If the field "TLS" is checked, the TLS protocol for secure connection is enabled;
If the field "Insecure" is checked, the validity of the server certificate will not been verified;
In the field "CA Certificate" the .pem CA Certificate of the remote broker/server used to open a secure connection is defined;
In the field "Client Certificate" the .pem Client's Certificate is defined;
In the field "Private Key" the corresponding .pem Client's Certificate key is defined;
In the field "Mnemonic" a description of the topic is defined.
In the second table, it is possible create the list of the topics in publish and subscribe to the remote broker. The means of the fields are:
If the field "Enable" is checked, the MQTT topic is enabled;
In the field "Local Topic" the name of the local topic to link to the remote topic is defined;
In the field "Remote Topic" the name of the remote topic to link to the local topic is defined;
In the field "Direction" it is possible to select the allowed access for the defined topic. It is possible to have:
IN: the topic can be only subscribed;
o
OUT: the topic can be only published;
o
BOTH: the topic can be published and subscribed.
o
In the field "QoS" the QoS level is defined;
In the field "Mnemonic" a description for the topic is defined.
