ASROCK Rack 1U12E-GENOA/2L2T Quick Installation Manual

*15G065276000AR*
P/N: 15G065276000AR V1.0
Quick Installation Guide
1U12E-GENOA/2L2T
The User's Manual is available for download from the ASRock Rack's offi cial website at http://
www.asrockrack.com.
Take note of the following precautions before installing the components or change any settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the components due to static electricity, NEVER place the components
directly on the carpet or the like. Also remember to use a grounded wrist strap or touch a safety
grounded object before installation.
3. Hold components by the edges and do not touch the ICs.
4. Whenever uninstalling any components, place them on a grounded anti-static pad or in the bag
that comes with the components.
5. When placing screws into the screw holes to secure any components to the barebone, please
do not over-tighten the screws! Doing so may damage both components and barebone.
2 Top View
2
1
3
10 9 8
12
5 Front Panel
1
HDD2 HDD4 HDD6
HDD1 HDD3 HDD5
No. Description
1 1 x USB 3.2 Gen1 Port
12 x 2.5" Hot-Swap HDD Trays
2
(2.5" NVMe / SATA SSD / SAS HDD)
3 Control Panel (depends on the speci cation of the server board)
4
7 6 5
11
13
2
HDD8 HDD10 HDD12
HDD11
HDD7 HDD9
1 Replace Server Board
Carefully unplug all cables and release
1
thumbscrews on the ser ver board to
remove them from the barebone.
Align the replaced server board with the
2
mounting holes
A f f i x t he screws clock w ise into t he
3
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws
No. From
1 Riser Card (PCIe x16) (RB1)
2 Riser Card (PCIe x16) (RB2)
3 Serverboard
4 2 x Power Supply Units (PSU)
5 System Fan 1
6 System Fan 2
7 System Fan 3
8 System Fan 4
9 System Fan 5
10 System Fan 6
11 2.5" HDD Backplane Board (BPB)
12 Front USB 3.2 Gent1 Port
12 x 2.5" HDD Trays (HDD1)
13
(Hot-swapable)
14 Front Control Panel
I/O Panel
4
2
1 3
No. Description
1 USB 3.2 Gen1 Ports (USB3_1_2)
14
2 IPMI LAN Header (IPMI_LAN1)
3 1G LAN RJ-45 Port (LAN1)
4 1G LAN RJ-45 Port (LAN2)
6 Rear Panel
1
3
No. Description
1 2 x Power Supply Units (PSU)
2 Rear Vent
3 I/O Shield (depends on the speci cation of the server board)
4 2 x PCI Express Slots (for the riser cards)
5 1 x OCP NIC 3.0 Slot (supports up to PCIE Gen5 device)
www.asrockrack.com
Control Panel
3
LEFT SIDE
2
4
1
6
8
No. Description
1 USB 3.2 Gen1 Port
2 System Reset Button
3 NMI (Nonmaskable Interrupt) Button
4 Power Button and LED
5 ID Button and LED
6 HDD Status LED
7 System Status LED
8 LAN1 and Activity LED
9 LAN2 and Activity LED
4 5 6
No. Description
5 10G LAN RJ-45 Port (LAN3)
6 10G LAN RJ-45 Port (LAN4)
7 VGA Port (VGA)
8 UID Switch (UID)
2 3 4
RIGHT SIDE
3
RST NMI
5
ID
7 5
9 5
L1 L2
8
5
