Setting Fixed Sample Points

Setting Fixed Sample Points
You are able to set up to five fixed Sample points so that you can monitor
the effects that your settings are having in key areas around your image.
Each sample point is indicated with a diamond and a number in the
preview image. The current values for each sample point are shown next
to the appropriate number in the Color Info window.
You can work with the sample points as follows:
•
To move an existing sample point, activate the sample point picker by
clicking on the Sample Point button to make it grey, then click and
drag on the target point.
•
To delete an existing sample point, activate the sample point picker,
click once on the target point and then press the backspace button on
your keyboard.
•
To keep the existing sample points, but hide them in the preview, mark
the Hide points check box. To view and/or edit the points again,
remove the mark from this check box.
•
To remove all sample points from your preview click Remove all.
To set a sample point, click on the Sample Point button,
which will turn grey when it is activated. Then click on a
point in your image to place the point. A numbered
diamond will then appear on the preview image at the point
you select.
