In the field "IP Address", the IP address of the converter is defined;
In the field "SubNet Mask" the Subnet Mask of the converter is defined;
In the field "Gateway" the default gateway of the network is defined. This feature can be enabled or disabled pressing the Check Box
field;
In the field "DNS" the IP Address of the DNS server is defined. This feature can be enabled or disabled pressing the Check Box field.
MQTT B  MQTT B
ROKER ROKER
This section is used to define the general parameters of the MQTT broker. The means of the fields are:
In the field "Port" the TCP port used for MQTT connection is defined;
In the field "TLS Certificate" it is possible to import a certificate for the broker and use TLS protocol;
In the field "TLS Key" it is possible to import the private key of the broker for TLS protocol;
In the field "Client Authentication CA
keys for the Clients;
In the field "Client Persistance
MQTT B  NTP (N
ROKER ETWORK
This section is used to define the NTP parameters. The means of the fields are:
In the field "Server URL" the NTP address is defined.
MQTT B  M I
ROKER OBILE NTERNET
This section is used to define the main parameters of LTE connectivity. The means of the fields are:
If the field "Enable Physical SIM" is checked, the SIM slot is enabled;
In the field "PIN" the PIN code of the SIM card is defined;
In the field "APN" the APN for mobile connection is defined;
In the field "Username" the user for mobile connection is defined;
In the field "Password" the password for mobile connection is defined;
ADFweb.com S.r.l.
:
Cert." it is possible to import the CA certificate used to generate the Certificates and Private
[Hours]" the amount of hours before a Client section expires is defined.
