11.6 The COM 1/2 serial interface cable
IDT terminal for dual row 0.1" (2.54 mm grid) and 1.27 mm flat cable
ATTENTION:
- Do not short-circuit these signal lines.
- Never connect any pins either on the same plug or to any other plug on the MICROSPACE.
The +/-10Volt will destroy the MICROSPACE core logic immediately. No warranty in this case.
- Do not apply power to this lines.
- Do not overload the output: max. output current of Maxim converters: 10 mA
11.7 The printer interface cable
IDT terminal for dual row 0.1" (2.54mm grid) and 1.27 mm flat cable
ATTENTION:
- Maximum length of this cable is 6 meters.
- Prevent short-circuits.
- Apply never power to these signals, the MICROSPACE MSM286 will be destroyed.
Line of pin 1
1 2
MSE286
MSE3/486
COM1/2
19 20
Parallelport Cable LPT1
1
6
2
COM1
7
9pin D-Sub
3
male
8
4
9
5
1
6
2
COM2
7
9pin D-Sub
3
male
8
4
9
5
1
14
2
15
24
12
25
13
49
