  • Page 1 Business Networking Solution Installation Guide Omada L2+ Managed Switch...
  • Page 3 Remind to take notice. The note contains the helpful information for a better use of the product. Related Document The User Guide and CLI Reference Guide of the product are provided on Download Center. To obtain the latest product information, visit the official website: https://www.tp-link.com.

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction ——————————— 01 Product Overview ............01 Appearance ...............01 Chapter 2 Installation ——————————— 16 Package Contents ............16 Safety Precautions ............16 Installation Tools ..............18 Product Installation ............18 Chapter 3 Connection ——————————— 20 Ethernet Port ..............20 SFP/SFP+ Slot ..............20 Console Port ..............20 Verify Installation .............21 Power On ................22 Initialization ................22...

  • Page 5: Chapter 1 Introduction

    Omada L2+ Managed Switch Chapter 1 Introduction Product Overview Designed for workgroups and departments, TP-Link Omada's L2+ Managed Switch provides wire-speed performance and abundant L2 management features. It provides a variety of service features and multiple powerful functions with high security.
  • Page 6 Omada L2+ Managed Switch The front panel of SX3032F is shown as the following figure. Console Port SFP+ Slot (RJ45/USB) The front panel of SG3210 is shown as the following figure. 10/100/1000M Console Port 1G RJ45 Port SFP Slot (RJ45/USB) The front panel of SG3210X-M2 is shown as the following figure.
  • Page 7 Omada L2+ Managed Switch The front panel of SG3428MP is shown as the following figure. Console Port SFP Slot (RJ45/USB) RJ45 Port The front panel of SG3428X is shown as the following figure. Console Port SFP+ Slot (USB/RJ45) RJ45 Port The front panel of SG3428XF is shown as the following figure.
  • Page 8 Omada L2+ Managed Switch The front panel of SG3428XPP-M2 is shown as the following figure. Console Port 2.5G SFP+ Slot (RJ45/USB) RJ45 Port The front panel of SG3452 is shown as the following figure. Console Port 1G RJ45 Port SFP Slot (USB/RJ45) The front panel of SG3452P is shown as the following figure.
  • Page 9 Omada L2+ Managed Switch LEDs For SX3206HPP Indication On: The switch is powered on. Off: The switch is powered off or power supply is abnormal. Flashing: Power supply is abnormal. Flashing: The switch works properly. On or Off: The switch works improperly. On: The remaining PoE power is ≤...
  • Page 10 Omada L2+ Managed Switch Indication Green On: Running at 10 Gbps, but no activity. Green Flashing: Running at 10 Gbps and transmitting or receiving data. – Port 1 Yellow On: Running at 1 Gbps, but no activity. Yellow Flashing: Running at 1 Gbps and transmitting or receiving data. Off: No device is linked to the corresponding port.
  • Page 11 Omada L2+ Managed Switch Indication On: Running at 2.5 Gbps, but no activity. 2.5G Flashing: Running at 2.5 Gbps and transmitting or receiving data. Off: Running at 1000/100 Mbps or no device is linked to the corresponding port. Green On: Running at 1 Gbps, but no activity. Green Flashing: Running at 1 Gbps and transmitting or receiving data.
  • Page 12 Omada L2+ Managed Switch Indication Green On: Running at 10 Gbps, but no activity. Green Flashing: Running at 10 Gbps and transmitting or receiving data. Port 9–10 Yellow On: Running at 1 Gbps, but no activity. Yellow Flashing: Running at 1 Gbps and transmitting or receiving data. Off: No device is linked to the corresponding port.
  • Page 13 Omada L2+ Managed Switch For SG3210, SG3452 and SG3452X Indication On: The switch is powered on. Off: The switch is powered off or power supply is abnormal. Flashing: Power supply is abnormal. Flashing: The switch works properly. On or Off: The switch works improperly. Green On: Running at 1000 Mbps, but no activity.
  • Page 14 Omada L2+ Managed Switch For SG3428X Indication On: The switch is powered on. Off: The switch is powered off or power supply is abnormal. Flashing: Power supply is abnormal. Flashing: The switch works properly. On or Off: The switch works improperly. On: A device is linked to the port but no activity.
  • Page 15 Omada L2+ Managed Switch Indication Green On: Running at 10 Gbps, but no activity. Green Flashing: Running at 10 Gbps and transmitting or receiving data. Port 25–28 Yellow On: Running at 1 Gbps, but no activity. Yellow Flashing: Running at 1 Gbps and transmitting or receiving data. Off: No device is linked to the corresponding port.
  • Page 16 Omada L2+ Managed Switch Indication Green: All the fans work properly. Yellow: Not all the fans work properly. Green On: Running at 2.5Gbps, but no activity. Green Flashing: Running at 2.5Gbps and transmitting or receiving data. Speed or PoE Yellow On: Running at 10/100/1000Mbps, but no activity. (When the Speed Yellow Flashing: Running at 10/100/1000Mbps and transmitting or receiving data.
  • Page 17 Omada L2+ Managed Switch Indication On: Running at 1 Gbps, but no activity. Flashing: Running at 1 Gbps and transmitting or receiving data. Off: No device is linked to the corresponding port. Note: For SG3428MP Green On: Running at 1000 Mbps, but no activity. Green Flashing: Running at 1000 Mbps and transmitting or receiving data.
  • Page 18 Omada L2+ Managed Switch 100 M/1 G/2.5 G/ 10 M/100 M/ 10/100/1000 Mbps Model 5 G/10 Gbps 1000 M/2.5 Gbps SFP+ Slot SFP Slot Console Port RJ45 Port RJ45 Port RJ45 Port SX3016F SX3032F SG3210 SG3210X-M2 SG3210XHP-M2 SG3218XP-M2 SG3428 SG3428MP SG3428X SG3428XF SG3428XMP...
  • Page 19 PE (Protecting Earth) cable of AC cord or with Ground Cable. For detailed lightning protection measures, go to https://www.tp-link.com/support, search the model number of your switch and go to the product Support web page, refer to the Lightning Protection Guide from the Related Documents: https://www.tp-link.com/us/configuration-guides/lightning_protection_guide/.

  • Page 20: Chapter 2 Installation

    Omada L2+ Managed Switch Chapter 2 Installation Package Contents Make sure that the package contains the following items. Please contact your distributor, if any of the listed items is damaged or missing. The figures are for demonstration only. The actual items may differ in appearance and quantity from the depicted.
  • Page 21 Omada L2+ Managed Switch Keep the equipment room at an appropriate level of temperature and humidity. Too much or too little humidity may lead to bad insulation, leakage of electricity, mechanical property changes, and corrosion. High temperatures may accelerate aging of the insulation materials, significantly shortening the service life of the device.

  • Page 22: Installation Tools

    Use the signal SPD (Surge Protective Device) when wiring outdoor. ■ Note: For detailed lightning protection measures, go to https://www.tp-link.com/support, search the model number of your switch and go to the product Support web page, refer to the Lightning Protection Guide from the Related Documents: https://www.tp-link.com/us/configuration-guides/lightning_protection_guide/.
  • Page 23 Omada L2+ Managed Switch 3. Turnover the device and attach the supplied rubber feet to the recessed areas on the bottom at each corner of the device. Figure 2-1 Desktop Installation Feet Bottom of the Device Notch Rack Installation ■ To install the device in an EIA standard-sized, 19-inch rack, follow the instructions described below: 1.

  • Page 24: Chapter 3 Connection

    Omada L2+ Managed Switch Chapter 3 Connection Ethernet Port Connect an Ethernet port of the switch to the computer by RJ45 cable as the following figure shows. Figure 3-1 Connecting the RJ45 Port RJ45 Port RJ45 Cable SFP/SFP+ Slot The following figure demonstrates the connection of SFP/SFP+ slot to an SFP/SFP+ module. Figure 3-2 Inserting the SFP/SFP+ Module SFP/SFP+ Slot...

  • Page 25: Verify Installation

    Omada L2+ Managed Switch Connect the console (RJ45) port of the device with your computer by the console cable as the following figure shows. Figure 3-3 Connecting the Console (RJ45) Port Connect the console (USB) port of the device with your computer by the USB cable (not provided) as the following figure shows.

  • Page 26: Power On

    Omada L2+ Managed Switch Power On Plug the female connector of the provided power cord into the power socket of the device and plug the positive connector into a power outlet as the following figure shows. Make sure that the voltage of the power supply meets the requirement of the input voltage (100-240 V~ 50/60 Hz).

  • Page 27: Chapter 4 Configuration

    3. After a successful login, the main page will appear. You can click the menus on the top side and left side to configure the corresponding functions. For the detailed configurations, refer to the User Guide and CLI Guide. The guides can be found on the download center of our official website: https://www.tp-link.com/support/download/. Using the CLI ■...

  • Page 28: Controller Mode

    None For the detailed configurations, refer to the User Guide and CLI Guide. The guides can be found on the download center of our official website: https://www.tp-link.com/download-center.html Note: For certain devices, you may need to change the password the first time you log in, which will better protect your network and devices.
  • Page 29 Launch a web browser and enter https://omada.tplinkcloud.com in the address bar. Enter your TP-Link ID and password to log in. Click + Add Controller and choose Hardware Controller to add your controller. Then you can further configure the controller.
  • Page 30 Make sure that Cloud Access is enabled on your controller and your controller has been bound with your TP-Link ID. On the Omada Controller’s web page, go to Settings > Cloud Access to enable Cloud Access and bind your TP-Link ID. If you have set it up in the quick setup, skip this step.

  • Page 31: Appendix A Troubleshooting

    Omada L2+ Managed Switch Appendix A Troubleshooting Q1. What could I do if I forgot the username and password of the switch? Connect the console port of the PC to the console port of the switch and open a terminal emulation program.

  • Page 32: Appendix B Specifications

    Omada L2+ Managed Switch Appendix B Specifications Specifications for Switches with RJ45 Ports and SFP/SFP+ Slots Item Content IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3z, IEEE 802.3x, IEEE 802.1p, IEEE 802.1q, IEEE 802.1x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1ab IEEE 802.3af/at (For SX3206HPP, SG3210XHP-M2, SG3218XP-M2, SG3428MP, SG3428XMP, SG3428XMPP, SG3428XPP-M2, SG3452P, SG3452XP, SG3452XMPP) IEEE 802.3bt (For SX3206HPP, SG3428XMPP, SG3428XPP-M2, SG3452XMPP) IEEE 802.3i...
  • Page 33 Omada L2+ Managed Switch 10BASE-T: 2-pair UTP/STP of Cat. 3,4,5 (maximum 100 m) (Except SX3206HPP, SG3210XHP-M2, SG3428XF) 100BASE-TX: 2-pair UTP/STP of Cat. 5 or above (maximum 100 m) 1000BASE-T: 4-pair UTP/STP of Cat. 5e or above (maximum 100 m) 2.5GBASE-T: 4-pair UTP/STP of Cat. 5e or above (maximum 100 m) (For SX3206HPP, SG3210X-M2, SG3210XHP-M2, SG3218XP-M2, SG3428X-M2, SG3428XPP-M2) 5GBASE-T: 4-pair UTP/STP of Cat.
  • Page 34 Omada L2+ Managed Switch SG3428XMPP, SG3428X-M2, SG3428XPP-M2, SG3452, SG3452P, SG3452X, SG3452XP, SG3452XMPP: 0 °C to 40 °C (32 °F to 104 °F) SG3210, SG3428, SG3428MP, SG3428X , SG3428XF, SG3428X-UPS, Operating SG3428XMP: Temperature 0 °C to 45 °C (32 °F to 113 °F) SX3206HPP, SG3210X-M2, SG3210XHP-M2, SG3218XP-M2: 0 °C to 50 °C (32 °F to 122 °F) Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F)
  • Page 35 EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863. The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce/...
  • Page 36 To ask questions, find answers, and communicate with TP-Link users or engineers, please visit https://community.tp-link.com to join TP-Link Community. For technical support, the user guide and other information, please visit https://www.tp-link.com/support, or simply scan the QR code. © 2024 TP-Link 7106510777 REV1.2.0...
