9.2 The SuperState BIOS - SETUP (F8680.EXE)
The system configuration program, F8680.EXE, is used to setup the various parameters of the F8680
PC/Chip in addition to the Standard-Setup Menu in the BIOS.
A wrong parameter could hang the system or produce malfunctions. In this case RESET THE CMOS
RAM by closing the appropriate jumper for 1 -2 seconds and during the system power is on.
The setup program F8680.EXE is on the utility disk shipped with your documentation for the
MICROSPACE MSM286 PC. To run the setup program, you will need a CRT or LCD, keyboard and a
floppy drive. The F8680.EXE can then be placed in ROM-DOS, on the solid state disk, or on the hard
drive, if desired.
After starting the program (modify the parameters with cursor up/down or space key, accept with enter):
CMOS Entry validation:
External Keyboard Scanner Enable:
CPU Performance reduction (for power saving): none, 10%, 20%, .....
Emulation 286 Flag:
Power OFF Controls:
Blink rate at LCD Displays:
Double Scan control:
LCD Panning Control:
BUS Speed selection:
Graphic Configuration:
and more.....
YES
NO
Scanner ON or OFF
Consult the F8680 Datasheet
None, powersave with pos. or neg. signals on PUP Line
Character / Cursor (fast, 75%, half, 25%, slow)
ON
OFF
for small LCD panning enter the row offset 0-127
3 CPUCLK's per BUS Clock
refer to the F8680 Datasheet
Confirm the Update or leave the F8680.EXE program
= the following parameters are valid
= the following parameters are not valid
(works since V1.4.1.)
= 400 x 640 LCD's
= 200 x 640 LCD's
