DIGITAL-LOGIC MICROSPACE MSM286 Series Technical User's Manual page 34

DIGITAL-LOGIC AG
J33/J34 PCCARD Bus on the MSM286
Pin
Pin 1
Pin 2
Pin 3
Pin 4
Pin 5
Pin 6
Pin 7
Pin 8
Pin 9
Pin 10
Pin 11
Pin 12
Pin 13
Pin 14
Pin 15
Pin 16
Pin 17
Pin 18
Pin 19
Pin 20
Pin 21
Pin 22
Pin 23
Pin 24
Pin 25
Pin 26
Pin 27
Pin 28
Pin 29
Pin 30
Pin 31
Pin 32
Needs the option MSM286J for connecting a socket holder for PCCARDs to the MSM286 board. Ask
your nearest DIGITAL-LOGIC AG service.
Row A:
IOCS16
D7
D6
D5
D4
D3
D2
D1
D0
IORDY
AEN
A19
A18
A17
A16
A15
A14
A13
A12
A11
A10
A9
A8
A7
A6
A5
A4
A3
A2
A1
A0
GND
34
MSM286 Manual V6.4
Row B:
VCC
JEIDA-CS
PS2
PS3
MCR
CARDB
VPP (Programming voltage)
W0 (Write enable)
O0 (Read enable)
REFRESH
IOW
IOR
MCC2
MCC1
MCB2
MCB1
A25
A24
A23
A22
A21
A20
MCD1
MCD2
D8
D9
D10
D11
D12
D13
D14
D15
