- Page 1 Cabinet...
- Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
- Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size A x 16 B x 16 C x 8 D x 16 E x 2 Ø6 x 34mm Ø15 x 12mm Ø8 x 30mm...
- Page 5 A x 2 B x 2 Ø6 x 34mm Ø15 x 12mm Fix quickfit screw A to panel 1 as shown. Please note don't use an electric screwdriver or use force to rotate, may cause crack. Attach panel 5 to panel 1, turn cam locks B clockwise to tighten as shown.
- Page 6 A x 8 B x 8 C x 8 Ø6 x 34mm Ø15 x 12mm Ø8 x 30mm Insert wooden dowel C to the top and bottom of panel 1&2 at first. Cover panel 3 and 4 using screw A, turn cam locks B clockwise to tighten as shown.
- Page 7 D x 16 E x 2 H x 4 Ø3 x 12mm 28 x 14mm Ø4 x 16mm Cover panel 6 to assembled component, fix using screw D. F x 4 H x 8 Ø35mm Ø4 x 16mm Fix Hinge F to panel 7 and 8 using screw H as shown.
- Page 8 G x 2 H x 4 Ø35mm Ø4 x 16mm Fix Hinge G to another panel 8 using screw H as shown. J x 1 H x 8 K x 1 Ø4 x 16mm Ø20 x 23mm Ø4 x 20mm Attach panel 7 to panel 3 by fixing Hinge F using screw H.
- Page 9 H x 16 J x 2 K x 2 Ø4 x 16mm Ø20 x 23mm Ø4 x 20mm Attach panel 8 to panel 4 by fixing Hinge F using screw H.Attach another panel 8 to panel 5 by fixing Hinge G using screw H.
-
Page 10: Warranty Claims
WARRANTY WARRANTY CLAIMS •There is a 30-day warranty for broken furniture or any other problems that do not work properly. The warranty will start from the date of purchase which must be verified by proof of purchase. •Before making a claim, we may be able to answer your query, simply call us. Please leave your purchase order number, along with some details of the problem, if you want a replacement part. - Page 11 RETURNS CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM? PLEASE FOLLOW THE BELOW INSTRUCTIONS: •If you have purchased and have simply changed your mind, follow the retailer’s instructions for returns. DEFECTIVE ITEMS •If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance, please consult our FAQ section at feedbackstation@163.com as there may be a simple solution to the issue.
