NSD ABSOCODER NPG-220HZCLC Specifications & Instruction Manual page 24

● In the case of using the commercially available cable (JKPEV-S 1.25mm
with a connector
Converter
Dedicated cable
SP1
Dedicated cable
Connector pin arrangement
and wire color
Pin Wire Signal
No. color name
1 Brown SIN+
2 Red SIN-
3 Orange -COS+
4 Yellow -COS-
5 Green OUT1+
6 Blue OUT1-
7 Violet
8 Gray
9
－
10
－
11 Shield Shield
12
－
Cautions for the connection by the connector
1: The wire No. of JKPEV-S cable is printed on the surface of the white wire.
2: Unused wires of JKPEV-S cable should be severed at both ends.
Please install the connector
by customers
JKPEV-S Cable cross section
Connector pin arrangement and wire color
Pin
Wire No.(pair)
No.
1
1
2
3
2
4
5
3
6
7
－ 4
(Not used)
8
－
9
5
－
(Not used）
10
－
11
12
－ －
Commercially available cable
JKPEV-S cable
Wire Signal
color name
White SIN+
Black SIN-
White -COS+
Black -COS-
White OUT1+
Black OUT1-
White
－
Black
－
White
－
Black
－
Shield Shield
－ －
18
2 ×5P) and connecting
ABSOCODER
sensor
ABSOCODER sensor
Connector pin arrangement
and wire color
Pin Wire Signal
No. color name
1 Brown SIN+
2 Red SIN-
3 Orange -COS+
4 Yellow -COS-
5 Green OUT1+
6 Blue OUT1-
7
－ －
8
－ －
9
－ －
10
－ －
11 Shield Shield
12
－ －
