ASROCK Rack EP2C621D12 WS Quick Installation Manual

*15G065120000AK*
P/N: 15G065120000AK V1.0
Quick Installation Guide
EP2C621D12 WS
The server board User's Manual is available for download from the ASRock Rack's official website
at http://www.asrockrack.com.
Take note of the following precautions before you install server board components or change any
server board settings.
1. Unplug the power cord from the wall socket before touching any components.
2. To avoid damaging the server board's components due to static electricity, NEVER place your
server board directly on the carpet or the like. Also remember to use a grounded wrist strap or
touch a safety grounded object before you handle the components.
3. Hold components by the edges and do not touch the ICs.
4. Whenever you uninstall any component, place it on a grounded anti-static pad or in the bag
that comes with the component.
5. When placing screws into the screw holes to secure the server board to the chassis, please do
not over-tighten the screws! Doing so may damage the server board.
2 Motherboard Layout
1 2
CPU2_FAN1
DDR4_L1 (64 bit, 288-pin module, Blue)
DDR4_K1 (64 bit, 2
DDR4_J1 (64 bit, 2
USB 3.0
T: USB1
B: USB2
56
DDR4_G1 (64 bit, 2
DDR4_H1 (64 bit, 2
55
DDR4_I1 (64 bit, 2
REAR_FAN1
54
Super
PCIE7
(Blue)
I/O
53
52
PCIE6
(White)
51
PCIE5
(Blue)
BMC
EP2C621D12 WS
PCIE4
(White)
NMI_BTN1
50
1
PCIE3
(White)
BMC
ROM
PCIE2
(Blue)
49
PCIE1
(White)
48
SPEAKER1
COM1 1
HD_AUDIO1
IPMB_1
FRNT_VGA1 BMC_SMB_1
1
1
1
47 46 45 44 43 42
3 I/O Panel
3
1 2
No. Description No. Description
1 VGA Port (VGA1) 6
2 USB 3.0 Ports (USB3_1_2) 7
3 LAN RJ-45 Port (IPMI_LAN) 8
4 GLAN RJ-45 Port (LAN1) 9
5 GLAN RJ-45 Port (LAN2) 10
3
33.0cm (13.0 in)
ATX12V2
88 -pin module, Blue )
88 -pin module, Blue)
CPU2
88 -pin module, Blue)
88 -pin module, Blue)
88 -pin module, Blue)
RoHS
BATTERY1
BIOS
ROM
ME_RECOVERY1
FRONT_LED_LAN1
1
1
USB2_1 USB3_5_6
AUX_PANEL1
TPM1
USB3_1
1
1 1
41 40 39 38 37 36
10
7
5 9
4 8
6
GLAN RJ-45 Port (LAN3)
GLAN RJ-45 Port (LAN4)
Microphone (Pink)
Front Speaker (Lime)
Line In (Light Blue)
1 Install the Server Board
1
Insert the server board into the chassis.
2
A f f i x t he screws clock w ise into t he
mounting holes in all of the corners of
the server board.
Do not over-tighten the screws
4 5
ATXPWR1
ATX12V1
DDR4_C1 (64 bit, 288-pin module, Blue )
DDR4_B1 (64 bit, 288-pin module, Blue)
DDR4_A1 (64 bit, 288-pin module, Blue)
CPU1
DDR4_D1 (64 bit, 288-pin module, Blue)
DDR4_E1 (64 bit, 288-pin module, Blue )
DDR4_F1 (64 bit, 288-pin module, Blue)
CPU1_FAN1
PWM_CFG1
1
FRNT_FAN1
RAID_1
1
FRNT_FAN2
FRNT_FAN3
NUT30_1 NUT42_1 NUT60_1 NUT80_1
FRNT_FAN4
PLED PWRBTN
PANEL1
1
HDLED RESET
Intel
C621
CHASSIS_ID2
CHASSIS_ID1
CHASSIS_ID0
SSATA_SGPIO1 SATA_SGPIO1 SATA_SGPIO2
1
1
1
M2_2
1 1 1
SSATA_1 SSATA_0 SSATA_2
SATAPWR1 SATAPWR2
SSATA_3
1 1
35 34 33 32 31 30 29 28 27 26 25
4 Jumper Cap On/Off
When the jumper cap is placed on the pins, the jumper is
"Short". If no jumper cap is placed on the pins, the jumper
is "Open".
The illustration shows a 3-pin jumper whose pin1 and pin2
are "Short" when a jumper cap is placed on these 2 pins.
www.asrockrack.com
3 x 288-pin DDR4 DIMM Slots (DDR4_J1, DDR4_
1
K1, DDR4_L1)
2 CPU2 Fan Connector (CPU2_FAN1)
3 ATX 12V Power Connector (ATX12V2)
4 ATX 12V Power Connector (ATX12V1)
PSU_SMB1
5 ATX Power Connector (ATXPWR1)
6
6 PSU SMBus Header (PSU_SMB1)
7 3 x 288-pin DDR4 DIMM Slots (DDR4_A1,
7
DDR4_B1, DDR4_C1)
8 LGA 3647 CPU Socket (CPU1)
3 x 288-pin DDR4 DIMM Slots (DDR4_D1,
9
8
DDR4_E1, DDR4_F1)
10 CPU1 Fan Connector (CPU1_FAN1)
11 Front Fan Connector (FRNT_FAN1)
12 Front Fan Connector (FRNT_FAN2)
13 Front Fan Connector (FRNT_FAN3)
14 Front Fan Connector (FRNT_FAN4)
15 System Panel Header (PANEL1)
16 SATA3 Connector (SATA_6), White
9
17 SATA3 Connector (SATA_7), White
18 SATA3 Connector (SATA_4), White
10
19 SATA3 Connector (SATA_5), White
11
20 SATA3 Connector (SATA_2), White
12
21 SATA3 Connector (SATA_3), White
13
22 SATA3 Connector (SATA_0), White
14 23 SATA3 Connector (SATA_1), White
15
24 SATA3 DOM Connector (SSATA_3), Red
25 SATA DOM Power Jumper (SATAPWR2)
16
26 M.2 Socket (M2_2) (Type 2230 / 2242 / 2260 / 2280)
17
27 SATA DOM Power Jumper (SATAPWR1)
18
28 SATA3 DOM Connector (SSATA_2), Red
19
29 Chassis ID1 Jumper (CHASSIS_ID1)
20
30 Chassis ID0 Jumper (CHASSIS_ID0)
21
31 Chassis ID2 Jumper (CHASSIS_ID2)
22
32 SATA3 Connector (SSATA_0), White
23
24
33 SATA SGPIO Connector (SATA_SGPIO1)
34 SATA3 Connector (SSATA_1), White
35 SATA SGPIO Connector (SSATA_SGPIO1)
36 USB 3.0 Header (USB3_5_6)
37 ME Recovery Jumper (ME_RECOVERY1)
38 Vertical Type A USB 3.0 (USB3_1)
39 USB 2.0 Header (USB2_1)
40 TPM Header (TPM1)
41 Auxiliary Panel Header (AUX_PANEL1)
42 Speaker Header (SPEAKER1)
Intelligent Platform Management Bus header
43
(IPMB_1)
44 BMC SMBus Header (BMC_SMB_1)
45 Front VGA Header (FRNT_VGA1)
46 Serial Port Header (COM1)
47 Front Panel Audio Header (HD_AUDIO1)
48 Front LAN LED Connector (FRONT_LED_LAN1)
49 SATA SGPIO Connector (SATA_SGPIO2)
50 Non Maskable Interrupt Button (NMI_BTN1)
51 M.2 Socket (M2_1) (Type 2230 / 2242 / 2260 / 2280)
52 Virtual RAID On CPU Header (RAID_1)
53 PWM Configuration Header (PWM_CFG1)
3 x 288-pin DDR4 DIMM Slots (DDR4_G1,
54
DDR4_H1, DDR4_I1)
55 Rear Fan Connector (REAR_FAN1)
56 LGA 3647 CPU Socket (CPU2)
