- Page 1 TV Cabinet Plan (1) Plan (2) Version:09/23/2022...
- Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
- Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size Ax16(+1) Bx16(+1) Cx24(+1) Dx10(+1) Ø 15x10mm Ø 6x30mm Ø 4x35mm Ø 6x35mm Ex10(+1) Hx20(+1) Ø...
- Page 4 Ø 3x12mm Ø 6x30mm Ø 4x14mm 4/28...
- Page 5 5/28...
- Page 6 Separat part(F) into 3 parts as shown. F1x2 Ø3.5x10mm Fix part(F1) to No.2 and No.5 with screw(E) as shown. 6/28...
- Page 7 Ø6x35mm Insert quickfit screw(A) into No.2 and No.3 plate with a screwdriver as shown. Ø15x10mm Ø6x30mm Connect No.6 with No.2 plate using wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. 180° 7/28...
- Page 8 Ø15x10mm Ø6x30mm Connect No.3 plate with No.6 using wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. 180° Ø6x35mm Insert quickfit screw(A) into No.4 and No.5 plate with a screwdriver as shown. 8/28...
- Page 9 Ø15x10mm Ø6x30mm Connect No.6 with No.5 plate using wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. 180° Ø15x10mm Ø6x30mm Connect No.4 with No.6 using wooden dowel(C) and turn cam lock(B) clockwise to tighten as shown. 180° 9/28...
- Page 10 Ø6x30mm Insert wooden tenon(C) into No.2, No.3, No.4 and No.5 plate as shown. Ø6x35mm Insert quickfit screw(A) into corresponding holes in No.1 plate with a screwdriver as shown. 10/28...
- Page 11 Ø15x10mm Attach the two components to No.1 plate, turn cam lock(B) clockwise to tighten as shown. 180° 90° 11/28...
- Page 12 Please combine two No.9 plate with No.10; two No.11 plate with No.12 at first. Slide the back plate into available slots as shown. 12/28...
- Page 13 Ø6x30mm Ø4x35mm Cover No.8 plate to the component using wooden dowel(C) and fix with screw(D) as shown. 13/28...
- Page 14 Hx20 Ø3x16mm Fix iron sheet(G) to No.8 plate with screw(H) as shown. 14/28...
- Page 15 Rotate No.14 legs into the iron sheet part. Rotate No.13 leg support into No.8 plate as shown. 15/28...
- Page 16 Rotate part(M) into No.13 leg support as shown. Cover foot peg(Y) to No.14 leg. 16/28...
- Page 17 Qx12 Px12 Ø4x14mm Ø3x16mm Reinforce back plates using part(P) and screw(Q) as shown. Fix part(V) to No.2 and No.5 plate with screw(W) as shown. 17/28...
- Page 18 If the item is unstable or the bottom plate sinks.Please adjust part(M) at the bottom of No.13 leg support. 18/28...
- Page 19 F2x2 Ø3.5x10mm Ø3.5x10mm Ø3x12mm Fix hinge(J) to No.16 and No.17 plate respectively with screw(K) as shown. Fix part(F2) to No.16 and No.17 plate respectively with screw(E) as shown. Fix handle(S) to No.16 and No.17 plate respectively with screw(R) as shown. 19/28...
- Page 20 F3x2 Kx16 Ø3x12mm Attach No.16 door plate to left, No.17 to right by fixing hinge with screw(K) as shown. Combine all parts of accessory(F) ,as shown. 20/28...
- Page 21 If the TV table door panel tilts or sinks, please adjust part(F3). 21/28...
- Page 22 This TV cabinet can be used in two ways. Plan 1 is to add a removable plate that would be used only as a TV cabinet (steps are in step 23). Plan 2 is to install a matching fireplace, which can be used as a mantelpiece (steps 24 to 27).
- Page 23 Insert part(L) into the opposite positions of No.3 and No.4 plate.Place the No.7 plate in, as shown. Plan (1) 23/28...
- Page 24 Ø3x12mm Please make sure you have bought a matching fireplace. Remove the shell of the fireplace. Connect No.15 plate with the fireplace using screw(R). Step 1 fireplace shell Step 2 Plan (2) 24/28...
- Page 25 Connect the data cable connector before hanging the glass frame on the appliance. Gently push on the glass panel by aligning the 4 hooks until it snaps into position (sinks down 1-2 cm). Thread the matching screw into the threaded holes on the glass panel. Check the alignment of the glass paneland securely tighten the screws.
- Page 26 Push the fireplace vertically into the TV cabinet, as shown. Be careful to insert the fireplace plug through the round hole in No.11 plate. fireplace Behind Plan (2) 26/28...
- Page 27 Ø4x35mm Please use screw N to secure the fireplace to panels 3 and 4, as shown. Plan (2) 27/28...
- Page 28 Ø4x35mm Ø6x30mm For extra stability, it is WALL WALL WALL recommended that you drilling hole attach the TV cabinet to the 6x30mm wall . Additional hardware (D, ,U,V ), as shown. Should you choose not to affix the product to the wall,serious injury may be caused.if the product tips over.
