Bathroom Cabinet
Version:05/24/2023
1/16

Advertisement

loading
Need help?

Need help?

Do you have a question about the Bathroom Cabinet and is the answer not in the manual?

Questions and answers

Related Manuals for FUFU & GAGA Bathroom Cabinet

Summary of Contents for FUFU & GAGA Bathroom Cabinet

  • Page 1 Bathroom Cabinet Version:05/24/2023 1/16...
  • Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
  • Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size A x 40 B x 12 C x 5 D x 18 E x 31 M5 x 40 mm 8 x 30 mm M3.5 x 12 mm...
  • Page 4 2PCS 4PCS 4PCS 4PCS 4PCS 4PCS 4/16...
  • Page 5 ALWAYS install tipover restraint provided. NEVER put a TV on this product. NEVER allow children to stand,climb or hang on drawers,doors,or shelves. NEVER open more than one drawer at a time. Place heaviest items in the lowest drawers. This is a permanent label. Do not remove! 5/16...
  • Page 6 G x 8 M6 x 35 mm Insert quickfit screw(G) into corresponding holes in plate #3/#2 with a screwdriver as shown. A x 8 G x 8 CL x 2 CR x 2 M3.5 x 12 mm M6 x 35 mm Insert quickfit screw(G) into corresponding holes in plate #4/#7 with a screwdriver as shown.
  • Page 7 A x 8 G x 4 CL x 2 CR x 2 M3.5 x 12 mm M6 x 35 mm Insert quickfit screw(G) into corresponding holes in plate #5/#6 with a screwdriver as shown. Using screw(A) to lock the slide (CR/CL) to the plate #5/#6 as shown. D x 8 E x 2 H x 4...
  • Page 8 E x 10 H x 8 8 x 30 mm 15 x 12 mm 180° Connect plate #1/#3/#9/#17 to plate #7/#4 using wooden dowel(E),insert cam lock(H) into plate #1/#3/#9 and turn clockwise to tighten as shown. E x 8 H x 6 8 x 30 mm 15 x 12 mm 180°...
  • Page 9 D x 10 E x 11 M5 x 40 mm 8 x 30 mm Fix plate #8 to plate #1/#4/#5/#6/#7 using wooden dowel(E) and screw (D) as shown. 9/16...
  • Page 10 C x 5 L x 15 M4 x 14 mm Fix foot(C) to plate #8 using screw(L) as shown. B x 12 F x 4 K x 2 L x 24 M4 x 14 mm M4 x 14 mm Fix part(K) to plate #17/#4/#7 with screw(B),fix the hinge (F) to plate #15/#16 and plate #5/#6 with screw(L) as shown.
  • Page 11 Adjust door following the direction. Adjust the door up and down to match the cabinet. II:Adjust the upper II:tighten the screw. I:loosen the screw. and lower position. When the door position is not Adjust the door left and right to match the cabinet for suitable crack of the door standard,please adjust the door according to the right picture.
  • Page 12 G x 16 I x 16 M6 x 35 mm M4 x 35 mm Insert quickfit screw(G)into corresponding holes in plate #13 with a screwdriver as shown. Connect plate #10/#14 to plate #11 using screw(I),slide plate #12 into available slots as shown.
  • Page 13 Put the drawer to the cabinet as shown. 13/16...
  • Page 14 Drill a hole on your wall as shown. N x 2 8 x 40 mm Knock part(N) into the hole. 14/16...
  • Page 15 J x 2 M x 2 20 mm M6 x 60 mm Fix the item to part(N) with washer(J) and screw(M) as shown. 15/16...
  • Page 16 Glue the cabinet and put the basin on the cabinet. 16/16...

  • Page 17: Warranty Claims

    WARRANTY WARRANTY CLAIMS •There is a 30-day warranty for broken furniture or any other problems that do not work properly. The warranty will start from the date of purchase which must be verified by proof of purchase. •Before making a claim, we may be able to answer your query, simply call us. Please leave your purchase order number, along with some details of the problem, if you want a replacement part.
  • Page 18 RETURNS CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM? PLEASE FOLLOW THE BELOW INSTRUCTIONS: •If you have purchased and have simply changed your mind, follow the retailer’s instructions for returns. DEFECTIVE ITEMS •If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance, please call us.
