K-array Thunder-KS I User Manual page 16

Thunder-KS I
USER GUIDE
Mixing console
or matrix
Signal Input
14
Active Subwoofer
AES3
OUT
AES3
IN
Active Subwoofer
K-framework3
PC or MAC Smartphone/Tablet
Remote Control
Top loudspeakers
Passive Subwoofer
4-pole speaker cable
SpeakON NL4
Top loudspeakers output on channels 1 and 3: SpeakON NL4 +1 –1
Passive Subwoofer output on channel 4: SpeakON NL4 +2 –2
Top loudspeakers
2- or 4-pole speaker cable
SpeakON NL4 wired on +1 –1
Passive Subwoofer
Speaker Output
