- Page 1 Shoe cabinet 1/17 Version:09/13/2022...
- Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
- Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size Ax16(+1) Bx16(+1) Cx26(+2) Dx12(+1) Ø15x10mm Ø6x30mm Ø4x35mm Ø6x35mm Hx54(+5) G-1 G-2 G-3 Ø3.5x12mm Ø6x12mm (+1) Jx16 Ø4x12mm...
- Page 4 (+1) Sx12 Ø5x10mm Ø6x30mm 4/17...
- Page 5 5/17...
- Page 6 Ø6x35mm Insert quickfit screw(A) into corresponding holes in plate 5 and 6 as shown. Use a hammer to knock part(G-1,G-2) into plate 5 and 6 as shown. 6/17...
- Page 7 Ø15x10mm Ø6x30mm Attach plate 2, 3 and 4 to plate 5 with wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. Ø15x10mm Ø6x30mm Attach plate 6 to plate 2, 3 and 4 with wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown.
- Page 8 Ø6x30mm Ø4x35mm Connect plate 6 with plate 8 using wooden dowel (C) and fix with screw(D) as shown. Ax10 Ø6x35mm Insert quickfit screw(A) into corresponding holes in plate 1 and 9 as shown. 8/17...
- Page 9 Ø6x30mm Ø15x10mm Connect plate 9 to plate 8 with wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. Ø4x35mm Ø6x30mm Attach plate 7 to the bottom of the unit with wooden dowel(C) and fix with screw(D) as shown. 9/17...
- Page 10 Ø6x12mm Fix leg 10 to plate 7 with screw(F). Rotate leg support 18 into plate 7 as shown. Ø15x10mm Ø6x30mm Cover plate 1 to the top with wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. 10/17...
- Page 11 Jx16 Sx12 Ø3x12mm Ø4x12mm Ø5x10mm Fix back plate 14, 16 and 17 using screw(J) and nail(S) as shown. Please note plate 14,16 and 17 connect with plank 15. Fix part(K) to the back using washer(Q) and screw(L) as shown. Ø6x14mm Insert part(O) into plate 6 and 9, and put plate 20 in.
- Page 12 Ø4x16mm Ø3.5x12mm Fix hinge(N) to plate 19 with screw(H) as shown. Fix handle(M) to plate 19 with screw(P) as shown. Hx12 Ø3.5x12mm Attach plate 19 to plate 9 by fixing hinge with screw(H). 12/17...
- Page 13 Hx24 Ø3.5x12mm Fix plastic part(E) to plate 13 and 11 with screw(H) as shown. 13/17...
- Page 14 Ø3.5x12mm Ø4x16mm Fix plate 12 with plastic part with screw(H) as shown. Fix handle(M) to plate 11 with screw(P) as shown. 14/17...
- Page 15 Ø3.5x14mm Fix these drawers to sides of unit by fixing plastic part using part(G) and screw(I) as shown. Inser plate 12 as shown. 15/17...
- Page 16 Ø3.5x12mm Fix plate 12 with plastic part using screw(H) as shown. 16/17...
- Page 17 Ø4x35mm Ø6x30mm WALL WALL WALL drilling hole Ø6x30mm Install anti-tipping device as shown. WALL 17/17...
