Getting Started
According to the version and model, follow these steps to make
the system operating:
Active Subwoofer
(KS1 I, KS2 I, KS3 I, KS4 I)
1. Connect the input and output signal cables according to
the configuration you want to achieve.
2. Connect the power cord to an AC mains socket outlet and
to the powerCon TRUE connector on the Thunder-KS rear
panel: the Thunder-KS switches on when the powerCon
TRUE connector is locked and electricity flows.
3. Hold your mobile device (smartphone or tablet): ensure the
Wi-Fi connectivity is on;
4. You can either connect to the Thunder-KS DSP manually or
by scanning the rear QR code.
• • Automatic connect: launch the K-array Connect app and
scan the rear QR code to connect.
• • Manually connect:
a. Force refresh the list of available Wi-Fi networks
available on your device: the Thunder-KS built-in Wi-Fi
hotspot has an SSID starting with K-array followed by
the subwoofer's serial number, for example:
K-array-K140AP0107
b. Connect to the Thunder-KS Wi-Fi SSID: the default
password is the subwoofer's serial number, for
example K140AP0107 (to be written all caps).
c. Launch the K-array Connect app
5. In the K-array Connect app Devices menu, select the
Thunder-KS active subwoofer you want to connect to or
open the browser (Google Chrome recommended) and go
to the default IP address of the DSP web app: 192.168.0.1.
6. Use the app for managing your subwoofer.
Thunder-KS I
Passive Subwoofer
(KS1P I, KS2P I, KS3P I, KS4P I)
A. Use a four wire speakOn cable with NL4 speakOn
connectors. Check the SpeakOn terminal configuration:
by default the Thunder-KSP subwoofers are set to receive
signals on the +2-2 SpeakON terminals.
B. Connect the speaker cable to the SpeakON connector on
the Thunder-KSP rear panel.
C. Connect the other side of the speaker cable to a power
amplifier or to a Thunder-KSP active subwoofer.
D. On the active driving unit load the proper device preset
according to the Thunder-KSP passive subwoofer model.
K-array Connect Devices menu
USER GUIDE
Web App (on the web browser)
