UPDATE DEVICE:
By pressing the "Update Device" button, it is possible to load the created
Configuration into the device; and also the Firmware, if necessary. This by using the
Ethernet port.
If you don't know the actual IP address of the device you have to use this procedure:
Turn ON the device
Connect the Ethernet cable;
Insert the IP Address of the converter (if not known, it is possible to use
"ADFweb Discovery Tool" to find it);
Press the "Execute update
When all the operations are "OK" turn OFF the Device;
Close the updating windows and wait for restarting.
At this point the configuration/firmware on the device is correctly updated.
ADFweb.com S.r.l.
firmware" button to start the upload;
User Manual Modbus TCP Slave / MQTT Broker
Document code: MN67C07_ENG Revision 1.000
Figure 6: "Update device" windows
