- Page 1 Food cabinet Version:10/25/2022 1/63...
- Page 2 2/63...
- Page 3 A x 64+1 Bx 79+1 Cx 79+1 D x 104+1 E x 26 3 x 12 mm 6 x 35 mm 15 x 10 mm 5 x 40 mm G x 7 F x 9 K x 1 H x 2 J x 1 4 x 16 mm L x 1...
- Page 4 Z X 10 X X 1 Y X 1 CL X 2 W X 1 26 mm DL X 2 DR X 2 CR X 2 4/63...
- Page 5 5/63...
- Page 6 6/63...
- Page 7 7/63...
- Page 8 8/63...
- Page 9 9/63...
- Page 10 B x 8 M x 1 Q x 1 6 x 35 mm 4 x 12 mm Insert quickfit screw(B) into correcponding holes in plate #1 with a screwdriver as shown. Fix part(M) with screw(Q) as shown. 10/63...
- Page 11 B x 3 6x35mm Insert quickfit screw(B) into correcponding holes in plate #2 with a screwdriver as shown. 11/63...
- Page 12 C x 3 15x10mm Attach plate #2 to plate #3, and then turn cam lock(C) in plate #3 clockwise to tighten as shown. 12/63...
- Page 13 B x 4 6x35mm Insert quickfit screw(B) into correcponding holes in two sides of plate #4 with a screwdriver as shown. 13/63...
- Page 14 B x 4 6x35mm Insert quickfit screw(B) into correcponding holes in two sides of plate #6 with a screwdriver as shown. 14/63...
- Page 15 A x 4 C x 4 15x10mm Connect plate #4 and #6 with plate #5 using wooden dowel(A), and then turn cam lock(C) in plate #5 clockwise to tighten as shown. 15/63...
- Page 16 A x 4 C x 4 15x10mm Attach plate #7(x2) to plate #4 and #6 with wooden dowel(A) and then turn cam lock(C) in plate #7 clockwise to tighten as shown. 16/63...
- Page 17 E x 4 L x 1 A x 4 5 x 40 mm Attach plate #3 to plate #4 and #6 with wooden dowel(A) and then fix with screw(E) as shown. 17/63...
- Page 18 B x 4 6x35mm Insert quickfit screw(B) into correcponding holes in plate #9 with a screwdriver as shown. 18/63...
- Page 19 B x 4 6x35mm Insert quickfit screw(B) into correcponding holes in plate #10 with a screwdriver as shown. 19/63...
- Page 20 A x 6 C x 4 15x10mm Attach plate #9 to left of plate #3 and #7 with wooden dowel(A) and then turn cam lock(C) in plate #3,#7 clockwise to tighten as shown. 20/63...
- Page 21 A x 6 C x 4 15x10mm Attach plate #10 to right of plate #3 and #7 with wooden dowel(A) and then turn cam lock(C) in plate #3,#7 clockwise to tighten as shown. 21/63...
- Page 22 D x 8 3x12mm Fix rack #12 to plate #3 using screw(D) as shown. 22/63...
- Page 23 Slide plate #11 into available slots as shown. 23/63...
- Page 24 B x 8 S x 2 K x 1 6x35mm 3x14mm Insert quickfit screw(B) into correcponding holes in plate #13 with a screwdriver as shown. Fix part(K) with screw(S) as shown. 24/63...
- Page 25 E x 4 A x 4 5 x 40 mm Cover plate #13 to plate #9 and #10 using wooden dowel(A), and then fix with screw(E) as shown. 25/63...
- Page 26 Slide plate #14 and #15 into available slots as shown. 26/63...
- Page 27 A x 8 C x 8 15x10mm Cover plate #1 to the top of the component using wooden dowel(A), then turn cam lock(C) in plate #9,#4,#6,#10 clockwise to tighten as shown. 27/63...
- Page 28 B x 3 D x 2 CL x 1 6x35mm 3x12mm Insert quickfit screw(B) into correcponding holes in plate #17 as shown. Fix slide rail(CL) with screw(D) as shown. 28/63...
- Page 29 B x4 D x 4 CR x 1 CL x 1 6x35mm 3x12mm Insert quickfit screw(B) into correcponding holes in plate #18 as shown. Fix slide rail(CL) with screw(D) as shown. Flip the plate, insert quickfit screw(B) into correcponding holes. Fix slide rail(CR) with screw(D) as shown.
- Page 30 B x 1 CR x 1 D x 2 3 x 12mm 6x35mm Insert quickfit screw(B) into correcponding holes in plate #19 as shown. Fix slide rail(CR) with screw(D) as shown. 30/63...
- Page 31 A x 6 C x 6 15x10mm Connect plate #17 and #18 with plate #20 and #21 using wooden dowel(A) and then turn cam lock(C) in plate #20,#21 clockwise to tighten as shown. 31/63...
- Page 32 A x 2 C x2 15x10mm Connect plate #19 and #18 with plate #22 using wooden dowel(A) and then turn cam lock(C) in plate #22 clockwise to tighten as shown. 32/63...
- Page 33 B x 11 6x35mm Insert quickfit screw(B) into correcponding holes in plate #23 as shown. 33/63...
- Page 34 E x 6 A x 6 5 x 40 mm Cover plate #23 to plate #17,#18 and #19 using wooden dowel(A), and then fix with screw(E) as shown. 34/63...
- Page 35 E x 8 A x 2 5 x 40 mm Attach plate #24 to plate #23 using wooden dowel(A), and then fix with screw(E) as shown. 35/63...
- Page 36 B x 12 6x35mm Insert quickfit screw(B) into correcponding holes in plate #26 as shown. 36/63...
- Page 37 C x 12 15x10mm Connect plate #26 with plate #25 and then turn cam lock(C) in plate #25 clockwise to tighten as shown. 37/63...
- Page 38 C x 11 15x10mm Attach the base to plate #23 and then turn cam lock(C) in plate #25,#26 clockwise to tighten as shown. 38/63...
- Page 39 E x 5 5 x 40 mm Slide plate #51,#16 and #47 into available slots as shown. 39/63...
- Page 40 A x 8 C x 8 15x10mm Connect the two components using wooden dowel(A), then turn cam lock(C) in plate #24,#17,#18,#19 clockwise to tighten as shown. Require more then two people to assemble! 40/63...
- Page 41 P x 5 4x30mm Attach plate #27, #29 and #30 to plate #28, then fix with screw(P) as shown. Slide plate #31 into available slots as shown. 41/63...
- Page 42 B x 5 H x 2 D x 4 3 x 12 mm 6 x 35 mm Insert quickfit screw(B) into correcponding holes in plate #32 as shown. Fix hinge(H) using screw(D) as shown. 42/63...
- Page 43 C x 5 15x10mm Attach the component(in step 32) to plate #32, then turn cam lock(C) in plate #27,#29,#30 clockwise to tighten as shown. 43/63...
- Page 44 D x 2 J x 1 F x 2 W x 1 3 x 12 mm 4x16mm Fix handle(W) using screw(F), fix part(J) using screw(D) as shown. 44/63...
- Page 45 D x 4 X x 1 Y x 1 3 x 12 mm Fix support rod(X,Y) to plate #32 using screw(D) as shown. 45/63...
- Page 46 D x 4 3 x 12 mm Attach the component to plate #23 by fixing hinge with screw(D) as shown. 46/63...
- Page 47 D x 4 3 x 12 mm Fix support rod(X,Y) to plate #24 and #17 respectively using screw(D) as shown. 47/63...
- Page 48 P x 8 4x30mm Attach plate # 35 and #37 to plate #36, then fix with screw(P) as shown. Slide plate #38 into available slots. Attach plate # 39 and #41 to plate #40, then fix with screw(P) as shown. Slide plate #42 into available slots.
- Page 49 B x 8 F x 2 G x 2 6x35mm 4x16mm Insert quickfit screw(B) into correcponding holes in plate #33 and #34 as shown. Fix knob(G) with screw(F) as shown. 49/63...
- Page 50 C x 8 15x10mm Attach plate #33 to plate #35 and #37; attach plate #34 to plate #41 and #39, then turn cam lock(C) clockwise to tighten as shown. 50/63...
- Page 51 Dx 8 DL x 2 DR x 2 3 x 12mm Fix runner(DL) to plate #35 and #39; runner(DR) to plate #37 and #41 respectively using screw(D) as shown. 51/63...
- Page 52 Align rails, slide drawers. 52/63...
- Page 53 Z x 4 G x 2 F x 2 D x 8 26 mm 4 x 16 mm 3 x 12 mm Fix hinge(Z) to plate #43 and #44 respectively using screw(D) as shown. Fix knob(G) with screw(F) as shown. 53/63...
- Page 54 U x 4 D x 16 3 x 12 mm Attach door plate #43 to plate #17; door plate #44 to plate #19 by fixing hinge with screw(D) as shown. Insert part(U) into plate #18 and #19, place plate #8 in as shown.
- Page 55 55/63...
- Page 56 U x 12 Insert part(U) into plate #9,#4,#6 and #10, place plate #45 and #46 in as shown. 56/63...
- Page 57 Z x 6 G x 3 F x 3 D x 12 26 mm 4 x 16 mm 3 x 12 mm Fix hinge(Z) to plate #48,#49 and #50 respectively using screw(D) as shown. Fix knob(G) with screw(F) as shown. 57/63...
- Page 58 D x 24 3 x 12 mm Attach door plate #48 to plate #9; door plate #49 to plate #6; door plate #50 to plate #10 by fixing hinge with screw(D) as shown. 58/63...
- Page 59 59/63...
- Page 60 T x 28 R x 28 3 x 14 mm Reinforce back plate using part(R) with screw(T) as shown. 60/63...
- Page 61 N x 1 V x 1 4 x 35 mm Install anti-tipping device(N,V) as shown. 61/63...
- Page 62 62/63...
- Page 63 63/63...
