- Page 1 Shoe Cabinet ersion:05/27/2022 1/11...
- Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
- Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size A x 4 B x 17 C1 x 6 C2 x 6 6 x 30 mm 4 x 40 mm C3 x 6 D x 36...
- Page 4 4/11...
- Page 5 D x 24 F x 6 G x 3 L x 3 R x 3 3.5 x 14 mm 4 x 20 mm Fix plastic part L&R to panel 8 using screw as shown. Attach this part to panel 6 using screw(D) to corresponding holes as shown. Fix handle(G) to panel 6 using screw(F).
- Page 6 C1 x 6 C2 x 6 Knock part(C1,C2) slightly into the holes in panel 2&3 as shown. A x 2 B x 8 J1 x 1 J2 x 1 6 x 30 mm 4 x 40 mm 4 x 12 mm Fix part(J1) to panel 1 using screw(J2).
- Page 7 A x 2 B x 8 6 x 30 mm 4 x 40 mm Attach panel 2 to assembled part in step 4, using screw B) and wooden dowel(A) as shown. H x 4 I x 10 1.5 mm 2.5 x 14 mm Fix panel 4 to the back of assembled unit using screw(I) as shown.
- Page 8 B x 1 J3 x 1 4 x 40 mm 6 x 30 mm Install anti-tipping device with part(J3) and screw(B) as shown. wall WALL WALL 8/11...
- Page 9 C3 x 6 E x 6 4 x 10 mm Fix the plastic part(L&R) to panel 2& 3 by using (C3) slightly. Then screw(E) to tighten as shown. 3.5 x 14 mm 4 x 10 mm wall 9/11...
- Page 10 Insert panel 7 to the middle of drawers wall 10/11...
- Page 11 D x 6 3.5 x 14 mm Using screw D) to fix panel 7 to both side plastic part as shown. 3.5 x 14 mm 4 x 10 mm wall 11/11...
