I-2533CS series
User Manual
Version 1.0.0, Sep. 2013
Service and usage information for
I‐2533CS / I‐2533CS‐60 / I‐2533CS‐A / I‐2533CS‐B
I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0)
Page:
1
Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com
Advertisement
Table of Contents
Related Manuals for ICP DAS USA I-2533CS Series
Summary of Contents for ICP DAS USA I-2533CS Series
- Page 1 I-2533CS series User Manual Version 1.0.0, Sep. 2013 Service and usage information for I‐2533CS / I‐2533CS‐60 / I‐2533CS‐A / I‐2533CS‐B I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 1 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...
- Page 2 If you have any problem, please feel free to contact us. You can count on us for quick response. Email: service@icpdas.com I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 2 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...
-
Page 3: Table Of Contents
4.2.2.3. Read the I-2533CS CAN Filter Configuration......33 Firmware Upgrade ..................34 Dimension...................... 37 I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 3 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com... -
Page 4: Introduction
In order to solve the problem between CAN and fiber transmission medium, The I-2533CS series is specially designed for converting the electrical CAN bus signal to fiber optic cables. Besides, I-2533CS series has three more important features. - Page 5 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 5 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...
-
Page 6: Specifications
Screwed terminal block (RXD, TXD, GND) Round LED PWR, FB_Ack, FB_Err, CAN_Err, CAN_Tx and CAN_Rx LEDs Power I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 6 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com... - Page 7 The I-2533CS-A and I-2533CS-B is a couple. Users must use pair in the applications. Due to this characteristic, the Group ID of the I-2533CS-A and I-2533CS-B is useless. I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 7 ...
-
Page 8: Features
Allows user-defined CAN baud rate Fiber broken line detection Utility tool for CAN message filter configuration The CAN port with the same Group ID can communicate with each other I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 8 ... -
Page 9: Technical Data
The following figure is the block diagram illustrating the functions of the I-2533CS series. Figure 2-1 Block Diagram of I-2533CS series I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 9 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com... -
Page 10: Appearance
2.2. Appearance Figure 2-2 Appearance of I-2533CS and I-2533CS-60 Figure 2-3 Appearance of I-2533CS-A and I-2533CS-B I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 10 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com... -
Page 11: Pin Assignment
Wiring of CAN_GND and F.G. is not necessary; users can modify the configuration of wiring according to real applications. I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 11 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com... -
Page 12: Rotary Switch
When users would like to update the module’s firmware or set the CAN baud rate, message filter of the I-2533CS series, use the rotary switch on the upper of the power connector to achieve this purpose. Users can find it on the top of the power connector. -
Page 13: Led Indicator
+7(495)109-02-08 sales@bbrc.ru www.bbrc.ru 2.5. LED Indicator There are 6 LEDs on the I-2533CS series. One for power indication, two for fiber indication and three for CAN bus indication. The LED assignment and description are shown as follows. Figure 2-5 LED Assignment of I-2533CS... -
Page 14: Terminator Resistor Setup
The DIP switch for terminator resistor is under the power connector. Figure 2-7 Location of Terminator Resistor DIP Switch I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 14 ... - Page 15 Figure 2-9 Application 1 If your application is like the structure as follows, the terminator resistor is not needed. Figure 2-10 Application 1 I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 15 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...
-
Page 16: Module Group Id
2.7. Module Group ID The CAN port with the same “Group ID” setting can communicate with each other via fiber optics. This setting is used for I-2533CS series to communicate with the others modules on star topology application. ... - Page 17 Note: The I-2533CS-A and I-2533CS-B don’t support the Group function. When using the I-2533CS-A and I-2533CS-B, the Group ID of them must be the same. I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 17 ...
-
Page 18: Wire Connection
Figure 2-12 Wire Connection for I-2533CS and I-2533CS-60 Figure 2-13 Wire Connection for I-2533CS-A and I-2533CS-B I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 18 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com... -
Page 19: Network Deployment
< 410 ~1.3 (AWG16) < 980 < 900 < 780 < 670 I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 19 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com... -
Page 20: Fiber Selection & Fiber Length
ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru 3.2. Fiber Selection & Fiber Length The specification of fiber cable used to connect the I-2533CS series is shown as following table. Table 3-3 Specification of Fiber Diameter [μm]... -
Page 21: Setup The I-2533Cs Series
Step 2: Install .NET Framework 4 component The I-2533CS Utility tool requires the .NET Framework 4 components. After executing the “Setup.exe” file, it will start to install .NET Framework 4 components. I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 21 ... - Page 22 After installing the .Net Framework components, the software will continue to install the Utility tool. 1. Click the “Next” button to continue. 2. Select the installation path of the I-2533CS Utility and click the “Next” button. I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 22 ...
- Page 23 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru 3. Confirm the installation. Click the “Next” button to start the installation 4. Installation complete. Click the “Close” button to exit I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 23 ...
-
Page 24: Setting Up The I-2533Cs Series
+7(495)109-02-08 sales@bbrc.ru www.bbrc.ru 4.2. Setting up the I-2533CS series After installing the utility tool, please follow the following steps to set up the communication between the Utility and the I-2533CS series. Here is the example for the I-2533CS configuration. ... -
Page 25: User-Defined Can Baud Rate Configuration
+7(495)109-02-08 sales@bbrc.ru www.bbrc.ru 4.2.1. User-defined CAN Baud Rate Configuration The I-2533CS series allows users to set the special CAN baud rate by using the “User-defined CAN Baud Rate” field of the Utility. Figure 4-2 Set and read the CAN filter configuration ... -
Page 26: Can Filter Configuration
Set and read the CAN filter configuration Figure 4-4 CAN filter configuration dialog I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 26 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com... -
Page 27: Configure A Can Filter To The I-2533Cs
Then users would see the following window pop-up. Figure 4-6 CAN filter configuration dialog I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 27 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com... - Page 28 “CAN x Group CAN ID” field. Secondly, fill the value “4” in the “Start” field and the value “15” in the “End” field. Finally, click “Add” button in the “CAN x Group CAN ID” field. I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 28 ...
- Page 29 : This record is the CAN filter of 29-bit and single CAN ID. : This record is the CAN filter of 29-bit and group CAN ID. I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 29 ...
- Page 30 4. “Save to File” button provides the function to save the current CAN filter configuration into a file (*.FLT). 5. “OK” button would exit the configuration dialog. I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 30 ...
- Page 31 If users want to review the configuration, click “Read From Module” button to read back the information. I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 31 ...
-
Page 32: Download Existent Can Filter File To The I-2533Cs
configuration, click “Read From Module” button to read back the information. I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 32 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com... -
Page 33: Read The I-2533Cs Can Filter Configuration
“Create CAN Filter File”. Users can modify the CAN filter setting if necessary, or save it into a file. Figure 4-15 CAN filter id setting I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 33 ... -
Page 34: Firmware Upgrade
The software is located at: Fieldbus_CD:\CAN\Converter\I-2533CS\Software\Tool The firmware is located at: Fieldbus_CD:\CAN\Converter\I-2533CS\Firmware\ http://www.icpdas.com/products/Remote_IO/can_bus/i-2533cs.htm I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 34 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com... - Page 35 ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru Step 5: Execute the “Firmware Update Tool”. Step 6: Select the necessary COM port of PC. I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 35 ...
- Page 36 “Firmware Update Success! Please Reboot Module!” information will be display on the “3. Firmware Update” frame. Step 9: Reboot the module and press the “Exit” button to exit. I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 36 ...
-
Page 37: Dimension
ГК Атлант Инжиниринг – официальный представитель в РФ и СНГ +7(495)109-02-08 sales@bbrc.ru www.bbrc.ru 6. Dimension I-2533CS series CAN to Single Mode Fiber Bridge User Manual (version 1.0.0) Page: 37 Copyright © 2013 ICP DAS Co., Ltd. All Rights Reserved. E-mail: service@icpdas.com...
