3. If it is necessary to do power consumption measurement during debugging, STMicroelectronics has an
interesting solution. It is possible to use an STLINK-V3PWR. This product allows two sources of supply: a first
for the current measurement on the STM32WBA65RI, and a second source to supply the rest of the board
(LEDs). As in the previous case, the jumper (JP2) must be OFF, and the main supply (for current
measurement) connected to pin 1 of JP2 (refer to
set JP4 OFF and connect this source to the top side (pin 10, 8, 6, 4, or 2 of JP4).
The supply voltage on JP2 must be 3V3.
The details above concern the supply of the board by STLINK-V3PWR. The debug probe must be connected
on the CN14 on the mezzanine board (MB2143).
UM3462 - Rev 1
Figure 17. Current measurement with STLINK-V3PWR
U11
3.3 V LDO
U9
Power switch 5 V/3 A
®
USBC protection
U18
JP4
5V
5V_STLK
3.3 V LDO
5V_VIN
5V_EXT
VBUS_STLK
JP4
5V_USB_MCU
Figure 17). For the second source (+5V), it is necessary to
3V3_STLK
3V3
JP2
Ammeter
+5Vaux
STLINK-V3PWR
UM3462
Hardware layout and configuration
ST_LINK/V3EC
Joystick (B1)
Grove connector (CN12)
Digital microphone (U21)
OLED (U13)
MIPI10 (CN14)
TAG (CN15)
STM32WBA65RI
