAFETY INSTRUCTIONS. SAVE THESE INSTRUCTIONS. This guide contains important instructions that you must follow during installation and maintenance of the Enphase IQ Battery(ies). Failing to follow any of these instructions may void the warranty (enphase.com/warranty). Refer to MSDS document and Safety Datasheet at enphase.com/en-au. - Page 37 (enphase.com/warranty). WARNING: Before installing or using the IQ Battery(ies), read all instructions and NOTE: When replacing Enphase IQ Battery(ies), you must replace with an cautionary markings in this guide and on the equipment. IQ Battery(ies) of the same type, with the same AC current rating.
- Page 38 Installer notes IQ Battery 5P Quick Install Guide...
- Page 39 Installer notes IQ Battery 5P Quick Install Guide...
- Page 40 Installer notes IQ Battery 5P Quick Install Guide...
- Page 41 © 2023 Enphase Energy. All rights reserved. Enphase, the e and CC logos, IQ, and certain other marks listed at https:/ /enphase.com/trademark-usage-guidelines are trademarks of Enphase Energy, Inc. in the US and other countries. Data subject to change. IQ Battery 5P Quick Install Guide...
