NSD ABSOCODER NPG-220HZCLC Specifications & Instruction Manual page 11

(2) Performance Specification
Items
Converter model
Applicable sensor
Minimum resolution
Position detection format
Pulse output format
Min. pulse width/Max.
repetition frequency
(up/down)
Pulse output permissible
speed
Number of detection
axes
Position data sampling
time
Status output signal
Input signal
Front panel function
Function selector switch
(on rear face of product)
Monitor LED
Applicable standard
(Following values are also settable: 0.2μs/2.5MHz, 0.4μs/1.25MHz,
4.5m/s (Resolution: 1μm, pulse frequency:5MHz)
Pulse division
Pulse width
(up/down )
Alarm setting when turning ON the power supply
Pulse output format setting (up/down pulse or A/B phase pulse)
System state
monitor
Setting state monitor
Input state monitor
Output state monitor
Specifications
NPG-220HZCLC
IRS-32.8P18, IRS-32.8PA18
1μm(32.768mm/32768 divisions)
Semi-absolute format
Up/down or A/B phase pulse
0.1μs/5MHz
0.8μs/0.625MHz)
2
0.2ms
Integrated alarm: ALM
pulse output error: PE
sensor disconnected error: SE
low power error: PF
Error clear: CLR
limit error: LE
Error clear
Up/down pulse
1/1, 1/2, 1/5, 1/10
1 time, 2 times, 4 times, 8 times
Sensor travel direction setting
System ready: NOR,
integrated alarm: ALM,
pulse output error: PE,
sensor disconnected error: SE,
low power error: PF,
limit error: LE
Travel direction: CCW
Error clear input: CLR
Pulse output: PU, PD
CE Marking (EMC directive)
5
A/B phase pulse
1/1, 1/2, 1/4, 1/8
