- Page 1 Shoe cabinet Version:07/19/2022 1/12...
- Page 2 IMPORTANT INFORMATION! please read the entire manual before starting to assemble and/or using this product.follow the manual thoroughly and keep it for further reference. AVOID SCRATCHES! In order to avoid scratching this furnuture should be assembled on a soft layer-could be a rug. IMPROVE EFFICIENCY ! Try to find a partner to install with you, which can speed up...
- Page 3 Please prepare the following tools When installing, please carefully confirm whether each screw corresponds to the manual, accessories with similar shapes can be distinguished by size A x 16 B x 24 C x 4 D x 2 4 x 40 mm 3.5 x 14 mm 4 x 10 mm E x 4...
- Page 4 4/12...
- Page 5 H x 4 F1 x 4 F2 x 4 6 x 30 mm Hammer F1 & F2 slightly into the holes on panel 2 &3, Note do not tilt to avoid damage. Insert the wooden tenon (H) into plate 1, as shown. 5/12...
- Page 6 A x 8 G x 8 4 x 40 mm 12 mm Attach panel 1,4 and 5 to panel 3 using screw A as shown. 6/12...
- Page 7 A x 8 G x 8 4 x 40 mm 12 mm Attach panel 1,4 and 5 to panel 2 using screw A as shown. 7/12...
- Page 8 J x 22 I x 4 2.5 x 14 mm Fix panel 9 to the back of assembled unit using screw J to pre-drilled holes as shown. Fix part I to the bottom. 180° 90° 8/12...
- Page 9 B x 16 D x 2 E x 4 L x 2 R x 2 3.5 x 14 mm 4 x 16 mm Fix plastic part L&R to panel 8, use screw B to tighten. Attach this part to panel 6 using screw B to corresponding holes as shown. B x 4 3.5 x 14 mm Attach panel 7 to the assembled part...
- Page 10 C x 4 F3 x 4 4 x 10 mm Fix the plastic part L&R to panel 2&3 by using F3 slightly. Then screw C to tighten. 4 x 10 mm 3.5 x 14 mm 10/12...
- Page 11 Insert panel 7 to the middle of drawers 11/12...
- Page 12 B x 4 3.5 x 14 mm Using screw B to fix panel 7 to both side plastic part as shown. 3.5 x 14 mm 4 x 10 mm 12/12...
- Page 13 WARRANTY WARRANTY CLAIMS •There is a 30-day warranty for broken furniture or any other problems that do not work properly. The warranty will start from the date of purchase which must be verified by proof of purchase. •Before making a claim, we may be able to answer your query, simply call us. Please leave your purchase order number, along with some details of the problem, if you want a replacement part.
- Page 14 RETURNS CHANGED YOUR MIND AND NEED TO RETURN YOU ITEM? PLEASE FOLLOW THE BELOW INSTRUCTIONS: •If you have purchased and have simply changed your mind, follow the retailer’s instructions for returns. DEFECTIVE ITEMS •If your item is defective in any way, i.e. it doesn’t work but you can’t identify why, in the first instance, please call us.
