Roller Cabinet Parts List DX552508RC Replacement keys may be ordered using the code that appears on the face of the lock. To order replacement parts, have the part number, tool box and drawer pull color and quantity ready. If under warranty, the serial number is REQUIRED to get replacement parts.
Page 3
Roller Cabinet Parts List DX552508RC Item # Part number Descriptions ZDRD1305E2QWKR DX5525RC Drawer 1305 mm Wide, Double Deep, 100 Lb Slides, Black with Red Drawer Pulls ZDRD1305E2QWKU DX5525RC Drawer 1305 mm Wide, Double Deep, 100 Lb Slides, Black with Blue Drawer Pulls...
Page 4
ZDPDQ864K DX5525RC Quick Release Drawer Pull, C Shape 864 mm, Powder Coat Black ZSLW530F520 100 lb Drawer Slide set 12 sets Z-LGS Extreme Tools name plate Z-LGL Extreme Tools Logo ZM6SCHX-15 RX series drawer handle screws ZDL1278X559 PVC Drawer liner, large, 1278x559, PVC, Black...
ASSEMBLY Handle Installation NOTE: Assemble the handle first to make it easier to move the tool cabinet. Position the handle over the holes in the cabinet and attach with the provided (4) M6 hex head screws. Tighten securely. OPERATING PROCEDURE Drawer Removal Pull drawer out so that it is almost fully extended.
MAINTENANCE Lubricate the casters once a year with high quality ball bearing grease. Wear safety glasses and lubricate the slides twice a year with high quality, petroleum-based lubricant. This may be required more often If operating the tool box in colder climates. Use mild detergent and water to clean drawer fronts, drawer trim and other surfaces.
