ASROCK Rack M350 Quick Installation Manual

*15G065045001AK*
P/N: 15G065045001AK V1.1
Quick Installation Guide
Mezzanine Card Series
Introduction
Thank you for purchasing ASRock Rack mezzanine card, a reliable mezzanine card
produced under ASRock Rack's consistently stringent quality control. It delivers excellent
performance with robust design conforming to ASRock Rack's commitment to quality and
endurance.
Model Dimension
2.7'' x 4.3''
M350
(6.8 cm x 10.9 cm)
2.7'' x 4.3''
M540
(6.8 cm x 10.9 cm)
2.7'' x 4.3''
M599
(6.8 cm x 10.9 cm)
2.7'' x 4.3''
M350R
(6.8 cm x 10.9 cm)
2.7'' x 4.3''
M540R
(6.8 cm x 10.9 cm)
2.7'' x 4.3''
M599R
(6.8 cm x 10.9 cm)
2.7'' x 4.3''
M710
(6.8 cm x 10.9 cm)
2.7'' x 4.3''
M710S
(6.8 cm x 10.9 cm)
2.7'' x 4.3''
MCX3
(6.8 cm x 10.9 cm)
2.7"x 4.3"
M3008S
(6.8 cm x 10.9 cm)
Interface / Connector
Gigabit LAN
/ 2 x RJ45
10/100/1000 Mb/s
10G/1G/100M/s / 2 x RJ45 (10G Base-T)
10G/s / 2 x SFP+ (Fiber)
Gigabit LAN
/ 2 x RJ45
10/100/1000 Mb/s
10G/1G/100M/s / 2 x RJ45 (10G Base-T)
10G/s / 2 x SFP+ (Fiber)
10/40Gb/s / 2 x QSFP+ 40Gb/s
10/40Gb/s / 1 x QSFP+ 40Gb/s
10/40Gb/s / 2 x QSFP+ 40Gb/s
SAS 12G / 2 x SAS HD 4i (8 ports)
LAN / Storage Controller
1 x Intel® i350
1 x Intel® X540
1 x Intel® 82599ES
1 x Intel® i350
1 x Intel® X540
1 x Intel® 82599ES
1 x Intel® XL710-AM2
1 x Intel® XL710-AM1
1 x Mellanox
ConnectX®-3 Pro EN
AvagoSAS3008 PowerPC
476 controller @ 1.2 GHz
