F E A T U R E C A B I N E T
Base Cabinet
Open Base/Wine Rack (Solid Top, 4 Legs) - Fitting Guide
Open
Base
Cabinet Parts
28x 5/8"
4x 1 1/4"
Screws
Screws
Tools Required
Drill
Stud Finder
Remember to take care when unpacking. Please keep your workspace clean,
clear, and tidy when working. This will help keep all items safe from damage. Any
waste cardboard or plastic should be flattened down and placed in the trash can.
A minimum of two people will be needed to lift the cabinet.
4x
2x
Legs
Toe Kick Clips
Screwdriver
Wine
Rack
8x
Cover Caps
Shelf Pegs
Clamp
Spirit Level
2x
Shelves
L-brackets
Tape Measure
Page 1
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Wren Kitchens Feature Open Base Cabinet
Summary of Contents for Wren Kitchens Feature Open Base Cabinet
- Page 1 F E A T U R E C A B I N E T Base Cabinet Open Base/Wine Rack (Solid Top, 4 Legs) - Fitting Guide Open Wine Base Rack Cabinet Parts 28x 5/8” 4x 1 1/4” Screws Screws Legs Toe Kick Clips Cover Caps Shelf Pegs...
- Page 2 Unpacking the parts and fittings Remove all content from the packaging and ensure that you familiarize yourself with all cabinet parts and fittings. All parts and fittings should be kept on a clean, level surface, and the frontal and shelf should be placed in the door safe along its longest length.
- Page 3 Please note that the open wine rack cabinets have fixed shelf heights that cannot be adjusted. Finding the shelf height Position the shelf pegs into the pre-drilled holes. The shelf can be positioned at 3 different heights, as shown in the image. Place the shelf in position so the pin of the shelf peg is inserted into the pre-drilled holes.
- Page 4 Securing the decor panel to the cabinet (if required) Clamp together the decor panel with the cabinet, checking the front edges are level and flush. Using the screws provided, 1 1/4” screws should be fixed alongside the shelf pegs at the top and bottom of the cabinet.
- Page 5 Sealing the decor panel Using silicone, seal the edges of the decor panel along the floor and wall. Remove the clamps. The following steps are for cabinets that require securing to the wall. Creating the pilot holes Drill small pilot holes through the back panel of the cabinet.
- Page 6 No screws or wall plugs are provided for attaching the cabinet to the wall. This is due to variations in wall construction. Before drilling into the wall, you MUST check for any hidden services or pipework within the walls. Fixing the cabinet to the wall Fix to the wall through the pilot holes using the appropriate screws and fixings.
