IASO-W08PLED-N6210 Panel PC
MODEL:
IASO-W08PLED-N6210
8" Panel PC with Intel® Celeron® Processor N6210,
P-CAP Touchscreen, 8 GB LPDDR4x, 128GB eMMC,
USB 3.2 Gen 1, 1GbE, PoE, Audio and RoHS
User Manual
Page i
Rev. 1.01 - February 24, 2025
[MODEL NAME]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IASO-W08PLED-N6210 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for IEI Technology IASO-W08PLED-N6210

Summary of Contents for IEI Technology IASO-W08PLED-N6210

  • Page 1 IASO-W08PLED-N6210 Panel PC MODEL: IASO-W08PLED-N6210 8" Panel PC with Intel® Celeron® Processor N6210, P-CAP Touchscreen, 8 GB LPDDR4x, 128GB eMMC, USB 3.2 Gen 1, 1GbE, PoE, Audio and RoHS User Manual Page i Rev. 1.01 - February 24, 2025 [MODEL NAME]...
  • Page 2 IASO-W08PLED-N6210 Panel PC Revision Date Version Changes March 7, 2025 1.00 Initial release February 24, 2025 1.01 Patch update Page ii [MODEL NAME]...

  • Page 3: Copyright Notice

    IASO-W08PLED-N6210 Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Manual Conventions

    IASO-W08PLED-N6210 Panel PC Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    IASO-W08PLED-N6210 Panel PC Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 F ........................3 EATURES 1.3 F ......................3 RONT ANEL 1.4 B ......................4 OTTOM ANEL 1.5 R ......................5 ANEL 1.6 S .................... 6...
  • Page 6 IASO-W08PLED-N6210 Panel PC 5.2.1.1 Install the Required Libraries ..............27 5.2.1.2 Driver Installation ..................28 5.3 LED C ..................29 ONTROL XAMPLE 5.3.1 Windows and Windows 11 ................29 5.3.1.1 Preparations:....................29 5.3.1.2 Call SMBus API (SMB_Open) and Initialize Required Data Structures.. 30 5.3.1.3 Initialize the LED Status ................
  • Page 7 IASO-W08PLED-N6210 Panel PC List of Figures Figure 1-1: IASO-W08PLED-N6210 Panel PC ................2 Figure 1-2: Front View ........................3 Figure 1-3: Bottom Panel ....................... 4 Figure 1-4: Rear View ........................5 Figure 1-5: Dimensions (mm) ......................9 Figure 3-1: Ethernet Connector ....................17 Figure 3-2: AT/ATX Switch Location ..................

  • Page 8: List Of Tables

    IASO-W08PLED-N6210 Panel PC List of Tables Table 1-1: System Specifications ....................8 Table 3-1: Ethernet Connector Pinouts ..................17 Table 3-2: Connector LEDs ......................17 Page viii [MODEL NAME]...

  • Page 9: Introduction

    IASO-W08PLED-N6210 Panel PC Chapter Introduction Page 1...

  • Page 10: Overview

    1.1 Overview Figure 1-1: IASO-W08PLED-N6210 Panel PC The IASO-W08PLED-N6210 is an Intel® Celeron® Processor N6210 powered panel PC designed for easy and simplified integration into healthcare applications. The system has onboard 8GB LPDDR4x memory and 128GB eMMC for storage and memory capacity.

  • Page 11: Features

    Two USB 3.2 Gen 1 (5Gb/s) ports 1.3 Front Panel The front side of the IASO-W08PLED-N6210 is a flat-bezel panel with an 8" LCD screen surrounded by an ABS/PC plastic frame. The LED bars are located on both sides of the front panel.

  • Page 12: Bottom Panel

    IASO-W08PLED-N6210 Panel PC 1.4 Bottom Panel The bottom panel of the IASO-W08PLED-N6210 has the following connectors and components (Figure 1-3): ▪ 1 x 12 V DC input jack (standard) ▪ 1 x 1GbE RJ-45 supporting PoE ▪ 2 x USB 3.2 Gen 1 connector (5Gb/s) ▪...

  • Page 13: Rear Panel

    IASO-W08PLED-N6210 Panel PC 1.5 Rear Panel The rear panel contains four retention screw holes that support VESA 75 mount (Figure 1-4). Figure 1-4: Rear View Page 5...

  • Page 14: System Specifications

    IASO-W08PLED-N6210 Panel PC 1.6 System Specifications The technical specifications for the IASO-W08PLED-N6210 systems are listed below. LCD and Touchscreen LCD Size 8" Max. Resolution 1280 (W) x 800 (H) Brightness (cd/m Contrast Ratio 800:1 LCD Color 16.7M Pixel Pitch (mm) 0.13455 (H) x 0.13455 (V)
  • Page 15 IASO-W08PLED-N6210 Panel PC 1 x 12V DC input jack 1 x 1GbE LAN (RJ-45) with PoE 2 x USB 3.2 Gen 1 (5Gb/s) Type-A 1 x Audio line-out jack I/O Ports & Buttons 1 x Reset button 1 x Clear CMOS button...
  • Page 16 IASO-W08PLED-N6210 Panel PC Thermal Fanless EMC & Safety CE, CB, FCC Class B Part15 Supported OS Windows 11, Linux Ubuntu Power Power Input 12 V DC IEEE 802.3af (Class 3) 12.95W / IEEE 802.3at (Class 4) 25.5W 36 W FSP FSP036-RHBN3 power adapter...

  • Page 17: Dimensions

    IASO-W08PLED-N6210 Panel PC 1.7 Dimensions The IASO-W08PLED-N6210 dimensions are shown below. Figure 1-5: Dimensions (mm) Page 9...

  • Page 18: Unpacking

    IASO-W08PLED-N6210 Panel PC Chapter Unpacking Page 10...

  • Page 19: Unpacking

    IASO-W08PLED-N6210 Panel PC 2.1 Unpacking To unpack the panel PC, follow the steps below: WARNING The front side LCD screen has a protective plastic cover stuck to the screen. Only remove the plastic cover after the panel PC has been properly installed.
  • Page 20 IASO-W08PLED-N6210 Panel PC The IASO-W08PLED-N6210 panel PC is shipped with the following components: Quantity Item Image IASO-W08PLED-N6210 panel PC Power adapter, 63040-010036-210-RS (FSP FSP036-RHBN3, 36W) Power cord (EU, 183cm)* Power cord (US/Canada, 183cm)* *Either one; shipped according to the country code of the order.

  • Page 21: Installation

    IASO-W08PLED-N6210 Panel PC Chapter Installation Page 13...

  • Page 22: Safety Precautions

    Electric shocks can occur if the IASO-W08PLED-N6210 chassis is opened ▪ when the IASO-W08PLED-N6210 is running. To avoid risk of electric shock, this equipment must only be connected to a supply mains with protective earth.

  • Page 23: Anti-Static Precautions

    W08PLED-N6210 and severe injury to the user. Electrostatic discharge (ESD) can cause serious damage to electronic components, including the IASO-W08PLED-N6210. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the IASO-W08PLED-N6210 is accessed internally, or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 24: Installation Precautions

    WARNING 1. DO NOT modify this equipment without authorization of manufacturer. 2. DO NOT power up the IASO-W08PLED-N6210 while the front panel is facing down on a sheet of conductive foam. Doing so may cause the touch panel to malfunction due to the large surface area of contact between the conductive form and the touch panel.

  • Page 25: Gbe Connection

    IASO-W08PLED-N6210 Panel PC 3.4 GbE Connection The RJ-45 connector on the bottom panel allows 1GbE connection to be made to a Local Area Network. It supports PoE and PoE+ functions. Connect the Ethernet (PoE) port to the inline power from the power injector or a suitably powered switch port. The Ethernet cable must be a shielded outdoor rated Category 5e (CAT5e), or better, cable.

  • Page 26: At/Atx Mode Selection

    IASO-W08PLED-N6210 Panel PC 3.5 AT/ATX Mode Selection AT or ATX power mode can be used on the IASO-W08PLED-N6210. The selection is made through an AT/ATX switch located on the bottom panel (Figure 3-2). Figure 3-2: AT/ATX Switch Location 3.6 VESA Mounting The IASO-W08PLED-N6210 is VESA (4 screws: M4 type, 6 mm length min.) compliant...

  • Page 27: Powering On The System

    Connect the power adapter to the power connector of the IASO-W08PLED-N6210. NOTE: The FSP036-RHBN3 power adapter came with the IASO-W08PLED-N6210 is a forming part of the device. Figure 3-4: Power Input Connector and Power Button Step 2: Locate the power button on the bottom panel (Figure 3-4).

  • Page 28: Clear Cmos

    Step 0: 3.8 Clear CMOS If the IASO-W08PLED-N6210 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, push the clear CMOS button for three seconds, then restart the system. The clear CMOS button location is shown in Figure 3-5.

  • Page 29: System Maintenance

    IASO-W08PLED-N6210 Panel PC 3.10 System Maintenance If the components of the IASO-W08PLED-N6210 fail, they must be replaced. Please contact the system reseller or vendor to purchase the replacement parts. NOTE: A user cannot replace a motherboard. If the motherboard fails it must be shipped back to IEI to be replaced.

  • Page 30: Driver Installation

    IASO-W08PLED-N6210 Panel PC Chapter Driver Installation Page 22...

  • Page 31: Available Drivers

    IASO-W08PLED-N6210 Panel PC 4.1 Available Drivers All the drivers for the IASO-W08PLED-N6210 are available on IEI Resource Download Center (https://download.ieiworld.com). Type IASO-W08PLED-N6210, and press Enter to find all the relevant software, utilities, and documentation. Figure 4-1: IEI Resource Download Center 4.2 Driver Download...
  • Page 32 IASO-W08PLED-N6210 Panel PC Step 3: Click the driver file name on the page and you will be prompted with the  following window. You can download the entire ISO file ( ), or click the small  arrow to find an individual driver and click the file name to download (...

  • Page 33: Led Bar Control

    IASO-W08PLED-N6210 Panel PC Chapter LED Bar Control Page 25...

  • Page 34: Overview

    IASO-W08PLED-N6210 Panel PC 5.1 Overview WARNING The LED light is only for aesthetic purpose, not for warning use. The LED color cannot be configured to red, yellow and green. This chapter provides detailed instructions on how to control the LED bar. It is organized...

  • Page 35: Preparations

    IASO-W08PLED-N6210 Panel PC LED Control on Ubuntu: Before proceeding with LED control on Ubuntu 22.04, make sure you have completed the necessary preparations. In Section 5.3.2, you will learn how to compile and run the LED control code on Ubuntu 22.04. Additionally, you will discover how to customize the LED control code according to your specific requirements.

  • Page 36: Driver Installation

    IASO-W08PLED-N6210 Panel PC Step 2: After installing the packages, restart your computer. 5.2.1.2 Driver Installation Follow the steps below to install the "IEISMBDrv" device driver (version 1.0.0.6). Make sure to follow each step carefully for a successful installation. Step 1: Open the command prompt in command line mode and run it as administrator.

  • Page 37: Led Control Example

    IASO-W08PLED-N6210 Panel PC IEI SMB Device Driver is v1.0.0.6: 5.3 LED Control Example 5.3.1 Windows and Windows 11 Use the following example program. For detailed information, please refer to the DemoLED_example.cpp file. 5.3.1.1 Preparations: Before proceeding, make sure to complete the following preparations: Step 1: Include the headers SMBAPI.h and LED.h (if using any necessary defines).

  • Page 38: Call Smbus Api (Smb_Open) And Initialize Required Data Structures

    IASO-W08PLED-N6210 Panel PC Step 3: Prepare the data structures: SMB_INFO and SMB_BLK_INFO. Refer to the example below: #include ".\your_folder\SMBAPI.h" #include ".\your_folder\LED.h" 5.3.1.2 Call SMBus API (SMB_Open) and Initialize Required Data Structures This function is used to open the SMBus driver. For detailed APIs and data structures, refer to the "SMB_API.doc"...

  • Page 39: Initialize The Led Status

    IASO-W08PLED-N6210 Panel PC 5.3.1.3 Initialize the LED Status To initialize the LED status, follow the steps below, which are divided into three sections. Each section includes the following sub-steps: (1) Set the values for address, data, and command. (2) Call the function `SMB_WriteByte()`.

  • Page 40: Write To Led

    IASO-W08PLED-N6210 Panel PC 5.3.1.4 Write to LED 5.3.1.4.1 Adjusting LED Brightness Ensure that the value provided for brightness is between 1 and 255. (1) Set the values for address and command. (2) Set data (Set the desired value for the LED brightness.) (3) Call the function `SMB_WriteByte()`.
  • Page 41 IASO-W08PLED-N6210 Panel PC SMB_BLK_INFO smbBlkInfo; smbBlkInfo.addr = 0xD0; smbBlkInfo.count = 15; smbBlkInfo.mode_i2c = 0; smbBlkInfo.command = 0xA1; Write RGB Data to `smbBlkInfo.data`. Step 2: Regarding RGB LED data and sequencing, the following information is provided: Data Source: The RGB data in the 'colorarray' mentioned here is simulated for a breathing (or color pattern) effect.
  • Page 42 IASO-W08PLED-N6210 Panel PC correspond to the LED bar on both sides of the Panel PC, arranged from top to bottom (synchronized on both sides). The configuration for different platforms: In the DemoLED_example.cpp file, the configuration of "is_reverse_led" and "is_separate_left_right" depends on the platform.
  • Page 43 IASO-W08PLED-N6210 Panel PC //for Left LED SMB_BLK_INFO smbBlkInfoLeft; smbBlkInfoLeft.addr = 0xC2; smbBlkInfoLeft.count = 15; smbBlkInfoLeft.mode_i2c = 0; smbBlkInfoLeft.command = 0xA1; for (int LED = 0; LED < 5; LED++) sh = (LED) * 3; if (is_reverse_led==true) i_led = 4 - LED;...
  • Page 44 IASO-W08PLED-N6210 Panel PC if (is_reverse_led==true) i_led = LED; else i_led = 4 - LED; smbBlkInfoRight.data[sh] = colorarrary[i_led].R; smbBlkInfoRight.data[sh + 1] = colorarrary[i_led].G; smbBlkInfoRight.data[sh + 2] = colorarrary[i_led].B; printf(" %d, %d, %d\n", colorarrary[i_led].R, colorarrary[i_led].G, colorarrary[i_led].B); For more detailed usage, please refer to the content of the DemoLED_example.cpp file.
  • Page 45 IASO-W08PLED-N6210 Panel PC Set Data: Set the desired value for the R, G, or B component of the Step 3: LED. Set Command: Select the appropriate command for the R, G, or B Step 4: component. Refer to the example below: SMB_INFO smbInfo;...

  • Page 46: Call The Smbus Api (Smb_Close) To Close The Connection

    IASO-W08PLED-N6210 Panel PC 5.3.1.5 Call the SMBus API (SMB_Close) to Close the Connection This function is used to close the SMBus driver. Refer to the example below: SMB_INFO smbInfo; smbInfo.addr = 0xD0; for (int ii = 0x14 ; ii <= 0x17 ; ii++) smbInfo.command = ii;...

  • Page 47: Ubuntu 22.04

    IASO-W08PLED-N6210 Panel PC 5.3.2 Ubuntu 22.04 Follow the instruction below to control the LED bar on Ubuntu 22.04. 5.3.2.1 Install Packages Ensure that you have the necessary files from the TLC_LED_TEST.tgz Step 1: archive. Install the required packages, i2c-tools and libi2c-dev, using the...

  • Page 48: Compile And Run

    IASO-W08PLED-N6210 Panel PC 5.3.2.2 Compile and Run Add the necessary includes in the main.c file. Step 1: Compile the code to create the 'main_app' executable. Step 2: # gcc -o main_app main.c -lic2 Run the executable file (main_app) as root.

  • Page 49: Changing Led Color

    IASO-W08PLED-N6210 Panel PC Changing LED Color 5.3.2.3 Set the REG_PWM0 register to 0xA1. Step 1: Set the desired values for the LED's R, G, and B components. Step 2: Please refer to the usage in the main_ubuntu.cpp file. Page 41...

  • Page 50: Os Version & Result

    IASO-W08PLED-N6210 Panel PC 5.3.2.4 OS Version & Result Page 42...

  • Page 51: Led Bar Demo App

    IASO-W08PLED-N6210 Panel PC 5.4 LED Bar Demo App In this Demo GUI App, we provide three examples of LED variations, including: 1. Color Cycling (Breathing Effect): This example demonstrates the gradual transition of the LED color from Color1 to Color2, and then back to Color1. To start the simulation, click the START button.
  • Page 52 IASO-W08PLED-N6210 Panel PC Pattern Display - Wavelike LED Variation Static Color - Changing the Color of a Single LED Page 44...

  • Page 53: Regulatory Compliance

    IASO-W08PLED-N6210 Panel PC Appendix Regulatory Compliance Page 45...

  • Page 54: Declaration Of Conformity

    IASO-W08PLED-N6210 Panel PC DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive (2004/108/EC, 2014/30/EU) ◼ Low-Voltage Directive (2006/95/EC, 2014/35/EU) ◼ RoHS II Directive (2011/65/EU, 2015/863/EU) ◼ If the user modifies and/or install other devices in the equipment, the CE conformity declaration may no longer apply.
  • Page 55 IASO-W08PLED-N6210 Panel PC Español [Spanish] IEI Integration Corp. declara que el equipo cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/EU. Ελληνική [Greek] IEI Integration Corp. ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ ΟΥΣΙΩΔΕΙΣ ΑΠΑΙΤΗΣΕΙΣ ΚΑΙ ΤΙΣ ΛΟΙΠΕΣ ΣΧΕΤΙΚΕΣ ΔΙΑΤΑΞΕΙΣ ΤΗΣ ΟΔΗΓΙΑΣ...

  • Page 56: Fcc Warning

    IASO-W08PLED-N6210 Panel PC Slovensko [Slovenian] IEI Integration Corp. izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 2014/53/EU. Slovensky [Slovak] IEI Integration Corp. týmto vyhlasuje, že zariadenia spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 2014/53/EU.

  • Page 57: Rohs Statement

    IASO-W08PLED-N6210 Panel PC ROHS STATEMENT The label on the product indicates this product conforms to European (EU) Restriction of Hazardous Substances (RoHS) that set maximum concentration limits on hazardous materials used in electrical and electronic equipment. CHINA ROHS The label on the product indicates the estimated “Environmentally Friendly Use Period”...

  • Page 58: Product Disposal

    IASO-W08PLED-N6210 Panel PC Appendix Product Disposal Page 50...
  • Page 59 IASO-W08PLED-N6210 Panel PC CAUTION Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Dispose of used batteries according to instructions and local regulations. ▪ Outside the European Union - If you wish to dispose of used electrical and electronic products outside the European Union, please contact your local authority so as to comply with the correct disposal method.

  • Page 60: C Maintenance And Cleaning Precautions

    IASO-W08PLED-N6210 Panel PC Appendix Maintenance and Cleaning Precautions Page 52...

  • Page 61: Maintenance And Cleaning

    Thinner Spray-type cleaner, Benzene, Wax, Abrasive cleaner, Acid or Alkaline solvent. C.1.1 Maintenance and Cleaning Prior to cleaning any part or component of the IASO-W08PLED-N6210, please read the details below. ▪ To clean the IASO-W08PLED-N6210, remove dirt with a lightly moistened cloth.
  • Page 62 IASO-W08PLED-N6210. ▪ Using solvents – The use of solvents is not recommended when cleaning the IASO-W08PLED-N6210 as they may damage the plastic parts. ▪ Cotton swabs - Cotton swaps moistened with water are excellent tools for wiping hard to reach areas.

  • Page 63: Symbol Definitions

    IASO-W08PLED-N6210 Panel PC Appendix Symbol Definitions Page 55...
  • Page 64 IASO-W08PLED-N6210 Panel PC The following symbols appear on the product, its labeling, or the product packing. Each symbol carries a special definition, as defined below: Direct current Fragile, handle with care AC current Keep dry Protective earth (ground) This side up...

  • Page 65: Watchdog Timer

    IASO-W08PLED-N6210 Panel PC Appendix Watchdog Timer Page 57...
  • Page 66 IASO-W08PLED-N6210 Panel PC NOTE: The following discussion applies to DOS. Contact IEI support or visit the IEI website for drivers for other operating systems. The Watchdog Timer is a hardware-based timer that attempts to restart the system when it stops working. The system may stop working because of external EMI or software bugs.

  • Page 67: Example Program

    IASO-W08PLED-N6210 Panel PC NOTE: The Watchdog Timer is activated through software. The software application that activates the Watchdog Timer must also deactivate it when closed. If the Watchdog Timer is not deactivated, the system will automatically restart after the Timer has finished its countdown.

  • Page 68: F Error Beep Code

    IASO-W08PLED-N6210 Panel PC Appendix Error Beep Code Page 60...

  • Page 69: Pei Beep Codes

    IASO-W08PLED-N6210 Panel PC F.1 PEI Beep Codes Number of Beeps Description Memory not Installed Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed...

  • Page 70: G Hazardous Materials Disclosure

    IASO-W08PLED-N6210 Panel PC Appendix Hazardous Materials Disclosure Page 62...

  • Page 71: Rohs Ii Directive (2015/863/Eu)

    IASO-W08PLED-N6210 Panel PC G.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU).

  • Page 72: China Rohs

    IASO-W08PLED-N6210 Panel PC G.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些 元件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572- 2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 64...
