CHARACTERISTICS:
The HD67C07-xxx-x-xxx-B2 is a Modbus TCP Slave / MQTT Broker Converter.
It allows the following characteristics:
Electrical isolation between Ethernet and Power Supply;
Mountable on 35mm Rail DIN;
Wide power supply input range: 12...35V DC and 8...24V AC;
Wide temperature range: -40°C / 85°C [-40°F / +185°F].
CONFIGURATION:
You need Compositor SW67C07 software on your PC in order to perform the following:
Define the parameter of MQTT;
Define the parameter of Modbus TCP line;
Define the list of allowed MQTT Clients;
Define the list of MQTT topic published and subscribed from/to Modbus TCP;
Define the list of topics to be forwarded via the internal bridge;
Update the device.
