Packing List

In addition to this guide, the package includes the following items:

MDC-700

Technical Support

service@icpdas.com

www.icpdas.com

 For Desktop Web

RS-232 Cable

(CA-0910)

Resources

How to search for drivers, manuals and

spec information on ICP DAS website.

 For Mobile Web

Model Name

MDC-700 Quick Start

Screw Driver

2.4 mm

v1.3, Sep. 2020

Wire Terminal

x 32

Need help?

Do you have a question about the MDC-700 and is the answer not in the manual?

Page 1 MDC-700 Quick Start v1.3, Sep. 2020 Packing List In addition to this guide, the package includes the following items: MDC-700 Screw Driver Wire Terminal RS-232 Cable 2.4 mm x 32 (CA-0910) Technical Support Resources How to search for drivers, manuals and service@icpdas.com...
Page 2 Connecting to PC, Network and Power 1) Connect the power supply. (+10 ~ +30 VDC). 2) Connect the MDC-700 and PC to the same switch in the LAN Hub/Switch Power supply (+10 ~ +30V Assigning an IP address Before starting this configuration, the MDC-700 needs be connected to your network and powered-on.
Page 3 Confirm that the connection is successful on the page. The connection to the MDC-700 is established The connection to the MDC-700 is not established. iii. Scroll down to Ethernet Configuration section, set a valid IP address for your MDC-700, and click on the Apply button.
Page 4 NOTE: The MDC-700 can be reset to factory defaults by shorting the RESET pin to GND pin over 3 seconds. The LED display will show “RESET” as below and the IP set previously will be removed. Go to the Web Site Go to the web interface at http://xxx.xxx.xxx.xxx, where...
