TP-Link Omada IES210GPP Quick Start Manual

Industrial easy managed switch

Hide thumbs Also See for Omada IES210GPP:

Installation manual (2 pages)

page of 26

/ 26
Bookmarks

Quick Links

Download this manual

Omada Industrial

Easy Managed Switch

Quick Start Guide

Need help?

Do you have a question about the Omada IES210GPP and is the answer not in the manual?

Questions and answers

Summary of Contents for TP-Link Omada IES210GPP

Page 2 Omada Industrial Easy Managed Switch CONTENTS About this Guide Chapter 1 Product Overview ———————————————————— 01 1.1 Front Panel ...............................01 1.2 Top Panel ..............................04 Chapter 2 Installation ——————————————————————— 05 2.1 Installation Procedures ........................05 2.2 Prepare for Installation ........................05 2.3 Install the Switch ...........................06 2.4 Verify Installation ...........................09 2.5 Power on the Switch ..........................09 Chapter 3 Configuration ——————————————————————...
Page 3 Omada Industrial Easy Managed Switch About this Guide This Installation Guide describes the hardware characteristics, installation methods and the points that should be attended to during the installation. This Installation Guide is structured as follows: Chapter 1 Product Overview This chapter describes the external components of the switch. Chapter 2 Installation This chapter illustrates the installation procedures of the switch.
Page 4 Omada Industrial Easy Managed Switch More Resources Main Site https://www.omadanetworks.com/ Video Center https://support.omadanetworks.com/video/ Documents https://support.omadanetworks.com/document/ Product Support https://support.omadanetworks.com/product/ Technical Support https://support.omadanetworks.com/contact-support/ Warranty For details on the warranty period, policy, and procedures, visit https://support.omadanetworks.com/warranty-services/. Support For technical support, user guides and other information, please visit https://support.omadanetworks.com/.
Page 5 Omada Industrial Easy Managed Switch Chapter 1 Product Overview 1.1 Front Panel (The figures are for demonstration only. They may differ from your actual products. ) The front panel of IES206G / IES208G is shown as the following figure. Power Status LED Reset Button RJ45 Port Link/Act LED...
Page 6 Omada Industrial Easy Managed Switch Explanation On: PWR1 power supply is on. Off: PWR1 power supply is off. Power Status On: PWR2 power supply is on. Off: PWR2 power supply is off. On (Green): Running at 1000 Mbps Link/Act On (Yellow): Running at 10/100 Mbps Ports 1-5 of IES206G Blinking: Transmitting/receiving data Ports 1-8 of IES208G...
Page 7 Omada Industrial Easy Managed Switch The front panel of IES206GPP / IES210GPP is shown as the following figure. Power Status LED PoE Max LED Reset Button RJ45 PoE Port Link/Act LED PoE Status LED RJ45 Port SFP Slot SFP LED...
Page 8 Omada Industrial Easy Managed Switch Explanation On: PWR1 power supply is on. Off: PWR1 power supply is off. Power Status On: PWR2 power supply is on. Off: PWR2 power supply is off. On (Green): Running at 1000 Mbps Link/Act On (Yellow): Running at 10/100 Mbps Ports 1-5 of IES206GPP Blinking: Transmitting/receiving data Ports 1-10 of IES210GPP...
Page 9 Omada Industrial Easy Managed Switch 1.2 Top Panel (The figures are for demonstration only. They may differ from your actual products. ) Terminal Block Ground Screw...
Page 10 Omada Industrial Easy Managed Switch Chapter 2 Installation 2.1 Installation Procedures The installation procedures of the switch are shown as follows. Prepare for Installation Install the Switch Verify Installation Power On the Switch 2.2 Prepare for Installation Package Contents ■ The actual package contents may differ based on region.
Page 11 Omada Industrial Easy Managed Switch Other Installation Tools ■ • Phillips screwdriver • Driller • Expansion bolts • ANSI B1.1 4# standard screws • Wire stripper • Wire crimper • Ratcheting torque screwdriver • Ring terminal • Ground wires • Copper wires •...
Page 12 Omada Industrial Easy Managed Switch The mounting dimensions are shown as follows: • DIN-rail mounting dimensions 1) DIN-rail mounting bracket 2) DIN-rail 1 mm (0.04 in) 7.5 mm (0.3 in) • Wall-mounting dimensions 1) Non-PoE Switch (For IES206G/ IES208G) 16 mm (0.6 in)
Page 13 Omada Industrial Easy Managed Switch 2) PoE Switch (For IES206GPP/ IES210GPP) 16 mm (0.6 in) Ground the Switch ■ The switch must be properly grounded before connecting to power supply and other devices. Caution: The ground wire must be copper and at least 14 AWG. Wire DC Power Supply ■...
Page 14 Omada Industrial Easy Managed Switch Connect the Switch ■ The steps to connect the switch are as follows: • Ground the switch properly. • Connect the terminal block to the DC power supply (keep the power off). • Insert the terminal block into the switch. •...
Page 15 Omada Industrial Easy Managed Switch all LED indicators will turn on momentarily and then turn off except the Power LED(s), indicating a successful initialization.
Page 16 Omada Industrial Easy Managed Switch Chapter 3 Configuration 3.1 Configuration Overview The switch supports two configuration options: • Standalone Mode: Configure and manage the switch singly. • Controller Mode: Configure and manage the network devices centrally. It is recommended in the large-scale network, which consists of mass devices such as access points, switches, and gateways.
Page 17 Omada Industrial Easy Managed Switch * Omada App With the TP-Link Omada app, you can access and manage your Omada devices at a local site or remotely with a tap of your phone. You can download and install the TP-Link Omada app...
Page 18 Omada Industrial Easy Managed Switch Appendix A Troubleshooting Q1. What could I do if I forgot the username and password of the switch? Press the Reset button for at least 5 seconds to reset the system. The system will be reset to the factory default settings, and the default login user name and password are both admin.
Page 19 Omada Industrial Easy Managed Switch Appendix B Specifications Item Content IEEE 802.3, IEEE 802.3i, IEEE 802.3ab IEEE 802.3u, IEEE 802.3z IEEE 802.3x, IEEE 802.1p, IEEE 802.1q Standards IEEE 802.1d, IEEE 802.1w, IEEE 802.1ab IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt (For IES206GPP/IES210GPP) 10Base-T: UTP/STP of Cat.
Page 20 Omada Industrial Easy Managed Switch Up to 60 W (PoE++ Port) PoE Power Per Port Up to 30 W (PoE+ Port) Operating Temperature -40 °C to 75 °C (-40 °F to 167 °F) Storage Temperature -40 °C to 85 °C (-40 °F to 185 °F) Operating Humidity 5% to 95%RH Non-condensing Storage Humidity...
Page 21 Any changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. We, TP-Link Systems Inc., has determined that the equipment shown as above has been shown to comply with the applicable technical standards, FCC part 15. There is no unauthorized change is made in the equipment and the equipment is properly maintained and operated.
Page 22 TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863. The original EU declaration of conformity may be found at https://www.tp-link.com/en/ce UKCA Mark Warning TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of the Electromagnetic Compatibility Regulations 2016 and Electrical Equipment (Safety) Regulations 2016.
Page 23 限用物質含有情況標示聲明書限用物質及其化學符號單元鉛鎘汞六價鉻多溴聯苯多溴二苯醚 PBDE ○ ○ ○ ○ ○ ○ 外殼 ○ ○ ○ ○ ○ ○ 塑膠組件 ○ ○ ○ ○ ○ ○ 五金組件 — ○ ○ ○ ○ ○ 其他及其配件 — ○ ○...
Page 24 ■ The operating temperature for the device shall be within -40˚C to 75˚C (-40˚F to 167˚F). ■ 運作溫度 : -40˚C to 75˚C (-40˚F to 167˚F) Please read and follow the above safety information when operating the device. We cannot guarantee that no accidents or damage will occur due to improper use of the device. Please use this product with care and operate at your own risk.
Page 25 Frame or chassis 框架或外殼 Functional earthing 功能接地 Caution, hot surface 請注意，表面過熱 Caution 警告 Operator's manual 操作手冊 Stand-by 待機 "ON"/"OFF" (push-push) “開啟”/”關閉”（按壓式） Fuse 保險絲 Fuse is used in neutral N 保險絲用於中性線 N RECYCLING 回收 This product bears the selective sorting symbol for Waste electrical and electronic equipment (WEEE).
Page 26 Disconnection, all power plugs 斷線，所有電源插頭 Switch of mini-gap construction 迷你間隙結構開關 Switch of micro-gap construction (for US version) Switch of micro-gap / micro-disconnection construction (for other versions except US) µ 小間隙結構開關（US 版本）小間隙 / 小斷開結構的開關（非 US 版） Switch without contact gap (Semiconductor switching device) ε...
