  • Page 1 Business Networking Solution Installation Guide Omada Pro L2+ Managed Switch...
  • Page 3 Remind to take notice. The note contains the helpful information for a better use of the product. Related Document The User Guide and CLI Reference Guide of the product are provided on Download Center. To obtain the latest product information, visit the official website: https://www.tp-link.com.
  • Page 4 Contents Chapter 1 Introduction ——————————— 01 Product Overview ............01 Appearance ...............01 Chapter 2 Installation ——————————— 11 Package Contents ............11 Safety Precautions ............11 Installation Tools ..............13 Product Installation ............13 Chapter 3 Connection ——————————— 16 Ethernet Port ..............16 SFP/SFP+ Slot ..............16 Console Port ..............16 Verify Installation .............17 Power On ................18 Initialization ................18...
  • Page 5 Omada Pro L2+ Managed Switch Chapter 1 Introduction Product Overview Designed for workgroups and departments, TP-Link Omada Pro L2+ Managed Switch provides wire-speed performance and abundant L2 management features. It provides a variety of service features and multiple powerful functions with high security.
  • Page 6 Omada Pro L2+ Managed Switch The front panel of S5500-24F4XF is shown as the following figure. Console Port SFP Slot SFP+ Slot (USB/RJ45) RJ45 Port The front panel of S5500-8MHP2XF is shown as the following figure. Console Port 2.5G SFP+ Slot (RJ45/USB) RJ45 Port The front panel of S5500-24MPP4XF is shown as the following figure.
  • Page 7 Omada Pro L2+ Managed Switch The front panel of S5500-48GP4XF is shown as the following figure. PoE Max Speed Console(RJ45) Console(USB) 10Gbps 1Gbps activity 1000Mbps 10/100Mbps activity Delivering Power Over Budget Fault SFP+ Speed Console Port 1G RJ45 Port SFP+ Slot (RJ45/USB) LEDs For S5500-4XHPP2XF...
  • Page 8 Omada Pro L2+ Managed Switch For S5500-8XF Indication On: The switch is powered on. Off: The switch is powered off or power supply is abnormal. Flashing: Power supply is abnormal. Flashing: The switch works properly. On or Off: The switch works improperly. Green On: Running at 10 Gbps, but no activity.
  • Page 9 Omada Pro L2+ Managed Switch For S5500-24F4XF PWR1* PWR2 Indication The switch is powered by PWR1. Green On PWR2 is disconnected or it works improperly. The switch is powered by PWR1. Green On Yellow On** PWR1 and PWR2 are connected.* The switch is powered by PWR2.
  • Page 10 Omada Pro L2+ Managed Switch Indication On: The remaining PoE power is ≤ 7 W. PoE Max Flashing: The remaining PoE power keeps ≤ 7 W after this LED is on for 2 minutes. Off: The remaining PoE power is > 7 W. Green: All the fans work properly.
  • Page 11 Omada Pro L2+ Managed Switch Indication Green On: The port is supplying power normally. Green Flashing: The supply power exceeds the correponding port's maximum power. Speed or PoE Yellow On: Overload or short circuit is detected. (When the PoE LED Yellow Flashing: Power-on self-test failed.
  • Page 12 Omada Pro L2+ Managed Switch For S5500-24GP4XF, S5500-48GP4F and S5500-48GP4XF Indication On: The switch is powered on. Off: The switch is powered off or power supply is abnormal. Flashing: Power supply is abnormal. Flashing: The switch works properly. On or Off: The switch works improperly. On: The remaining PoE power is ≤...
  • Page 13 Omada Pro L2+ Managed Switch PoE switches, the port can also provide power for PDs. 10/100/1000 Mbps RJ45 Port Designed to connect to the device with a bandwidth of 10 Mbps, 100 Mbps or 1000 Mbps. For PoE switches, the port can also provide power for PDs. SFP/SFP+ Slot SFP slot is designed to install the 1 Gbps SFP module.
  • Page 14 PE (Protecting Earth) cable of AC cord or with Ground Cable. For detailed lightning protection measures, go to https://www.tp-link.com/support, search the model number of your switch and go to the product Support web page, refer to the Lightning Protection Guide from the Related Documents: https://www.tp-link.com/us/configuration-guides/lightning_protection_guide/.
  • Page 15 Omada Pro L2+ Managed Switch Chapter 2 Installation Package Contents Make sure that the package contains the following items. Please contact your distributor, if any of the listed items is damaged or missing. The figures are for demonstration only. The actual items may differ in appearance and quantity from the depicted.
  • Page 16 Omada Pro L2+ Managed Switch Keep the equipment room at an appropriate level of temperature and humidity. Too much or too little humidity may lead to bad insulation, leakage of electricity, mechanical property changes, and corrosion. High temperatures may accelerate aging of the insulation materials, significantly shortening the service life of the device.
  • Page 17 Use the signal SPD (Surge Protective Device) when wiring outdoor. ■ Note: For detailed lightning protection measures, go to https://www.tp-link.com/support, search the model number of your switch and go to the product Support web page, refer to the Lightning Protection Guide from the Related Documents: https://www.tp-link.com/us/configuration-guides/lightning_protection_guide/.
  • Page 18 Omada Pro L2+ Managed Switch 2. Remove the adhesive backing papers from the rubber feet. 3. Turnover the device and attach the supplied rubber feet to the recessed areas on the bottom at each corner of the device. Figure 2-1 Desktop Installation Feet Bottom of the Device...
  • Page 19 Omada Pro L2+ Managed Switch Caution: Leave 5 to 10 cm gaps around the devices for air circulation. ■ Avoid placing heavy things on the device. ■ Place the device with its bottom facing downwards. ■ Mount devices in sequence from the bottom to top of the rack and ensure a certain clearance ■...
  • Page 20 Omada Pro L2+ Managed Switch Chapter 3 Connection Ethernet Port Connect an Ethernet port of the switch to the computer by RJ45 cable as the following figure shows. Figure 3-1 Connecting the RJ45 Port RJ45 Port RJ45 Cable SFP/SFP+ Slot The following figure demonstrates the connection of SFP/SFP+ slot to an SFP/SFP+ module.
  • Page 21 Omada Pro L2+ Managed Switch Connect the console (RJ45) port of the device with your computer by the console cable as the following figure shows. Figure 3-3 Connecting the Console (RJ45) Port Connect the console (USB) port of the device with your computer by the USB cable (not provided) as the following figure shows.
  • Page 22 Omada Pro L2+ Managed Switch Power On Plug the female connector of the provided power cord into the power socket of the device and plug the positive connector into a power outlet as the following figure shows. Make sure that the voltage of the power supply meets the requirement of the input voltage (100-240 V~ 50/60 Hz).
  • Page 23 3. After a successful login, the main page will appear. You can click the menus on the top side and left side to configure the corresponding functions. For the detailed configurations, refer to the User Guide and CLI Guide. The guides can be found on the download center of our official website: https://www.tp-link.com/support/download/. Using the CLI ■...
  • Page 24 None For the detailed configurations, refer to the User Guide and CLI Guide. The guides can be found on the download center of our official website: https://www.tp-link.com/download-center.html Note: For certain devices, you may need to change the password the first time you log in, which will better protect your network and devices.
  • Page 25 2) Launch a web browser and enter https://omada.tplinkcloud.com in the address bar. Log in with your TP-Link ID. A list of controllers that have been bound with your TP-Link ID will appear. Then you can launch the controller to adopt and manage devices.
  • Page 26 With the Omada app, you can also manage your controller at a local site or a remote site via your mobile device. For the detailed configurations, refer to the User Guide of the controller. The guide can be found on the download center of our official website: https://www.tp-link.com/support/download/. Configuration...
  • Page 27 Omada Pro L2+ Managed Switch Appendix A Troubleshooting Q1. What could I do if I forgot the username and password of the switch? Connect the console port of the PC to the console port of the switch and open a terminal emulation program.
  • Page 28 Omada Pro L2+ Managed Switch Appendix B Specifications Specifications for Switches with RJ45 Ports and SFP/SFP+ Slots Item Content IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3z, IEEE 802.3x, IEEE 802.1p, IEEE 802.1q, IEEE 802.1x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1ab IEEE 802.3af/at (For S5500-4XHPP2XF, S5500-8MHP2XF, S5500-24MPP4XF, S5500- 24GP4F, S5500-24GP4XF, S5500-48GP4F, S5500-48GP4XF) IEEE 802.3bt (For S5500-4XHPP2XF, S5500-24MPP4XF) Standards...
  • Page 29 S5500-4XHPP2XF: PWR, SYS, PoE Max, FAN, Speed, PoE, SFP+ S5500-24F4XF: PWR, SYS, 100/1000Mbps, FAN, SFP+ S5500-8MHP2XF: PWR, SYS, PoE Max, FAN, Speed, PoE, Port 9, Port 10 S5500-24MPP4XF: PWR, SYS, PoE Max, FAN, Speed or PoE, SFP+, Speed, PoE S550 0 -24G P4F: P W R , SYS , FA N , PoE M A X , S peed , PoE , 10 0 B ase - TX/1000BASE-X S5500-24GP4XF: PWR, SYS, PoE Max, FAN, Speed or PoE, SFP+, Speed, PoE S5500-48GP4F: PWR, SYS, Speed, PoE Max, FAN, PoE, Port 1-52...
  • Page 30 EU Declaration of Conformity TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2011/65/EU and (EU)2015/863. The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce/...
  • Page 31 • Plug the product into the wall outlets with earthing connection through the power supply cord or plug. • The socket-outlet shall be installed near the equipment and shall be easily accessible. • The PoE ports shall not be used to charge lithium batteries or devices supplied by lithium batteries.
  • Page 32 To ask questions, find answers, and communicate with TP-Link users or engineers, please visit https://community.tp-link.com to join TP-Link Community. For technical support, the user guide and other information, please visit https://www.tp-link.com/support, or simply scan the QR code. © 2023 TP-Link 7106510757 REV1.1.1...
