FUFU & GAGA Shoe Storage Cabinet Manual
Hide thumbs Also See for Shoe Storage Cabinet:

Advertisement

Quick Links

Shoe Storage Cabinet
Version:12/15/2022
1/21

Advertisement

loading
Need help?

Need help?

Do you have a question about the Shoe Storage Cabinet and is the answer not in the manual?

Questions and answers

Summary of Contents for FUFU & GAGA Shoe Storage Cabinet

  • Page 1 Shoe Storage Cabinet Version:12/15/2022 1/21...
  • Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
  • Page 3: Table Of Contents

    Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size A x 36 C x 8 F x 8 G x 5 B x 36 3.5 x 30 mm 6 x 28 mm 15 x 9.5 mm...
  • Page 4 4/21...
  • Page 5 STEP1: Extend Slide Extender la diapositiva Extendre la diapositive STEP2: Push lever UP Empujar hacia arriba Lever le levier STEP3: Remove Runner Quitar el corredor Enlever le coureur 5/21...
  • Page 6: A X 20

    A x 20 O x 6 P x 6 J1 x 1 H x 4 6 x 28 mm 3 x 14 mm Knock part(P) and (O) into corresponding holes in plate 1 and 2 as shown. Screw quickfit screw(A) into corresponding holes in plate 1 and 2 with a screwdriver as shown.
  • Page 7: B X 2

    A x 2 B x 2 J1 x 1 H x 4 6 x 28 mm 3 x 14 mm Screw quickfit screw(A) into plate 4 as shown. Attach plate 5 to plate 4, put cam lock(B) into holes in plate 5 and turn clockwise to tighten at first.
  • Page 8 B x 20 C x 4 15 x 9.5 mm 8 x 40 mm Slide plate 8 along grooves in plate 4,8 and 9 at first. Insert wooden dowel(C) into plate 4 as shown. Connect plate 1 and 2 with plate 4,8,9 and 10, put cam lock(B) into holes in plate 4,8,9,10 and turn clockwise to tighten at first.
  • Page 9 A x 6 B x 6 C x 4 6 x 28 mm 15 x 9.5 mm 8 x 40 mm Screw quickfit screw(A) into corresponding holes in plate 3 as shown. Cover plate 3 to the top with wooden dow- el(C), put cam lock(B) into holes in plate 1,4,2 and turn clockwise to tighten as shown.
  • Page 10: I X 16

    I x 16 H x 16 R x 2 T x 2 3.5 x 14 mm 3.5 x 20 mm Reinforce back plate using part(I) and screw(H) as shown. Fix part(R) to plate 1 and 2 respectively using screw(T) as shown. 10/21...
  • Page 11 F x 8 3.5 x 30 mm Fix plate 16 and 17 to plate 19 using screw(F) as show. Slide plate 18 along grooves as shown. 11/21...
  • Page 12 A x 8 6 x 28 mm Screw quickfit screw(A) into plate 14 and 15 as shown. 12/21...
  • Page 13 B x 8 G x 2 15 x 9.5 mm Attach plate 14 and 15 respectively to the component, put cam lock(B) into holes in plate 16,17 and turn clockwise to tighten as shown. Fix handle(G1) to plate 14 and 15 using screw(G2) as shown.
  • Page 14: 200 Mm

    J2 x 2 H x 8 200 mm 3.5 x 14 mm Fix runner(J2) to drawer side using screw(H) as shown. 14/21...
  • Page 15: L X 3

    G x 3 U x 18 L x 3 M x 3 3.5 x 12 mm Fix plastic hinge(L) and (M) to plate 13 using screw(U) as shown. Fix handle(G1) to plate 13 using screw(G2) as shown. 15/21...
  • Page 16 H x 6 3.5 x 14 mm Fix plate 11 to plastic hinge(L) and (M) using screw(H) as shown. 16/21...
  • Page 17 H x 6 3.5 x 14 mm Fix plate 12 to plastic hinge(L) and (M) using screw(H) as shown. 17/21...
  • Page 18 N x 6 K x 6 Assemble the drawers to plate 1 and 2, knock part(N) into the holes in plastic hinges, and fix using screw(K) as shown. 18/21...
  • Page 19 Place plate 12 in. 19/21...
  • Page 20 H x 6 3.5 x 14 mm Fix plate 12 to plastic hinge(L) and (M) using screw(H) as shown. 20/21...
  • Page 21: Q X 2

    Q x 2 S x 2 Install anti-tipping device as shown. 8 50 21/21...
