Quick Installation Guide
Mezzanine Card Series
Introduction
hank you for purchasing ASRock Rack mezzanine card, a reliable mezzanine card
produced under ASRock Rack's consistently stringent quality control. It delivers excellent
performance with robust design conforming to ASRock Rack's commitment to quality and
endurance.
Model Dimension
M350 2.7'' x 4.3''
(6.8 cm x 10.9 cm)
M540 2.7'' x 4.3''
(6.8 cm x 10.9 cm)
M599 2.7'' x 4.3''
(6.8 cm x 10.9 cm)
M350R 2.7'' x 4.3''
(6.8 cm x 10.9 cm)
M540R 2.7'' x 4.3''
(6.8 cm x 10.9 cm)
M599R 2.7'' x 4.3''
(6.8 cm x 10.9 cm)
M710 2.7'' x 4.3''
(6.8 cm x 10.9 cm)
M710S 2.7'' x 4.3''
(6.8 cm x 10.9 cm)
MCX3 2.7'' x 4.3''
(6.8 cm x 10.9 cm)
Interface LAN Controller
Gigabit LAN 1 x Intel® i350
10/100/1000 Mb/s
10G/1G/100M/s 1 x Intel® X540
10G/s 1 x Intel® 82599ES
Gigabit LAN 1 x Intel® i350
10/100/1000 Mb/s
10G/1G/100M/s 1 x Intel® X540
10G/s 1 x Intel® 82599ES
10/40Gb/s 1 x Intel® XL710-AM2
10/40Gb/s 1 x Intel® XL710-AM1
10/40Gb/s 1 x Mellanox ConnectX®-3
Pro EN
LAN Connector
2 x RJ45
2 x RJ45 (10G Base-T)
2 x SFP+ (Fiber)
2 x RJ45
2 x RJ45 (10G Base-T)
2 x SFP+ (Fiber)
2 x QSFP+ 40Gb/s
1 x QSFP+ 40Gb/s
2 x QSFP+ 40Gb/s
