IOVU-571N RISC-based Panel PC
IEI Technology Corp.
MODEL:
IOVU-571N
RISC-based Panel PC with 5.7" Monitor and Touch Screen
Fast Ethernet, USB, RS-232/422/485
Rev. 1.00 – 25 March, 2009
IOVU-571N RISC-based Panel PC
SD Card Slot, RoHS Compliant
User Manual
Page i

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IOVU-571N and is the answer not in the manual?

Questions and answers

Related Manuals for IEI Technology IOVU-571N

Summary of Contents for IEI Technology IOVU-571N

  • Page 1 IOVU-571N RISC-based Panel PC IOVU-571N RISC-based Panel PC IEI Technology Corp. MODEL: IOVU-571N RISC-based Panel PC with 5.7" Monitor and Touch Screen Fast Ethernet, USB, RS-232/422/485 SD Card Slot, RoHS Compliant User Manual Page i Rev. 1.00 – 25 March, 2009...
  • Page 2 IOVU-571N RISC-based Panel PC Revision Date Version Changes 25 March, 2009 1.00 Initial release Page ii...
  • Page 3 IOVU-571N RISC-based Panel PC Copyright COPYRIGHT NOTICE The information in this document is subject to change without prior notice in order to improve reliability, design and function and does not represent a commitment on the part of the manufacturer. In no event will the manufacturer be liable for direct, indirect, special, incidental, or consequential damages arising out of the use or inability to use the product or documentation, even if advised of the possibility of such damages.

  • Page 4: Packing List

    IOVU-571N from or contact an IEI sales representative directly. To contact an IEI sales representative, please send an email to sales@iei.com.tw. The items listed below should all be included in the IOVU-571N package. 1 x IOVU-571N 1 x Utility CD...

  • Page 5: Table Of Contents

    IOVU-571N RISC-based Panel PC Table of Contents 1 INTRODUCTION......................1 1.1 O ........................2 VERVIEW 1.2 B ........................2 ENEFITS 1.3 F ........................3 EATURES 1.4 T ..................3 ECHNICAL PECIFICATIONS 1.5 C ......................4 ERTIFICATIONS 2 DETAILED SPECIFICATIONS .................. 5 2.1 M...
  • Page 6 IOVU-571N RISC-based Panel PC 4.4.4 RS-422/485 Serial Port ..................24 4.4.5 NAND/NOR Flash Boot and RS-422/485 Setup Switch........24 4.4.6 USB Connector ....................25 4.5 S ........................ 26 OFTWARE A TERMINOLOGY......................27 B HAZARDOUS MATERIALS DISCLOSURE ............29 B.1 H...
  • Page 7 List of Figures Figure 1-1: IOVU-571N........................2 Figure 2-1: Front Panel ........................6 Figure 2-2: IOVU-571N Connectors (Bottom Panel)..............7 Figure 2-3: IOVU-571N Connectors (Right Side Panel)...............7 Figure 2-4: IOVU-571N Physical Dimensions (millimeters)............9 Figure 4-1: Wall-mounting Bracket .....................16 Figure 4-2: Chassis Support Screws ..................17 Figure 4-3: Secure the IOVU-571N ....................18...
  • Page 8 IOVU-571N RISC-based Panel PC List of Tables Table 1-1: Technical Specifications....................4 Table 3-1: Package List Contents ....................12 Table 3-2: Optional Item.......................13 Table 4-1: LAN Pinouts ........................21 Table 4-2: Power Terminal Block Pinouts..................22 Table 4-3: RS-232 Serial Port (COM 1) Pinouts .................23 Table 4-4: RS-422/485 Serial Port Pinouts .................24...

  • Page 9: Introduction

    IOVU-571N RISC-based Panel PC Chapter Introduction Page 1...

  • Page 10: Overview

    RS-232/422/485 ports, network port and USB ports. The IOVU-571N combines the reliability of a traditional HMI with the flexibility of a PC and the small size of a thin-client. The IOVU-571N is preinstalled with Windows® CE .NET 5.0 operating system in a SD card, to provide rich application development and support connectivity to network and I/O devices.

  • Page 11: Features

    9~28 V DC input Windows® CE 5.0 preinstalled in a SD card Built-in 2 W stereo speaker RoHS compliant 1.4 Technical Specifications The IOVU-571N technical specifications are listed in Table 1-1. Specification Value System 200 MHz Nuvoton W90P910CBG processor 128 MB SDRAM...

  • Page 12: Certifications

    9-28 V DC input by power jack and terminal block power switch and power LED Table 1-1: Technical Specifications 1.5 Certifications All IOVU-571N series models comply with the following international standards: RoHS For a more detailed description of these standards, please refer to the appendices Page 4...

  • Page 13: Detailed Specifications

    IOVU-571N RISC-based Panel PC Chapter Detailed Specifications Page 5...

  • Page 14: Mechanical Overview

    IOVU-571N RISC-based Panel PC 2.1 Mechanical Overview 2.1.1 Front Panel The IOVU-571N front panel (Figure 2-1) comprises a 5.7” touch screen LCD in an ABS/PC frame. Figure 2-1: Front Panel 2.1.2 Connector Panel All external peripheral interface connectors are located on the right side panel and the bottom panel of the system enclosure.

  • Page 15: Figure 2-2: Iovu-571N Connectors (Bottom Panel)

    IOVU-571N RISC-based Panel PC Figure 2-2: IOVU-571N Connectors (Bottom Panel) Figure 2-3: IOVU-571N Connectors (Right Side Panel) External peripheral interface connectors on the IOVU-571N include: 1 x Power jack 1 x Power terminal block 1 x RS-232 connector Page 7...

  • Page 16: Internal Overview

    1 x SD slot (right side panel) 2.2 Internal Overview Internally the IOVU-571N contains a motherboard, connected to the external interface connectors. The motherboard is also connected to the LCD panel and touch screen. For full motherboard specifications and details, please refer to the motherboard user manual.

  • Page 17: Physical Dimensions

    IOVU-571N RISC-based Panel PC 2.3 Physical Dimensions The physical dimensions of the IOVU-571N are shown in Figure 2-4 and listed below: Width: 180.00 mm Height: 132.00 mm Depth: 40.00 mm Figure 2-4: IOVU-571N Physical Dimensions (millimeters) Page 9...

  • Page 18: Unpacking

    IOVU-571N RISC-based Panel PC Chapter Unpacking Page 10...

  • Page 19: Anti-Static Precautions

    When the IOVU-571N is unpacked, please do the following: Follow the anti-static precautions outlined in Section 3.1. Make sure the packing box is facing upwards so the IOVU-571N does not fall out of the box. Make sure all the items listed below are included.

  • Page 20: Packing Contents

    If some of the components listed in the checklist below are missing, please do not proceed with the installation. Contact the IEI reseller or vendor you purchased the IOVU-571N from or contact an IEI sales representative directly. To contact an IEI sales representative, please send an email to sales@iei.com.tw.

  • Page 21: Optional Items

    IOVU-571N RISC-based Panel PC 3.4 Optional Items The following optional items are available. Quantity Item and Part Number Image Power adapter (P/N: 63000-PSP0601AD101CT60-RS) Table 3-2: Optional Item Page 13...

  • Page 22: Installation

    IOVU-571N RISC-based Panel PC Chapter Installation Page 14...

  • Page 23: Installation Precautions

    Electric shock and personal injury might occur if the rear panel of the IOVU-571N is opened while the power cord is still connected to an electrical outlet.

  • Page 24: Wall Mounting

    Stand mounting The four mounting methods are fully described below. 4.3.1 Wall Mounting To mount the IOVU-571N flat panel PC onto a wall, please follow the steps below. Step 1: Select the location on the wall for the wall-mounting bracket.

  • Page 25: Figure 4-2: Chassis Support Screws

    Step 6: Insert the four monitor mounting screws provided in the wall mounting kit into the four screw holes on the real panel of the IOVU-571N and tighten until the screw shank is secured against the rear panel (Figure 4-2).

  • Page 26: Arm Mounting

    Figure 4-3: Secure the IOVU-571N 4.3.2 Arm Mounting The IOVU-571N is VESA (Video Electronics Standards Association) compliant and can be mounted on an arm with a 75 mm interface pad. To mount the IOVU-571N on an arm, please follow the steps below. Step 1: The arm is a separately purchased item.

  • Page 27: Stand Mounting

    Figure 4-4. Figure 4-4: Arm Mount Retention Screw Holes Step 4: Secure the IOVU-571N to the interface pad by inserting four retention screws through the mounting arm interface pad and into the IOVU-571N. 4.3.3 Stand Mounting The IOVU-571N has Video Electronics Standards Association (VESA) standard mounting holes tapped into the rear panel.

  • Page 28: External Connectors

    IOVU-571N RISC-based Panel PC Figure 4-5: Stand Mounting 4.4 External Connectors Figure 4-6 shows the bottom panel. The bottom panel consists of one RJ-45 Ethernet connector, two serial ports, and two power connectors. Figure 4-6: IOVU-571N External Connectors Page 20...

  • Page 29: Lan Connector

    IOVU-571N RISC-based Panel PC 4.4.1 LAN Connector CN Label: LAN1 RJ-45 CN Type: CN Location: See Figure 4-6 CN Pinouts: See Table 4-1 The LAN ports support 10 Mb/s (Ethernet) and 100 Mb/s (Fast Ethernet) transfer rates. To plug in an Ethernet cable, refer to Figure 4-7 below.

  • Page 30: Power Terminal Block

    IOVU-571N RISC-based Panel PC 4.4.2 Power Terminal Block CN Label: TERMINAL 2-pin terminal block CN Type: CN Location: See Figure 4-6 CN Pinouts: See Table 4-2 A single power terminal block can be connected to a 9 VDC to 28 VDC power source.

  • Page 31: Figure 4-8: Serial Device Connector

    IOVU-571N RISC-based Panel PC Figure 4-8: Serial Device Connector The pinouts for the serial port are shown below. PIN NO. DESCRIPTION PIN NO. DESCRIPTION Table 4-3: RS-232 Serial Port (COM 1) Pinouts Figure 4-9: COM1 Pinout Locations Page 23...

  • Page 32: Rs-422/485 Serial Port

    See Figure 4-10 CN Pinouts: See Table 4-5 The IOVU-571N has one DIP switch on the bottom panel. The switch configures the NAND or NOR flash boot and select COM2 function mode. Figure 4-10: DIP Switch The settings for the DIP switch are shown below.

  • Page 33: Usb Connector

    CN Pinouts: See Table 4-6 The IOVU-571N has one external USB 2.0 type A port on the right side panel. The port connects to both USB 2.0 and USB 1.1 devices. To install a USB device, refer to Figure 4-11 below.

  • Page 34: Software

    The IOVU-571N has Windows CE 5.0 pre-installed. For information about configuring the operating system, adding remote management tools or additional software and drivers, refer to the user manuals on IEI IOVU Utility CD that came with the IOVU-571N. Page 26...

  • Page 35: A Terminology

    IOVU-571N RISC-based Panel PC Appendix Terminology Page 27...
  • Page 36 IOVU-571N RISC-based Panel PC AC ’97 Audio Codec 97 (AC’97) refers to a codec standard developed by Intel® in 1997. CompactFlash® CompactFlash® is a solid-state storage device. CompactFlash® devices use flash memory in a standard size enclosure. Type II is thicker than Type I, but a Type II slot can support both types.

  • Page 37: B Hazardous Materials Disclosure

    IOVU-571N RISC-based Panel PC Appendix Hazardous Materials Disclosure Page 29...

  • Page 38: Hazardous Materials Disclosure Table For Ipb Products Certified As Rohs Compliant Under 2002/95/Ec Without Mercury

    IOVU-571N RISC-based Panel PC B.1 Hazardous Materials Disclosure Table for IPB Products Certified as RoHS Compliant Under 2002/95/EC Without Mercury The details provided in this appendix are to ensure that the product is compliant with the Peoples Republic of China (China) RoHS standards. The table below acknowledges the presences of small quantities of certain materials in the product, and is applicable to China RoHS only.
  • Page 39 IOVU-571N RISC-based Panel PC Part Name Toxic or Hazardous Substances and Elements Lead Mercury Cadmium Hexavalent Polybrominated Polybrominated Biphenyls Diphenyl (Pb) (Hg) (Cd) Chromium (CR(VI)) (PBB) Ethers (PBDE) Housing Display Printed Circuit Board Metal Fasteners Cable Assembly Fan Assembly Power Supply...
  • Page 40 IOVU-571N RISC-based Panel PC 此附件旨在确保本产品符合中国 RoHS 标准。以下表格标示此产品中某有毒物质的含量符 合中国 RoHS 标准规定的限量要求。 本产品上会附有”环境友好使用期限”的标签，此期限是估算这些物质”不会有泄漏或突变”的 年限。本产品可能包含有较短的环境友好使用期限的可替换元件，像是电池或灯管，这些 元件将会单独标示出来。 部件名称 有毒有害物质或元素 铅 汞 镉 六价铬 多溴联苯 多溴二苯 醚 (Pb) (Hg) (Cd) (CR(VI)) (PBB) (PBDE) 壳体 显示 印刷电路板 金属螺帽 电缆组装 风扇组装 电力供应组装 电池 O: 表示该有毒有害物质在该部件所有物质材料中的含量均在 SJ/T11363-2006 标准规定的限量要求以下。...
