2 O
VERVIEW
2.1 Standard Features MSM286X / L:
The MICROSPACE MSM286 is a miniaturized modular device incorporating the major elements of a
PC/AT compatible computer. It includes standard PC/AT compatible elements, such as:
MSM286X142
MSM286X142:
functions
Low power F8680A CPU with 14 MHz
BIOS ROM
DRAM 1 or 2 MBytes 70ns
Timers
DMA
Real time clock with battery buffer
LPT1 parallel port
COM1 / COM2 and optional COM3 serial port
Speaker interface
XT-keyboard interface
Floppy disk interface
AT-IDE harddisk interface
CGA/LCD video interface
AT-PC/104 BUS
2.2 Unique Features MSM286:
The MICROSPACE MSM286 includes all standard PC/AT functions plus unique Digital-Logic en-
hancements, such as:
MSM286X142
Solid state disk (SSD) 1 MByte
LCD interface with power supply for LCD-BIAS
(-15 to -25Volt adjustable)
Low power, less than 1 W
Single 5 volt supply
PCCARD 1.0 (SRAM)
Memory card interface 16 MBytes
Direct scanned keymatrix (8 x 8)
SuperState R Features of PC/Chip
Watchdog timer
Power-fail
Standard with full
MSM286L1405
MSM286L1405
version
Low Power F8680A CPU with 14 MHz
BIOS ROM
0.5 MByte DRAM
Timers
DMA
Real time clock with battery buffer
no LPT1
COM1
Speaker
XT-keyboard interface
no Floppy
no IDE
CGA/LCD video interface
XT-PC/104 BUS
MSM286L1405
Solid state disk (SSD) 1 MByte
LCD Interface
Low power, less than 0.7 W
Single 5 volt supply
PCCARD 1.0 (SRAM)
Direct scanned keymatrix (8x8)
SuperState R Features of PC/Chip
Watchdog timer
Power-fail
8
MSM286 Manual V6.4
Low functions, low-cost
