Mass storage:
FD:
HD:
Sockets SSD:
1st socket for SSD:
2nd socket for SSD:
PCCARD:
Memory CARD:
Standard AT interfaces:
Serial:
Parallel:
Keyboard:
Speaker:
RTC:
Enhanced Interfaces:
Video:
Keyboard:
Supervisory:
Watchdog:
BUS:
MSM286 PC/104
Clock:
Local Bus:
MSM-Local:
Clock:
Peripheral Extension:
MSM286:
Power Supply:
Working:
Floppy disk interface, for max. 2 floppies, 26 and 34 pins connector
IDE controller onboard but needs MSM5xxI or IV Piggyback board to
interface IDE 44pins drives
1 - 8 MBit, EPROM
1 - 8 MBit Flash, EPROM
SRAM only
Controller onboard but needs MSM286J to interface the PCCARD-
slot
COM1 and COM2
COM3
(onboard +/- 9 Volt supply)
(Baudrates: 50 - 115000 Baud programmable)
LPT1 Printer interface bi-directionally (Centronics)
XT-Keyboard
0.1 W output drive
146818A compatible RTC with CMOS-RAM 128Byte
LCD interface (with PS4 = low )
Resolution: 64 x 128 up to 400 x 640 pixel
CGA interface (with PS4 = high)
Resolution: 640 x 200 pixel 4 colors
Userdefined Keyboardmatrix
Definition of the keymatrix with KEYEDIT
LTC1232 with power-fail detection
IEEE-996 standard bus, by Ampro for PC/104 6 mA drive
8 MHz or programmable
XT-Local BUS for extension to MSM5xxIV
8 MHz
PC/104 BUS
5 Volts / 1 W
11
MSM286 Manual V6.4
PLCC32
DIL32
(V24 / RS232C)
(RS485)
( 8 x 8 matrix)
BIOS
SSD
