2) PoE Switch (For IES206GPP/ IES210GPP)
Ground the Switch
■
The switch must be properly grounded before connecting to power supply and other devices.
Caution:
The ground wire must be copper and at least 14 AWG.
Wire DC Power Supply
■
Use copper wires and ferrules of proper dimensions to wire the DC power supply and connect
it to the switch.
Caution:
1. The wires must be copper and at least 22 AWG for IES206G/ IES208G and 14 AWG for
IES206GPP/ IES210GPP.
2. The recommended length of the wire to be stripped is 10 mm (0.39 inch).
3. The recommended length of the copper ferrules is 8 mm (0.31 inch).
16 mm (0.6 in)
Omada Industrial Easy Managed Switch
9
