Dynojet POWER COMMANDER III Installation Instructions page 2

electronics cover
i943-411
The ignition must be turned OFF before
installation.
1 Remove the plastic electronics cover located
above the clutch housing.
2 Unplug the ECU connector on the right side
closest to the engine as shown in Figure B.
3 Attach the PCIII USB connectors to the ECU
and the factory wiring harness.
4 Route the PCIII USB harness out from under
the electronics cover and over to the left side
PCIII USB
of the air box as shown in Figure C.
5 Clean the left side of the air box and the back
of the PCIII USB using the supplied alcohol
swab and attach the supplied velcro.
6 Attach the PCIII USB to the air box.
7 Replace the electronics cover.
8 Insert the cd provided into your
computer's cd-rom drive.
9 Follow the on-screen instructions to install
the PCIII USB software.
Visit www.powercommander.com to
download software tutorials and the latest
maps.
2007-2008 Polaris Cleanfire Injection - PCIII USB - 2
