IEI Technology IASO-W07A-N6210 User Manual

7" medical panel pc with intel celeron processor n6210, p-cap touchscreen, 8 gb lpddr4x, 32gb emmc, hdmi output, six usb 3.2, wi-fi 6, dual gbe, speaker and rohs
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IASO-W07A-N6210 Medical Panel PC
MODEL:
IASO-W07A-N6210
7" Medical Panel PC with Intel® Celeron® Processor N6210,
P-CAP Touchscreen, 8 GB LPDDR4x, 32GB eMMC, HDMI Output,
Six USB 3.2, Wi-Fi 6, Dual GbE, Speaker and RoHS
User Manual
Page i
Rev. 1.00 - June 7, 2023
[MODEL NAME]

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IASO-W07A-N6210 and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology IASO-W07A-N6210

Summary of Contents for IEI Technology IASO-W07A-N6210

  • Page 1 IASO-W07A-N6210 Medical Panel PC MODEL: IASO-W07A-N6210 7" Medical Panel PC with Intel® Celeron® Processor N6210, P-CAP Touchscreen, 8 GB LPDDR4x, 32GB eMMC, HDMI Output, Six USB 3.2, Wi-Fi 6, Dual GbE, Speaker and RoHS User Manual Page i Rev. 1.00 - June 7, 2023...
  • Page 2 IASO-W07A-N6210 Medical Panel PC Revision Date Version Changes June 7, 2023 1.00 Initial release Page ii [MODEL NAME]...
  • Page 3 IASO-W07A-N6210 Medical Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.
  • Page 4 IASO-W07A-N6210 Medical Panel PC Manual Conventions WARNING Warnings appear where overlooked details may cause damage to the equipment or result in personal injury. Warnings should be taken seriously. CAUTION Cautionary messages should be heeded to help reduce the chance of losing data or damaging the product.

  • Page 5: Table Of Contents

    IASO-W07A-N6210 Medical Panel PC Table of Contents 1 INTRODUCTION ......................1 1.1 O ........................2 VERVIEW 1.2 F ........................3 EATURES 1.3 F ......................3 RONT ANEL 1.4 B ......................4 OTTOM ANEL 1.5 R ......................5 ANEL 1.6 S ....................
  • Page 6 IASO-W07A-N6210 Medical Panel PC 4.1.3 Getting Help ..................... 27 4.1.4 Unable to Reboot after Configuration Changes ..........28 4.1.5 BIOS Menu Bar ....................28 4.2 M ........................28 4.3 A ....................... 29 DVANCED 4.3.1 CPU Configuration ..................30 4.3.2 Trusted Computing ................... 32 4.3.3 IT5571 H/W Monitor ..................
  • Page 7 IASO-W07A-N6210 Medical Panel PC F.1 PEI B ...................... 67 ODES F.2 DXE B ....................67 ODES G HAZARDOUS MATERIALS DISCLOSURE ............68 G.1 R HS II D (2015/863/EU) ............... 69 IRECTIVE G.2 C HS ......................70 HINA Page vii [MODEL NAME]...
  • Page 8 IASO-W07A-N6210 Medical Panel PC List of Figures Figure 1-1: IASO-W07A-N6210 Medical Panel PC ............... 2 Figure 1-2: Front View ........................3 Figure 1-3: Bottom Panel ....................... 4 Figure 1-4: Rear View ........................5 Figure 1-5: Dimensions (mm) ......................8 Figure 3-1: Ethernet Connector ....................17 Figure 3-2: AT/ATX Switch Location ...................18...
  • Page 9 IASO-W07A-N6210 Medical Panel PC List of Tables Table 1-1: System Specifications ....................7 Table 3-1: Ethernet Connector Pinouts ..................17 Table 3-2: Connector LEDs ......................17 Table 4-1: BIOS Navigation Keys ....................26 Table 4-2: BIOS On-screen Navigation Keys ................27 Page ix [MODEL NAME]...

  • Page 11: Introduction

    IASO-W07A-N6210 Medical Panel PC Chapter Introduction Page 1...

  • Page 12: Overview

    LAN. NOTE: The IASO-W07A-N6210 medical panel PC is intended to be used to display general purpose medical information. The device shall not be used for diagnosis purpose or life supporting system.

  • Page 13: Features

     1.3 Front Panel The front side of the IASO-W07A-N6210 is a flat-bezel panel with a 7" LCD screen surrounded by an ABS/PC plastic frame. There is a power LED indicator located on the front panel. The status descriptions of the power LED indicator are listed below.

  • Page 14: Bottom Panel

    IASO-W07A-N6210 Medical Panel PC 1.4 Bottom Panel The bottom panel of the IASO-W07A-N6210 has the following connectors and components (Figure 1-3):  1 x 12 V DC input jack (standard)  1 x HDMI output connector  2 x 1GbE RJ-45 ...

  • Page 15: Rear Panel

    IASO-W07A-N6210 Medical Panel PC 1.5 Rear Panel The rear panel contains four retention screw holes that support VESA 75 mount. A speaker is also pre-installed inside the rear panel. See Figure 1-4. Figure 1-4: Rear View Page 5...

  • Page 16: System Specifications

    IASO-W07A-N6210 Medical Panel PC 1.6 System Specifications The technical specifications for the IASO-W07A-N6210 systems are listed below. LCD and Touchscreen LCD Size 7" Max. Resolution 1024 (W) x 600 (H) Brightness (cd/m Contrast Ratio 800:1 Viewing Angle (H-V) 170°/170° Backlight MTBF...

  • Page 17: Table 1-1: System Specifications

    IASO-W07A-N6210 Medical Panel PC Physical Thermal Fanless Mounting VESA 75 mm x 75 mm Dimensions (W x H x D) 190.9 mm x 127.3 mm x 43.4 mm Weight (Net/Gross) 0.72 kg / 1.65 kg Environment Temperature -20ºC - 60ºC...

  • Page 18: Dimensions

    IASO-W07A-N6210 Medical Panel PC 1.7 Dimensions The IASO-W07A-N6210 dimensions are shown below. Figure 1-5: Dimensions (mm) Page 8...

  • Page 19: Unpacking

    IASO-W07A-N6210 Medical Panel PC Chapter Unpacking Page 9...

  • Page 20: Unpacking

    IASO-W07A-N6210 Medical Panel PC 2.1 Unpacking To unpack the medical panel PC, follow the steps below: WARNING / AVERTISSEMENT The front side LCD screen has a protective plastic cover stuck to the screen. Only remove the plastic cover after the medical panel PC has been properly installed.

  • Page 21: Packing List

    IASO-W07A-N6210 was purchased from or contact an IEI sales representative directly by sending an email to iei_medical@ieiworld.com. 3 2 6 H 3 7 8 H The IASO-W07A-N6210 medical panel PC is shipped with the following components: Quantity Item Image IASO-W07A-N6210 medical panel PC...

  • Page 22: Installation

    IASO-W07A-N6210 Medical Panel PC Chapter Installation Page 12...

  • Page 23: Safety Precautions

     Electric shocks can occur if the IASO-W07A-N6210 chassis is opened when the IASO-W07A-N6210 is running. To avoid risk of electric shock, this equipment must only be connected to a supply mains with protective earth. Page 13...
  • Page 24  Never replace or repair any components on your own. If the components of the IASO-W07A-N6210 fails or malfunctions it must be shipped back to IEI to be repaired. Please contact the system vendor, reseller or an IEI sales person directly.

  • Page 25: Anti-Static Precautions

    Electrostatic discharge (ESD) can cause serious damage to electronic components, including the IASO-W07A-N6210. Dry climates are especially susceptible to ESD. It is therefore critical that whenever the IASO-W07A-N6210 is accessed internally, or any other electrical component is handled, the following anti-static precautions are strictly adhered to.

  • Page 26: Installation Precautions

    1. DO NOT modify this equipment without authorization of manufacturer. Ne modifiez pas cet équipement sans l'autorisation du fabricant. 2. DO NOT power up the IASO-W07A-N6210 while the front panel is facing down on a sheet of conductive foam. Doing so may cause the touch panel to malfunction due to the large surface area of contact between the conductive form and the touch panel.

  • Page 27: Gbe Connection

    IASO-W07A-N6210 Medical Panel PC 3.4 GbE Connection Each RJ-45 connector on the bottom panel allows 1GbE connection to be made to a Local Area Network. Description Description MDIA3- MDIA1+ MDIA3+ MDIA2+ MDIA2- MDIA0- MDIA1- MDIA0+ Table 3-1: Ethernet Connector Pinouts...

  • Page 28: At/Atx Mode Selection

    IASO-W07A-N6210 Medical Panel PC 3.5 AT/ATX Mode Selection AT or ATX power mode can be used on the IASO-W07A-N6210. The selection is made through an AT/ATX switch located on the bottom panel (Figure 3-2). Figure 3-2: AT/ATX Switch Location Page 18...

  • Page 29: Vesa Mounting

    IASO-W07A-N6210 Medical Panel PC 3.6 VESA Mounting The IASO-W07A-N6210 is VESA (4 screws: M4 type, 6 mm length min.) compliant and can be mounted on a mounting device with a 75 mm interface pad. The IASO-W07A-N6210 VESA mount retention screw holes are shown below. Refer to the installation guide that came with the mounting device to mount the IASO-W07A-N6210.

  • Page 30: Powering On The System

    Connect the power adapter to the power connector of the IASO-W07A-N6210. NOTE: The FSP FSP065-DHBM1 power adapter came with the IASO-W07A-N6210 is a forming part of the medical device. Figure 3-4: Power Input Connector and Power Button Step 2: Locate the power button on the I/O panel.

  • Page 31: Figure 3-5: Power Led

    IASO-W07A-N6210 Medical Panel PC Figure 3-5: Power LED Page 21...

  • Page 32: Clear Cmos

    IASO-W07A-N6210 Medical Panel PC 3.8 Clear CMOS If the IASO-W07A-N6210 fails to boot due to improper BIOS settings, the clear CMOS jumper clears the CMOS data and resets the system BIOS information. To do this, push the clear CMOS button for three seconds, then restart the system. The clear CMOS button location is shown in Figure 3-6.

  • Page 33: System Maintenance

    IASO-W07A-N6210 Medical Panel PC 3.10 System Maintenance If the components of the IASO-W07A-N6210 fail, they must be replaced. Please contact the system reseller or vendor to purchase the replacement parts. NOTE: A user cannot replace a motherboard. If the motherboard fails it must be shipped back to IEI to be replaced.

  • Page 34: Bios Setup

    IASO-W07A-N6210 Medical Panel PC Chapter BIOS Setup Page 24...

  • Page 35: Introduction

    IASO-W07A-N6210 Medical Panel PC 4.1 Introduction A licensed copy of the BIOS is preprogrammed into the ROM BIOS. The BIOS setup program allows users to modify the basic system configuration. This chapter describes how to access the BIOS setup program and the configuration options that may be changed.

  • Page 36: Using Setup

    IASO-W07A-N6210 Medical Panel PC 4.1.2 Using Setup The BIOS Setup menu can be navigated by using a keyboard or a touchscreen. 4.1.2.1 Keyboard Navigation For keyboard navigation, use the navigation keys shown in Table 4-1. Function Up arrow Move to previous item...

  • Page 37: Touch Navigation

    IASO-W07A-N6210 Medical Panel PC 4.1.2.2 Touch Navigation For touchscreen navigation, use the on-screen navigation keys shown below. On-screen Button Function Previous Values Load the last value you set. Optimized Defaults Load the factory default values in order to achieve the best performance.

  • Page 38: Unable To Reboot After Configuration Changes

    IASO-W07A-N6210 Medical Panel PC 4.1.4 Unable to Reboot after Configuration Changes If the computer cannot boot after changes to the system configuration are made, CMOS defaults. 4.1.5 BIOS Menu Bar The menu bar on top of the BIOS screen has the following main items: ...

  • Page 39: Advanced

    IASO-W07A-N6210 Medical Panel PC  System Date [xx/xx/xx] Use the System Date option to set the system date. Manually enter the day, month and year.  System Time [xx:xx:xx] Use the System Time option to set the system time. Manually enter the hours, minutes and seconds.

  • Page 40: Cpu Configuration

    IASO-W07A-N6210 Medical Panel PC 4.3.1 CPU Configuration Use the CPU Configuration ( B IOS Menu 3) to view detailed CPU specifications and 8 3 9 H configure the CPU. BIOS Menu 3: CPU Configuration  Intel(R) SpeedStep(tm) [Enabled] Use the Intel(R) SpeedStep(tm) option to enable or disable the Intel® SpeedStep™...
  • Page 41 IASO-W07A-N6210 Medical Panel PC  Intel Virtualization Technology [Enabled] Use the Intel Virtualization Technology option to enable or disable virtualization on the system. When combined with third party software, Intel® Virtualization technology allows several OSs to run on the same system at the same time.

  • Page 42: Trusted Computing

    IASO-W07A-N6210 Medical Panel PC 4.3.2 Trusted Computing Use the Trusted Computing menu (BIOS Menu 4) to configure settings related to the Trusted Computing Group (TCG) Trusted Platform Module (TPM). BIOS Menu 4: Trusted Computing  Security Device Support [Enable] Use the Security Device Support option to configure support for the security device.

  • Page 43: It5571 H/W Monitor

    IASO-W07A-N6210 Medical Panel PC 4.3.3 IT5571 H/W Monitor The IT5571 H/W Monitor menu ( B IOS Menu 5) shows the state of H/W real-time 8 4 5 H operating temperature, fan speeds and system voltages. BIOS Menu 5: IT5571 H/W Monitor ...

  • Page 44: Rtc Wake Settings

    IASO-W07A-N6210 Medical Panel PC 4.3.4 RTC Wake Settings The RTC Wake Settings menu ( B IOS Menu 6) configures RTC wake event. 8 3 8 H BIOS Menu 6: RTC Wake Settings  Wake System with Fixed Time [Disabled] Use the Wake System with Fixed Time option to specify the time the system should be roused from a suspended state.

  • Page 45: Network Stack Configuration

    IASO-W07A-N6210 Medical Panel PC 4.3.5 Network Stack Configuration The Network Stack Configuration menu ( B IOS Menu 7) configures network stack 8 3 8 H settings. BIOS Menu 7: Network Stack Configuration  Network Stack [Disabled] Use the Network Stack option to enable or disable UEFI network stack.

  • Page 46: Chipset

    IASO-W07A-N6210 Medical Panel PC 4.4 Chipset Use the Chipset menu (BIOS Menu 8) to configure the system chipset. BIOS Menu 8: Chipset Page 36...

  • Page 47: System Agent (Sa) Configuration

    IASO-W07A-N6210 Medical Panel PC 4.4.1 System Agent (SA) Configuration Use the System Agent (SA) Configuration menu (BIOS Menu 9) to configure the System Agent (SA) parameters. BIOS Menu 9: System Agent (SA) Configuration  VT-d [Enabled] Use the VT-d option to enable or disable VT-d support.

  • Page 48: Memory Configuration

    IASO-W07A-N6210 Medical Panel PC 4.4.1.1 Memory Configuration Use the Memory Configuration submenu ( B IOS Menu 10) to display the memory 6 3 2 H information. BIOS Menu 10: Memory Configuration Page 38...

  • Page 49: Graphics Configuration

    IASO-W07A-N6210 Medical Panel PC 4.4.1.2 Graphics Configuration Use the Graphics Configuration menu ( B IOS Menu 11) to view the graphics settings. 6 3 2 H BIOS Menu 11: Graphics Configuration Page 39...

  • Page 50: Pch-Io Configuration

    IASO-W07A-N6210 Medical Panel PC 4.4.2 PCH-IO Configuration Use the PCH-IO Configuration menu (BIOS Menu 12) to configure the PCH-IO chipset. BIOS Menu 12: PCH-IO Configuration  Restore AC Power Loss [Last State] Use the Restore AC Power BIOS option to specify what state the system returns to if there is a sudden loss of power to the system.
  • Page 51 IASO-W07A-N6210 Medical Panel PC  Power Saving Function(ERP) [Disabled] Use the Power Saving Function(ERP) BIOS option to enable or disable the power saving function.  Disabled Power saving function is disabled. EFAULT  Power saving function is enabled. It will reduce power Enabled consumption when the system is off.

  • Page 52: Pci Express Configuration

    IASO-W07A-N6210 Medical Panel PC 4.4.2.1 PCI Express Configuration Use the PCI Express Configuration submenu (BIOS Menu 13) to configure the PCI Express slots. BIOS Menu 13: PCI Express Configuration  M2_A1 [Enabled] Use the M2_A1 option to enable or disable the M.2 expansion slot.

  • Page 53: Sata Configuration

    IASO-W07A-N6210 Medical Panel PC 4.4.2.2 SATA Configuration Use the SATA Configuration menu (BIOS Menu 14) to change and/or set the configuration of the SATA devices installed in the system. BIOS Menu 14: SATA Configuration  SATA Mode Selection [AHCI] Use the SATA Mode Selection option to configure how the SATA controller(s) operate.

  • Page 54: Hd Audio Configuration

    IASO-W07A-N6210 Medical Panel PC 4.4.2.3 HD Audio Configuration Use the HD Audio Configuration menu (BIOS Menu 15) to configure the PCH Azalia settings. BIOS Menu 15: HD Audio Configuration  HD Audio [Enabled] Use the HD Audio option to enable or disable the High Definition Audio controller.

  • Page 55: Security

    IASO-W07A-N6210 Medical Panel PC 4.5 Security Use the Security menu (BIOS Menu 16) to set system and user passwords. BIOS Menu 16: Security  Administrator Password Use the Administrator Password field to set or change an administrator password.  User Password Use the User Password field to set or change a user password.

  • Page 56: Boot

    IASO-W07A-N6210 Medical Panel PC 4.6 Boot Use the Boot menu ( B IOS Menu 17) to configure system boot options. 8 5 2 H BIOS Menu 17: Boot  Quiet Boot [Enabled] Use the Quiet Boot BIOS option to select the screen display when the system boots.
  • Page 57 IASO-W07A-N6210 Medical Panel PC BIOS Menu 18: Save & Exit  Save Changes and Reset Use the Save Changes and Reset option to save the changes made to the BIOS options and reset the system.  Discard Changes and Reset Use the Discard Changes and Reset option to exit the system without saving the changes made to the BIOS configuration setup program.

  • Page 58: Driver Installation

    IASO-W07A-N6210 Medical Panel PC Chapter Driver Installation Page 48...

  • Page 59: Available Drivers

    IASO-W07A-N6210 Medical Panel PC 5.1 Available Drivers All the drivers for the IASO-W07A-N6210 are available on IEI Resource Download Center (https://download.ieiworld.com). Type IASO-W07A-N6210, and press Enter to find all the relevant software, utilities, and documentation. Figure 5-1: IEI Resource Download Center 5.2 Driver Download...
  • Page 60 IASO-W07A-N6210 Medical Panel PC Step 3: Click the driver file name on the page and you will be prompted with the  following window. You can download the entire ISO file ( ), or click the small  arrow to find an individual driver and click the file name to download (...

  • Page 61: A Regulatory Compliance

    IASO-W07A-N6210 Medical Panel PC Appendix Regulatory Compliance Page 51...
  • Page 62 IASO-W07A-N6210 Medical Panel PC DECLARATION OF CONFORMITY This equipment is in conformity with the following EU directives: EMC Directive (2004/108/EC, 2014/30/EU)  Low-Voltage Directive (2006/95/EC, 2014/35/EU)  RoHS II Directive (2011/65/EU, 2015/863/EU)  Medical Device Directive 93/42/EEC: EN 60601-1 ...
  • Page 63 IASO-W07A-N6210 Medical Panel PC Español [Spanish] IEI Integration Corp. declara que el equipo cumple con los requisitos esenciales y cualesquiera otras disposiciones aplicables o exigibles de la Directiva 2014/53/EU. Ελληνική [Greek] IEI Integration Corp. ΔΗΛΩΝΕΙ ΟΤΙ ΕΞΟΠΛΙΣΜΟΣ ΣΥΜΜΟΡΦΩΝΕΤΑΙ ΠΡΟΣ ΤΙΣ...
  • Page 64 IASO-W07A-N6210 Medical Panel PC Slovensko [Slovenian] IEI Integration Corp. izjavlja, da je ta opreme v skladu z bistvenimi zahtevami in ostalimi relevantnimi določili direktive 2014/53/EU. Slovensky [Slovak] IEI Integration Corp. týmto vyhlasuje, že zariadenia spĺňa základné požiadavky a všetky príslušné ustanovenia Smernice 2014/53/EU.
  • Page 65 IASO-W07A-N6210 Medical Panel PC UL CLASSIFIED The label on the product indicates this product complies with the requirements of ES 60601-1 (2005) + AMD (2012), CAN/CSA-C22.2 No. 60601-1:14. ROHS STATEMENT The label on the product indicates this product conforms to European (EU) Restriction of Hazardous Substances (RoHS) that set maximum concentration limits on hazardous materials used in electrical and electronic equipment.

  • Page 66: B Product Disposal

    IASO-W07A-N6210 Medical Panel PC Appendix Product Disposal Page 56...
  • Page 67 IASO-W07A-N6210 Medical Panel PC CAUTION / ATTENTION Risk of explosion if battery is replaced by an incorrect type. Only certified engineers should replace the on-board battery. Risque d'explosion si la batterie est remplacée par un type incorrect. Seuls les ingénieurs certifiés doivent remplacer la batterie embarquée.

  • Page 68: C Maintenance And Cleaning Precautions

    IASO-W07A-N6210 Medical Panel PC Appendix Maintenance and Cleaning Precautions Page 58...
  • Page 69 IASO-W07A-N6210 Medical Panel PC When maintaining or cleaning the IASO-W07A-N6210, please follow the guidelines below. WARNING / AVERTISSEMENT If you dropped any material or liquid such as water onto the panel PC when cleaning, unplug the power cable immediately and contact your dealer or the nearest service center.

  • Page 70: Maintenance And Cleaning

    Some components in the IASO-W07A-N6210 may only be cleaned using a product specifically designed for the purpose. In such case, the product will be explicitly mentioned in the cleaning tips. Below is a list of items to use when cleaning the IASO-W07A-N6210. ...

  • Page 71: D Symbol Definitions

    IASO-W07A-N6210 Medical Panel PC Appendix Symbol Definitions Page 61...
  • Page 72 IASO-W07A-N6210 Medical Panel PC The following symbols appear on the product, its labeling, or the product packing. Each symbol carries a special definition, as defined below: Direct current Fragile, handle with care AC current Keep dry Protective earth (ground) This side up...

  • Page 73: E Watchdog Timer

    IASO-W07A-N6210 Medical Panel PC Appendix Watchdog Timer Page 63...
  • Page 74 IASO-W07A-N6210 Medical Panel PC NOTE: The following discussion applies to DOS. Contact IEI support or visit the IEI website for drivers for other operating systems. The Watchdog Timer is a hardware-based timer that attempts to restart the system when it stops working.
  • Page 75 IASO-W07A-N6210 Medical Panel PC NOTE: The Watchdog Timer is activated through software. The software application that activates the Watchdog Timer must also deactivate it when closed. If the Watchdog Timer is not deactivated, the system will automatically restart after the Timer has finished its countdown.

  • Page 76: F Error Beep Code

    IASO-W07A-N6210 Medical Panel PC Appendix Error Beep Code Page 66...

  • Page 77: Pei Beep Codes

    IASO-W07A-N6210 Medical Panel PC F.1 PEI Beep Codes Number of Beeps Description Memory not Installed Memory was installed twice (InstallPeiMemory routine in PEI Core called twice) Recovery started DXEIPL was not found DXE Core Firmware Volume was not found Recovery failed...

  • Page 78: G Hazardous Materials Disclosure

    IASO-W07A-N6210 Medical Panel PC Appendix Hazardous Materials Disclosure Page 68...

  • Page 79: Rohs Ii Directive (2015/863/Eu)

    IASO-W07A-N6210 Medical Panel PC G.1 RoHS II Directive (2015/863/EU) The details provided in this appendix are to ensure that the product is compliant with the RoHS II Directive (2015/863/EU). The table below acknowledges the presences of small quantities of certain substances in the product, and is applicable to RoHS II Directive (2015/863/EU).

  • Page 80: China Rohs

    IASO-W07A-N6210 Medical Panel PC G.2 China RoHS 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些 元件将会单独标示出来。 部件名称 有毒有害物质或元素 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求以下。 X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 SJ/T11364-2014 與 GB/T26572-2011 标准规定的限量要求。 Page 70...
