- Page 1 ETAS ES134.1 Interface Extension Module User Guide...
- Page 2 Copyright The data in this document may not be altered or amended without special notification from ETAS GmbH. ETAS GmbH undertakes no further obligation in relation to this document. The software described in it can only be used if the customer is in possession of a general license agreement or single license.
-
Page 3: Table Of Contents
Connections ES134.1 ........ - Page 4 Contact Information ..............27 ETAS ES134.1 - User Guide...
-
Page 5: Safety Notices
Program codes or program control sequences that are created or changed via ETAS products, as well as all types of data obtained through the use of ETAS prod- ucts, must be checked for their reliability and suitability prior to use or distribution. -
Page 6: Intended Use
The product is designed in accordance with state-of-the-art technology. Only operate the product and its accessories if they are in perfect working order. Shut down a damaged product immediately. Do not open or alter the product. Only ETAS may make changes to the product. -
Page 7: Assembly
NOTICE indicates a situation, which may result in damage to property if not avoided. Assembly Only install, connect, disconnect and cable ETAS products and components when they are de-energized. Assembly location Install the product on a smooth, level and firm surface. -
Page 8: Electrical Connection
8 | Safety Notices If the firmware update is not completed successfully, try it again. If a new firmware update is not possible and the product is not functional, send the product to ETAS. WARNING Risk due to undefined vehicle behavior during an ECU reset If you operate the product in combination with ETKs, the ECU must not be reset in an uncontrolled manner. -
Page 9: Transport
- Make sure that no moisture enters the product. Repairs If repairs are required, send the product to ETAS. 1.10 Shipment and Packaging You can find the return form and information about this process on the ETAS web- site:www.etas.com/en/support/hw_return_form.php. ETAS ES134.1 - User Guide... -
Page 10: Hardware Description
Overview 2.1.1 Description The Interface Extension Module ES134.1 is equipped with two LIN bus interfaces for connection to the LIN bus of a vehicle or an ECU and with a Lemo connector for connection of the following products: - ES523.1 - ES592.1... -
Page 11: Design
Two independent LIN channels 2.2.2 LEDs The ES134.1 is equipped with 5 LEDs for displaying the module's operating state, as well as for displaying the function of the two LIN connections LIN 1 and LIN 2. Fig. 2-2 LED layout of the ES134.1... - Page 12 No error Flashing red Firmware update is being performed. Do not disconnect the module from the power supply. Lit red The boot process was not successful or the module encountered a software error. Restart the module. ETAS ES134.1 - User Guide...
-
Page 13: Updating The Firmware
Flashing red Communication error at LIN 2 interface Updating the Firmware The firmware for the product can be updated using the ETAS "Hardware Service Pack" (HSP) service software. You can find the software in the Download Center on the ETAS website: www.etas.com... -
Page 14: Multi-Client Support
LIN bus or internally by the module with the LIN reference voltage 24 V LIN systems In 24 V LIN systems, the LIN node of the ES134.1 module can only be supplied exter- nally by the LIN bus with the LIN reference voltage VBAT. -
Page 15: Commissioning
Ensure that the test setup is EMC-compliant. A test setup that uses shielded and unshielded components at the same time can lead to impairment of the sig- nal quality and is not recommended by ETAS. ETAS ES134.1 - User Guide... -
Page 16: Operation
- Only make changes when the vehicle is stationary (e.g. changes to the test setup, changes to the ETK configuration, software updates). NOTE If the ES134.1 is used as slave device, configure the ES134.1 like the master device of the LIN bus (e.g. LIN speed, LIN version etc.). ETAS ES134.1 - User Guide... -
Page 17: Technical Data
Marking for UKCA conformity (chapter 4.5 on page 19) Marking for KCC conformity (chapter 4.6 on page 19) Marking for CMIM conformity (Chapter 4.7 on page 19) Marking for WEEE (chapter 4.8 on page 20) ETAS ES134.1 - User Guide... -
Page 18: Norms And Standards
62.68 x 1.89 x 0.94 in Weight with cable 0.18 kg / 0.4 lb RoHS Conformity 4.2.1 European Union The EU Directive 2011/65/EU limits the use of certain dangerous materials for elec- tric and electronic devices (RoHS conformity). ETAS ES134.1 - User Guide... -
Page 19: China Rohs
"REACH Declaration" (www.etas.com/Reach). This information is continu- ously updated. CE Conformity With the CE mark attached to the product or its packaging, ETAS confirms that the product corresponds to the applicable, product-specific Directives of the Euro- pean Union. The CE Declaration of Conformity for the product is available upon request. -
Page 20: Product Return And Recycling
The user is obligated to separately collect old devices and provide them to the WEEE return system for recycling. The WEEE Directive applies to all ETAS devices, but not to external cables or bat- teries. Additional information about the recycling program of ETAS GmbH is available from the ETAS sales and service locations (see 7 on page 27). -
Page 21: Terminal Assignment
Terminal assignment of LEMO connector Signal UBATTP1 UBATTP2 UBATTM RX_D2+ TX_D1- RX_D2- UBATTM TX_D1+ Housing 4.11.2 Terminal Assignment of LIN interface DSUB (male) Fig. 4-4 ES134.1 DSUB connection Signal Not connected Not connected VBAT- Not connected Not connected VBAT- ETAS ES134.1 - User Guide... -
Page 22: Electrical Data
Compatible with the LIN standard used by Client 1 Electrical isolation Interface separated from the other interfaces : Selection of internal LIN V by INCA currently in preparation : Support for master operating mode by INCA currently in preparation ETAS ES134.1 - User Guide... - Page 23 23 | Technical Data NOTE Multi-client simulation scenarios: Turn on the LIN bus and configure all slave applications and PID responses before starting LIN communication. ETAS ES134.1 - User Guide...
-
Page 24: Cables And Accessories
• CBH500 Cable ............25 CBCF100 Cable Fig. 5-1 CBCF100 cable Y-cable for connecting a second LIN channel. DSUB connection (female) Fig. 5-2 DSUB connection (female) to the ETAS module Description Not connected Not connected VBAT- Not connected Not connected... -
Page 25: Cbh500 Cable
CAN/LIN/FLX NOTE The CBH500 cable only supports one LIN channel. Order designation Short name Order number CAN, LIN and FlexRay interface cable, CBH500-2 F 00K 106 276 DSUB-DSUB (9fc - 9mc + 9fc), 2 m ETAS ES134.1 - User Guide... -
Page 26: Order Information
• ES134.1 ........ -
Page 27: Contact Information
27 | Contact Information Contact Information Technical Support For details of your local sales office as well as your local technical support team and product hotlines, take a look at the ETAS website: www.etas.com/en/hotlines.php ETAS Headquarters ETAS GmbH Borsigstraße 24...
