ASROCK Rack GENOA2D16NQM3-2Q Quick Installation Manual

*15G065327000AK*
P/N: 15G065327000AK V1.0
Quick Installation Guide
GENOA2D16NQM3-2Q
The server board User's Manual is available for download from the ASRock Rack's official website
at http://www.asrockrack.com.
Take note of the following precautions before installing server board components or change any
server board settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the server board's components due to static electricity, NEVER place the
server board directly on the carpet or the like. Also remember to use a grounded wrist strap or
touch a safety grounded object before handling the components.
3. Hold components by the edges and do not touch the ICs.
4. Whenever uninstall any component, place it on a grounded anti-static pad or in the bag that
comes with the component.
5. When placing screws into the screw holes to secure the server board to the chassis, please do
not over-tighten the screws! Doing so may damage the server board.
2 Motherboard Layout
1 2 3 4
52 IPMB1
FAN4 FAN3
PSU_SMB1
BMC_SMB1
51
NMI_BTN1
SFP_CON1
LAN1
SFP_CON2
LAN2
50
NCSI_SEL1
UBM_SEL1
IPMI_LAN1
49
48
ASPEED
AST2600
USB3.2 Gen1 Ports
(USB3_1)
47
USB3.2 Gen1 Ports
(USB3_2)
46
COM1
Dr. Debug
UID1
45
44
43
42
41
FAN8 FAN7 FAN6
+12VSB_SEL1
40 39 38 37
3 I/O Panel
1 2 3
No. Description
1 25G SFP28 (Fiber) (SFP_CON1)
2 25G SFP28 (Fiber) (SFP_CON2)
3 IPMI LAN Header (IPMI_LAN1)
4 VGA Port (VGA)
4 Jumper Cap On/Off
5 6 7 8 9 10
DDR5_K1
MCIO6
FAN2 FAN1 DDR5_I1
12V_1
DDR5_H1
MCIO5
DDR5_G1
TPM_BIOS_PH1
DDR5_A1
DDR5_B1
MCIO8
DDR5_C1
DDR5_E1
MCIO7
DDR5_W1
DDR5_U1
DDR5_T1
DDR5_S1
PCIE6
DDR5_M1
MCIO4
DDR5_N1
DDR5_O1
MCIO3
FAN5
DDR5_Q1
34
36 35 33 32
5 6
4
No. Description
5 USB3.2 Gen1 Port (USB3_1)
6 USB3.2 Gen1 Port (USB3_2)
7 UID Switch (UID1)
When the jumper cap is placed on the pins, the
jumper is "Short". If no jumper cap is placed on the
pins, the jumper is "Open".
The illustration shows a 3-pin jumper whose pin1
and pin2 are "Short" when a jumper cap is placed
on these 2 pins.
1 Install the Server Board
1
Insert the server board into the chassis.
2
A f f i x t he screws clock w ise into t he
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws
11 12 13
35.56 cm (14in)
PWM_CFG1
CPU_HSBP1
MCIO1
CPU0
ATX6PIN1
12V_2
CLRMOS1
BAT1
USB3_1_2
12V_3
CPU1
SATA_SGPIO1
SATA_SGPIO2
MCIO2
PANEL1
AUX_PANEL1
31 30
No. Description
37 System Fan Connector (FAN6)
38 System Fan Connector (FAN7)
39 System Fan Connector (FAN8)
OCP3 +12VSB Power Jumper
40
7 (+12VSB_SEL1)
41 OCP NIC 3.0 Slot (PCIe5.0 x16) (OCP1)
42 PCI Express 5.0 x16 Slot (PCIE6)
43 Mini Cool Edge IO x8 Connector (MCIO7)
44 M.2 Socket (M2_1) (Type 2280)
45 M.2 Socket (M2_2) (Type 2280)
46 COM Port Header (COM1)
47 Mini Cool Edge IO x8 Connector (MCIO8)
48 Front VGA Header (FRNT_VGA1)
49 NCSI Mode Jumper (NCSI_SEL1)
50 UBM Mode Jumper (UBM_SEL1)
Non Maskable Interrupt Button
51
(NMI_BTN1)
52 BMC SMBus Header (BMC_SMB1)
www.asrockrack.com
GENOA2D16NQM3-2Q
No. Description
Intelligent Platform Management Bus Header
1
(IPMB1)
2 PSU SMBus Header (PSU_SMB1)
14
3 System Fan Connector (FAN4)
15
4 System Fan Connector (FAN3)
16
5 System Fan Connector (FAN2)
6 System Fan Connector (FAN1)
7 SPI TPM Header (TPM_BIOS_PH1)
8 ATX 12V Power Connectors (12V_1)
9 Mini Cool Edge IO x8 Connector (MCIO5)
10 Mini Cool Edge IO x8 Connector (MCIO6)
17
18
2 x 288-pin DDR5 DIMM Slots
19
11
(DDR5_H1, DDR5_K1)
20
21
Backplane PCI Express Hot-Plug Connector
12
(CPU_HSBP1)
22
23
PWM Configuration Header
24
13
(PWM_CFG1)
25
2 x 288-pin DDR5 DIMM Slots
14
(DDR5_G1, DDR5_I1)
15 Mini Cool Edge IO x8 Connector (MCIO1)
16 AMD Socket SP5 (SM-LGA-6096) (CPU0)
2 x 288-pin DDR5 DIMM Slots
17
(DDR5_A1, DDR5_C1)
26
27 Micro-Fit ATX 6Pin Power Connector
18
(ATX6PIN1)
28
29
2 x 288-pin DDR5 DIMM Slots
19
(DDR5_B1, DDR5_E1)
20 ATX 12V Power Connectors (12V_2)
21 Clear CMOS Pad (CLRMOS1)
22 USB 3.2 Gen1 Header (USB3_1_2)
2 x 288-pin DDR5 DIMM Slots
23
(DDR5_T1, DDR5_W1)
24 ATX 12V Power Connectors (12V_3)
2 x 288-pin DDR5 DIMM Slots
25
(DDR5_S1, DDR5_U1)
26 SATA SGPIO Connector (SATA_SGPIO1)
27 SATA SGPIO Connector (SATA_SGPIO2)
28 Mini Cool Edge IO x8 Connector (MCIO2)
29 System Panel Header (PANEL1)
30 Auxiliary Panel Header (AUX_PANEL1)
31 AMD Socket SP5 (SM-LGA-6096) (CPU1)
2 x 288-pin DDR5 DIMM Slots
32
(DDR5_N1, DDR5_Q1)
2 x 288-pin DDR5 DIMM Slots
33
(DDR5_M1, DDR5_O1)
34 Mini Cool Edge IO x8 Connector (MCIO4)
35 Mini Cool Edge IO x8 Connector (MCIO3)
36 System Fan Connector (FAN5)
