Danfoss FC 102 Installation Manual page 80

VLT Frequency Converters, 0.25–90 kW
4
( ) ( )
L1/L2/L3
A1 4 (12)
A2 4 (12)
A3 4 (12)
A4 4 (12)
A5 4 (12)
B1 10 (7)
B2 35 (2)
B3 10 (7)
B4 35 (2)
C1 50 (1/0)
C2 95 (4/0)
C3 50 (1/0)
C4 95 (4/0)
80 | Danfoss A/S © 2025.02
[mm 2 (AWG)]
U/V/W -DC/+DC
4 (12) 4 (12)
4(12) 4 (12)
4 (12) 4 (12)
4 (12) 4 (12)
4 (12) 4 (12)
10 (7) 10 (7)
35 (2) 35 (2)
10 (7) 10 (7)
35 (2) 35 (2)
50 (1/0) 50 (1/0)
95 (4/0) 95 (4/0)
50 (1/0) 50 (1/0)
95 (4/0) 95 (4/0)
R+/R-
4 (12)
4 (12)
4 (12)
4 (12)
4 (12)
10 (7)
35 (2)
10 (7)
35 (2)
50 (1/0)
95 (4/0)
50 (1/0)
95 (4/0)
AN41701953385303-000301 / 130R1279
