Physical characteristics:
Dimensions:
Weight:
PCB thickness:
PCB layer:
Operating environment:
Relative humidity:
Vibration:
Shock:
Temperature:
EMV / EMC (IEC1131-2 refer MIL 461/462):
ESD Electro Static Discharge:
REF Radiated Electromagnetic Field:
EFT Electric Fast Transient: (Burst)
SIR Surge Immunity Requirements:
High-frequency Radiation:
Any information is subject to change without notice.
Length: 96mm / 3,8"
Width: 90mm / 3,6"
Height: 15mm / 0.6"
with MSM353: 25mm / 1.0"
120 gr / 4.5 ounces
1.6 mm / 0.0625 inches nominal
8 with ground plane for low noise
5 - 90% non condensing, RH-2
5 to 2000 Hz, 2G, DIN IEC 68-2-6
10G, DIN IEC 68-2-27
Operating: Standard version:
Industry version:
Storage: -55°C to +85°C
IEC 801-2, EN55101-2, VDE 0843/0847 Part 2
metallic protection needed
separate Ground Layer included
15kV single peak
IEC 801-3, VDE 0843 Part 3, IEC770 6.2.9.
not tested
IEC 801-4, EN50082-1, VDE 0843 Part 4
250V - 4kV, 50 ohms, Ts=5ns
Grade 2: 1KV Supply, 500 I/O, 5Khz
IEC 801-5, IEEE587, VDE 0843 Part 5
Supply:
I/O:
FD, CRT:
EN55022
12
MSM286 Manual V6.4
-25°C to +70°C
ask Digital-Logic AG
2 kV, 6 pulse/minute
500 V, 2 pulse/minute
none
