ETAS ES585.1 User Manual

K-line interface compact user's guide

Advertisement

ES585.1
K-Line Interface Compact
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ES585.1 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ETAS ES585.1

  • Page 1 ES585.1 K-Line Interface Compact User's Guide...
  • Page 2 Copyright The data in this document may not be altered or amended without special notification from ETAS GmbH. ETAS GmbH undertakes no further obligation in relation to this document. The software described in it can only be used if the customer is in possession of a general license agreement or single license.
  • Page 3: Table Of Contents

    Contents 1 Introduction ........... . . 5 Functions/Features .
  • Page 4 8 ETAS Contact Addresses ........
  • Page 5: Introduction

    The ES585.1 K-Line Interface Compact is an ETAS Compact Module for con- necting a PC to an ECU. The ES585.1 is connected to the ECU via the K-Line and to the PC via the parallel printer interface. This makes a powerful and universal connection to the PC possible.
  • Page 6: Requirements

    K-Line-Software ProFWIN (programming of ECUs with Flash-EPROMs) • 1.4.3 Necessary Protocols in the ECU For the ES585.1 with the K-Line to be able to be used on an ECU, the following protocols have to be implemented in the ECU: Application Protocol...
  • Page 7: Hardware Description

    Block Diagram Fig. 2-1 ES585.1 Block Diagram Housing A compact, stable metal housing is used for the ES585.1. The ES585.1 is spe- cifically designed to be installed in the passenger cell. ES585.1 SN 0 00 0 F 00 K 0 00 6 67 Fig.
  • Page 8: Ecu Interface

    The P-Module provides a programming voltage for flash EPROMs. 2.3.4 Display Element There is a display element (LED) on the back of the ES585.1 which indicates the operating states of the ES585.1. The following table lists what this LED indicates.
  • Page 9: Hardware Configuration And Installation

    (see chapter 6 on page 17). The connection must not be longer than 10 m. Firmware Update The firmware of the ES585.1 can be updated by the user from the connected PC using a service software. The program HSP is required for the firmware update of the ES585.1.
  • Page 10 Hardware Configuration and Installation...
  • Page 11: Functional Description

    The physical transfer of the data takes place at the PC printer interface (Cen- tronics) • from the PC to the ES585.1 in Byte mode via the data lines of the Cen- tronics interface and • from the ES585.1 to the PC in Nibble mode via several control lines of the Centronics interface.
  • Page 12 Functional Description...
  • Page 13: Technical Data

    This section describes the pin assignment of the ES585.1. (Centronics) 5.1.1 PC Printer Interface Fig. 5-1 ES585.1 Printer Interface The Centronics interface of the ES585.1 can work with every standard printer interface of a PC. 5.1.2 ECU Interface (K-Line) Fig. 5-2 ES585.1 Interface to the ECU...
  • Page 14: General Data

    General Data 5.2.1 Mechanical Data The dimensions listed in the table refer to the housing of the basic ES585.1 device without cables. Height 17 mm (0.7 in.) Width 59 mm (2.3 in.) Depth 71 mm (2.8 in.) Weight 260 g 5.2.2...
  • Page 15: Printer Interface

    5.3.3 Printer Interface Printer interface Centronics 5.3.4 Analog Output Output voltage 0 V to 4.096 V Δ=1.0 mV Quantization Resolution 12 Bit Technical Data...
  • Page 16 Technical Data...
  • Page 17: Cable And Accessories

    K-Line L-Line Green L-Line Analog output (programming voltage Blue Reserved for Flash-EPROMs) 1) ES585.1: not used Tab. 6-1 Cable Adapter KA45: Assignment of the Plugs Order Name Length Order Number Cable Adapter KA45 0.2 m (0.6 ft) F 00K 000 581...
  • Page 18: Cable K78

    Cable K78 Fig. 6-2 K-Line Interface Cable K78 Order Name Length Order Number K-Line Interface Cable K78 3 m (9.8 ft) F 00K 000 579 Cable K96 Fig. 6-3 K-Line Interface Cable K96 Order Name Length Order Number K-Line Interface Cable K96 8 m (26.3 ft) F 00K 000 383 Cable CBK100-1m5...
  • Page 19: Cable Adapter Ka18

    Cable Adapter KA18 Fig. 6-5 Cable Adapter KA18 Order Name Length Order Number Cable Adapter for K-Line Extension 0.2 m (0.6 ft) Y 261 A24 405 KA18 Cable Adapter K72 Fig. 6-6 Cable Adapter K72 Order Name Length Order Number Cable Adapter K72 3 m (9.8 ft) F 00K 000 372...
  • Page 20 Cable and Accessories...
  • Page 21: Ordering Information

    Ordering Information ES585.1 Order Name Short Name Order Number ES585.1 including ES585.1 F 00K 000 667 Cable Adapter KA45 Accessories Order Name Short Name Order Number Cable Adapter KA45 KA45 F 00K 000 581 Cable Adapter K72 F 00K 000 372...
  • Page 22 Ordering Information...
  • Page 23: Etas Contact Addresses

    Fax: +49 711 89661-105 Germany E-mail: sales@etas.de WWW: www.etasgroup.com North America ETAS Inc. 3021 Miller Road Phone: +1 888 ETAS INC Ann Arbor, MI 48103 Fax: +1 734 997-9449 E-mail: sales@etas.us WWW: www.etasgroup.com Japan ETAS K.K. Queen's Tower C-17F Phone:...
  • Page 24 +86 21 5037 2221 Shanghai 200120 E-mail: sales.cn@etasgroup.com P.R. China WWW: www.etasgroup.com India ETAS Automotive India Pvt. Ltd. No. 690, Gold Hill Square Phone: +91 80 4191 2585 12F Hosur Road, Bommanahalli Fax: +91 80 4191 2586 Bangalore 560 068 E-mail: sales.in@etasgroup.com...
  • Page 25: List Of Figures

    ES585.1Housing..................7 Fig. 3-1 ES585.1 Connection ................. 9 Fig. 5-1 ES585.1 Printer Interface................. 13 Fig. 5-2 ES585.1 Interface to the ECU ..............13 Fig. 6-1 Cable Adapter KA45 ................17 Fig. 6-2 K-Line Interface Cable K78 ..............18 Fig. 6-3 K-Line Interface Cable K96 ..............
  • Page 26 List of Figures...
  • Page 27: Index

    Byte mode 11 ECU 5 protocols in the 6 Electrical data 14 Environmental conditions 14 Cable adapter 9 ES585.1, ordering information 21 Cable Adapter KA18 19 ETAS Contact Addresses 23 Cable Adapter KA45 17 Extension cable 9 Cable Adapter KA72 19...
  • Page 28 ISO 9141-2 5 K-Line 5 LED 8 Mechanical Data 14 Nibble mode 11 Ordering information 21 accessories 21 ES585.1 21 Pin assignment 13 P-Module 8 Power supply 8 Programming voltage 8 Protocols 5 Protocols in the ECU 6 Protocols to be implemented 6...
