Page 2
IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
Page 3
Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size Ax15 Bx15 Cx22 Dx12 Ø6x30mm Ø4x40mm Ø6x35mm Ø15x10mm Hx36 Ø3.5x14mm Jx28 Ø4x10mm Ø4x14mm Px12 Ø4x14mm Ø3.5x14mm Ø6x30mm Ø4x40mm...
Page 5
Ø6x35mm Tighten Cam Bolt (A) to panel 2 and panel 4 ,as shown. Please hammer the G-1 and G-2 onto the 2 and 3 boards ,as shown. 5/28...
Page 6
Ø15x10mm Ø6x30mm Please turn No. 2 board and No. 4 board behind, INSERT SAWDUST C into No. 5 board, No. 6 board and No. 7 board respectively, then Lock with Cam Lock B with No. 2 board and No. 4 board respectively,as shown.
Page 7
Jx20 Ø4x14mm Ø6x35mm (1)Tighten Cam Bolt (A) to panel 1,as shown. (2)Please use screw (J) to lock with Iron Sheet (F) and plate No. 8 respectively,as shown. 7/28...
Page 8
Ø6x30mm Ø4x40mm Insert wooden pins (C) at the bottom of plate 2 and Plate 4 Plate 7 Use Screws (D) to lock plate No. 8 with plate No. 2 and Plate No. 3 Plate No. 4 Plate 7,as shown. Back Back Back 8/28...
Page 9
Please turn the number 14 pin to the plate (F) screw lock respectively . Please rotate number 15 pin to number 8 board. Please use adjustment pad (Q) to rotate number 15 pin,as shown. 9/28...
Page 10
Ø6x30mm Wood pins (C) are inserted in the upper parts of Plate 2 Plate 3 Plate 4 and Plate 5,as shown. 10/28...
Page 11
Insert number 9 number10 number 11 and number 12 back plate into the back plate slot of number 2 left side plate and 4 right side plate,as shown. 11/28...
Page 12
Ø15x10mm Lock Panel 1 with Panel 2 Panel 3 Panel 5 and Panel 4 with Cam Lock(B), as shown. 180° 12/28...
Page 13
Ø4x40mm Please rotate the cabinet body to the back and use screws (D) to lock the No. 5, No. 6 and No. 7 plates with No. 3 plates respectively,as shown. 13/28...
Page 14
Ø4x14mm Please use screw (J) to lock back plate No. 9, No. 10,No.11,No.12 and No. 6 respectively,as shown. 14/28...
Page 15
Please insert the movable tray (R) into the corresponding holes of No. 3 board and No. 4 Board respectively, and place No. 16 board on the movable tray (R),as shown. Please fasten the hardware hinge (O) to plate No. 17 with a screw (P) ,as shown. Please fasten the screw (L) through the 17 plate and the handle (k),as shown.
Page 16
Ø3.5x14mm Please fasten plate 17 with plate 4 with a screw (P) ,as shown. 16/28...
Page 17
Hx16 Ø3.5x14mm (1)Please fasten the E-1, E-2 and No. 18 plates with screws (H) respectively,as shown. (2)Please fasten the E-1, E-2 and No. 20 plates with screws (H) respectively,as shown. 17/28...
Page 18
Ø3.5x14mm (1)Please fasten the E-1, E-2 and No. 19 plates with screws (H) respectively as shown. (2)Please fasten the screw (L) through the 18 plate and the handle (k), as shown. 18/28...
Page 19
Ø3.5x14mm (1)Please fasten the E-1, E-2 and No. 21 plates with screws (H) respectively as shown. (2)Please fasten the E-1, E-2 and No. 20 plates with screws (H) respectively, as shown. 19/28...
Page 20
Ø3.5x14mm (1)Please fasten the E-1, E-2 and No. 19 plates with screws (H) respectively as shown. (2)Please fasten the screw (L) through the 21 plate and the handle (k),as shown. 20/28...
Page 21
Ø4x10mm Please use screw (I) to lock (G-3) through plate E-1 and No. 2 and plate E-2 and No. 3 respectively as shown. Note:Please note that the front panel of drawer No. 18 is different from No. 21! Plate 21 drawer down, plate 18drawer in the middle 21/28...
Page 22
Please insert panel 19 into the cabinet as shown. 22/28...
Page 23
Please use screw H to lock the E-1 and E-2 with plate 19 respectively as shown. 23/28...
Page 24
Ø4x40mm Ø6x30mm Ø4x14mm Please users according to the actual needs,to choose a Option or Option Anti-pour, choose one of the options to install,as shown. Option Option Please use a pen to locate the Please use the screw (M-2) to pass pour-proof position on the wall, through the cloth strip (M-1) and guide the hole position with an...
Page 25
Ø4x10mm Option Option Please use screw (I) to lock (G-3) Please use screw (I) to lock (G-3) through plate E-1 and No. 2 and through plate E-1 and No. 2 and plate E-2 and No. 3 respectively, plate E-2 and No. 3 respectively, as shown.
Page 26
Option Option Please insert panel 19 into the Please insert panel 19 into the cabinet ,as shown. cabinet ,as shown. WALL 26/28...
Page 27
Ø3.5x14mm Option Option Please use screw H to lock the E-1 Please use screw H to lock the E-1 and E-2 with plate 19 respectively , and E-2 with plate 19 respectively , as shown. as shown. WALL 27/28...
Page 28
Ø6x30mm Ø4x40mm Option Option Please use the pen to locate the anti-toppling position on the wall,use the impact rotation guide hole position, then use the hammer to hit (N-1) the wall, use the screw (N-2) to pass through the cloth to lock with the wall,as shown.
WARRANTY WARRANTY CLAIMS •There is a 30-day warranty for broken furniture or any other problems that do not work properly. The warranty will start from the date of purchase which must be verified by proof of purchase. •Before making a claim, we may be able to answer your query, simply call us. Please leave your purchase order number, along with some details of the problem, if you want a replacement part.
Page 30
RETURNS CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM? PLEASE FOLLOW THE BELOW INSTRUCTIONS: •If you have purchased and have simply changed your mind, follow the retailer’s instructions for returns. DEFECTIVE ITEMS •If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance, please call us.
