The mounting dimensions are shown as follows:
•
DIN-rail mounting dimensions
1) DIN-rail mounting bracket
2) DIN-rail
•
Wall-mounting dimensions
1) Non-PoE Switch (For IES206G/ IES208G)
16 mm (0.6 in)
Omada Industrial Easy Managed Switch
1 mm (0.04 in)
7.5 mm (0.3 in)
8
